Sony ILCE-QX1 Service Manual

SERVICE MANUAL
Ver. 1.1 2014.10
Revised-1
Replace the previously issued
SERVICE MANUAL 9-896-704-11
with this Manual.
Note:
Be sure to keep your PC used for service and checking of this unit
always updated with the latest version of your anti-virus software.
In case a virus affected unit was found during service, contact your
Service Headquarters.
[About the service of this model]
ILCE-QX1L is commodity that packed the Interchangeable Lens Digital Camera and Interchangeable Lens.
Refer to each following service manual the Interchangeable Lens kit, when you repair.
Model
ILCE-QX1
ILCE-QX1L SELP1650 (E PZ 16-50mm F3.5-5.6 OSS)
Model information table
Model
Destination US, CND, AEP, UK, RU, E, HK, CH, KR, JE, J
Color system
Lens
• Abbreviation
CH : Chinese model
CND : Canadian model
HK : Hong Kong model
J : Japanese model
JE : Tourist model
KR : Korea model
RU Russian model
:
ILCE-QX1/QX1L
9-896-704-12
ILCE-QX1/QX1L
Photo: ILCE-QX1 (Main body)
Lens
No supplied lens
ILCE-QX1
NTSC
–
INTERCHANGEABLE LENS DIGITAL CAMERA
Sony Corporation
注意：
修理時に使用するパソコンは，ウィルス検出ソフトが常にアップ
デートを行っているパソコンを使用してください。もし，修理を
行うセット，もしくはパソコンがウィルスに感染している事が判
明した場合は，ソニーグループ内は社内技術相談窓口に，特約店
様は特約店様専用電話窓口 （修理窓口） にご相談ください。
Service Manual of Lens
No supplied lens
9-834-693-1[]
ILCE-QX1L
US, CND, AEP, UK, RU, E, HK, CH, KR, JE, J
NTSC
E PZ 16-50 mm F3.5-5.6 OSS
Published by Sony Techno Create Corporation
US Model
Canadian Model
AEP Model
UK Model
Russian Model
E Model
Hong Kong Model
Chinese Model
Korea Model
Japanese Model
Tourist Model
2014J08-1
© 2014.10
