CA611 Owners Manual
CAUTION!
Be certain that the vehicle is outdoors before using this or any re-
mote vehicle starting device. A running engine produces dangerous
carbon monoxide fumes which can be harmful or fatal if prolonged
exposure occurs. DO NOT remote start the vehicle if the car is
garaged.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA611 and is the answer not in the manual?

Questions and answers

Related Manuals for Code Alarm CA611

Summary of Contents for Code Alarm CA611

  • Page 1 CA611 Owners Manual CAUTION! Be certain that the vehicle is outdoors before using this or any re- mote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if the car is...

  • Page 2: Arming The System

    Your Remote Start Alarm System has many features and available options some of which are selected at time of installation. Consult your installing dealer for options that may have been installed and are not listed. ARMING THE SYSTEM: 1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk. 2.

  • Page 3: Protection While The System Is Armed

    ARMING THE SYSTEM: If the passive arming feature has been selected: Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk. The LED will begin to flash rapidly indicating that the 30 second passive arming timer has begun. If the dash mounted LED does not begin to flash rapidly, then you have left a door, hood, or trunk ajar.

  • Page 4: Disarming The System

    DISARMING THE SYSTEM: As you approach the vehicle, press and release the Disarm button on the transmitter. The parking lights will flash 2 times, the siren/horn will chirp 2 times, and the LED will turn off. If you have the optional door lock/unlock circuit installed, the doors will unlock. If you have the optional entry illumination circuit installed, the interior light will turn on for 30 seconds or until the ignition key is switched on.

  • Page 5: While The System Is Sounding

    zone. For additional information, refer to INTRUSION WARNING SIGNALS (page 5) of this manual. NOTE: If the optional 2 step door unlock circuit is installed, when the unlock transmitter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock.

  • Page 6: Valet Mode

    VALET MODE: The valet button allows you to temporarily bypass all alarm functions, eliminating the need to hand your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions are bypassed, however the remote panic feature, remote door locks and remote start will remain operational.
  • Page 7 Disarm the system by use of the transmitter, or by use of the emergency override sequence. Turn the ignition switch to the ON position. Within 10 seconds, press and release the valet/override button 3 times. Within 10 seconds turn the ignition switch OFF, ON, OFF, ON, OFF, ON. (The siren/horn will sound and the lights will flash one time.) Within 10 seconds, begin to enter your chosen 10ths digit by pressing and releasing the button from 1 up to 9 times.
  • Page 8 Within 10 seconds, begin to press and release the push button switch to set the tenths digit. (As per example press and release 5 times to set the tenths digit to 5) Within 10 seconds of the last press of the button, turn the ignition OFF then ON.

  • Page 9: Eliminating The Normal Arm/Disarm Chirps

    new code tenths for step 2 above, and units for step 5 above. ELIMINATING THE NORMAL ARM/DISARM CHIRPS You can selectively eliminate the normal arm and disarm chirps by holding the transmitter button slightly longer when arming or disarming. This will prevent the siren/horn chirps for one arm or disarm cycle.

  • Page 10: Remote Starting The Vehicle

    REMOTE STARTING THE VEHICLE: Press and release the option button of your transmitter 2 times within 2 seconds to activate the remote start system. The vehicle will start and remain running for the pre-programmed 10 or 15 minutes. As a visual indication, the parking lights will flash or turn on depending on the programming set up by your installa- tion center.
  • Page 11 ADDITIONAL REMOTE FUNCTION CHANNEL 3/TRUNK: The system has an additional feature (Channel 3) that can be connected to the Trunk Release. To operate the accessory associated with channel 3, press and hold the trunk button of your transmitter for 4 seconds. ADDITIONAL REMOTE FUNCTION CHANNEL 4: The system has an additional feature (Channel 4) that can be connected to a number of different optional accessories.
  • Page 12 CA 611 SYSTEM FUNCTIONS AT A GLANCE ALARM DASH MOUNTED LED INDICATORS RAPID FLASHING SLOW FLASHING ON SOLID 2 FLASH...SOLID 3 FLASH...PAUSE 2 FLASH...PAUSE 1 FLASH...PAUSE ALARM SIREN/HORN CHIRP INDICATION 1 CHIRP 2 CHIRPS 3 CHIRPS 4 CHIRPS 5 CONTINUOUS ALARM PARKING LIGHT INDICATIONS 1 FLASH 2 FLASH...
  • Page 13 Code Systems, Inc. Limited Lifetime Warranty Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE vehicle security product (the “Product”), purchased from an authorized CODE dealer, that (except as provided below) should this Product under normal use and conditions, be proven defective in material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGINALLY INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for parts directly related to repairs of the defect(s).
