- Page 1 Model CD5400 User Guide Compact Disc Player CLASS 1 LASER PRODUCT LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. Read Instructions – All the safety and operating instructions should be read before the product is operated. Retain Instructions –... - Page 3 Servicing – Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power-supply cord or plug is damaged.
- Page 4 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
-
Page 6: Table Of Contents
CONTENTS 1. BEFORE USING... 3 2. ACCESSORIES ... 5 3. FEATURES ... 6 4. CONNECTIONS ... 7 5. NAMES AND FUNCTIONS... 8 Front panel ... 8 Display ... 9 Remote control unit ... 10 Rear panel ... 11 6. BASIC OPERATIONS ... 12 Playing CDs ... -
Page 7: Before Using
To ensure proper heat dissipation, install the player while leaving clearances between the player and wall or other components, as shown in the figure below. 2 cm or more 10 cm or more CD PLAYER CD5400 OPEN/CLOSE DISC RNDM RROG A –... -
Page 8: Cautions On Handling Batteries
BEFORE USING Do not place objects on top • Refrain from placing any objects on top of the player. Cautions on handling power cord • Do not touch the power cord with wet hands. • When disconnecting the power cord, always make sure that you take hold of the plug. -
Page 9: Accessories
2. ACCESSORIES Checking the accessories After opening the cover of the packing box, check that the following accessories are included. • Remote control unit (RC5400CD) DISPLAY POWER PROGRAM CANCEL RANDOM QUICK REPLAY PITCH RESET REPEAT SCROLL/ TEXT TIME RECALL REMOTE CONTROLLER RC5400CD •... -
Page 10: Features
CS4396 D/A converter, which was also made by Cirrus Logic and which has proved to be a valuable asset for the Marantz CD player, has been adopted. During CD play, the PCM signals recorded on the disc are... -
Page 11: Connections
4. CONNECTIONS This CD player is connected to an amplifier, CD recorder and other components for use. To ensure that the components are connected properly, refer to the instruction manuals that come with the components to be connected. Before connecting the components, be absolutely sure to turn off their power. -
Page 12: Names And Functions
5. NAMES AND FUNCTIONS Front panel CD PLAYER CD5400 STANDBY POWER ON/STANDBY z POWER ON/STANDBY switch and Standby indicator This is used to turn the player’s power ON and STANDBY. When it is pressed, the display lights and the power is turned on;... -
Page 13: Display
NAMES AND FUNCTIONS Display DISC TEXT 1 2 a Main display This displays the time information and text information of the disc played, the setting menus, etc. b TEXT indicator This lights when a disc supporting CD-TEXT has been loaded. c 8 8 8 8 8 (pause) indicator This lights when play is temporarily suspended. -
Page 14: Remote Control Unit
NAMES AND FUNCTIONS Remote control unit DISPLAY POWER PROGRAM CANCEL QUICK REPLAY RANDOM PITCH RESET REPEAT SCROLL/ TEXT TIME RECALL REMOTE CONTROLLER RC5400CD q DISPLAY button This is used to turn off the display (DISPLAY OFF mode). w Numeric buttons (0 to 9) These are used to specify the numbers of the tracks to be played. -
Page 15: Rear Panel
Before using the supplied connecting cable to make the connection between the player and the remote control connectors on a Marantz equipment, set the switch to EXTERNAL. Note: Signals cannot be received from the remote control unit if the switch is kept at EXTERNAL when the player is to be used on its own. -
Page 16: Basic Operations
6. BASIC OPERATIONS Playing CDs CD PLAYER CD5400 OPEN/CLOSE DISC RNDM RROG A – B RPT 1 PITCH EDIT PEAK TIME STANDBY TEXT 1 2 9 10 11 12 13 14 15 16 17 18 19 20 POWER ON/STANDBY TIME... -
Page 17: Playing A Specific Track
BASIC OPERATIONS Playing a specific track • Specifying the number of a track to be played (direct search) Select the number of the track to be played directly by pressing the numeric buttons (0 to 9) on the remote control unit. To select track number 10 or above, use the numeric buttons to select the higher digit first and then select the lower digit. -
Page 18: Playing A Specific Part Of A Specific Track
BASIC OPERATIONS Playing a specific part of a specific track • Searching a specific part of a track (search) While listening to a track being played, it is possible to search a specific part of that track by a forward or backward search. Forward searching through the track now playing PLAY OPEN/CLOSE... -
Page 19: Advanced Operations
7. ADVANCED OPERATIONS Repeat play (playing the same tracks repeatedly) • Playing all tracks repeatedly (all-track repeat) This function repeatedly plays all the tracks. Repeat play is possible even during random play or program play. Press the REPEAT button on the remote control unit. PITCH RESET REPEAT... -
Page 20: Random Play (Playing Tracks In A Random Sequence)
ADVANCED OPERATIONS Random play (playing tracks in a random sequence) This function rearranges the tracks into a random sequence and it then plays all the tracks in this random sequence. If it is used together with repeat play, the same tracks can be repeatedly played but in a different sequence every time. -
Page 21: Program Play (Playing Tracks In The Preferred Sequence)
ADVANCED OPERATIONS Program play (playing tracks in the preferred sequence) The order in which the CD tracks are played can be rearranged into the sequence desired. Up to 30 tracks can be programmed. • Program play in the time display mode In the case of a CD-TEXT disc, first press the TIME button on the remote control unit to set the main display to the time display mode. - Page 22 ADVANCED OPERATIONS • Program play in the text display mode In the case of a CD-TEXT disc, tracks can be selected by title for program play. If the main display is set to the time display mode, press the TEXT button on the remote control unit to establish the text display mode.
-
Page 23: Delete Program Play (Play With Undesired Tracks Skipped)
ADVANCED OPERATIONS Delete program play (play with undesired tracks skipped) This function makes it possible to skip those tracks that you do not want to hear during CD play. Up to 30 tracks can be deleted from the program. • Delete program play in the time display mode In the case of a CD-TEXT disc, first press the TIME button on the remote control unit to set the main display to the time... - Page 24 ADVANCED OPERATIONS • Delete program play in the text display mode In the case of a CD-TEXT disc, the tracks that are not desired can be selected by title for delete program play. If the main display is set to the time display mode, press the TEXT button on the remote control unit to establish the text display mode.
-
Page 25: Program Play
ADVANCED OPERATIONS • Checking the program or delete program contents REPEAT SCROLL/ TEXT TIME RECALL During programming operation or program play, press the SCROLL/RECALL button on the remote control unit. With program play, the programmed tracks are displayed one after the other in sequence on the main display. With delete program play, the deleted tracks are displayed one after the other in sequence on the main display. -
Page 26: Peak Search (Searching For The Loudest Passage)
ADVANCED OPERATIONS Peak search (searching for the loudest passage) If the cassette deck recording level is adjusted in relation to the peak level on the disc, it is possible to avoid distortion and noise in recording. This facility allows the peak over the entire disc or in the programmed to be detected tracks before proceeding to editing. -
Page 27: Program Edit
• Start Edit Recording Before start editing, connect remote control input of Marantz cassette deck with remote control output of CD5400 by remote control cable. Reverse mode switch may be set to any of one side ( both sides (... - Page 28 ADVANCED OPERATIONS - Synchro recording with Marantz one-way cassette deck, or Marantz auto reverse cassette deck set to one side ) mode. After setting up Edit program, setup the cassette deck to rec pause state. Press 3 or 8 buttons of the player to start A side program.
-
Page 29: Pitch Control (Changing The Play Speed)
ADVANCED OPERATIONS Pitch control (changing the play speed) The play speed (pitch) can be changed across a ± 12 step. ∗ Digital signals are not output during pitch control. • Increasing the play speed Press the PITCH+ button on the remote control unit. PITCH RESET The “PITCH”... -
Page 30: Other Functions
8. OTHER FUNCTIONS CD-TEXT “CD-TEXT” refers to a new kind of music disc which differs from a conventional music disc in that album titles, track titles and other text information are recorded on it. CDs with the following logos support this function. CD TEXT TEXT The text information is recorded on those parts which were... -
Page 31: Specifications And Dimensions
Allowable operating temperature ... +5 to +35°C Allowable operating humidity ... 5 to 90% (no condensation) This player’s specifications and exterior are subject to change without notice for improvements. Dimensions (unit: inch (mm)) 17-5/16 (440) CD PLAYER CD5400 PLAY STOP OPEN/CLOSE DISC RNDM RROG A –... -
Page 32: Troubleshooting
If the trouble persists even after the following points have been checked, consult your dealer or nearest Marantz sales office or service center. Disc fails to turn. • Has the power cord been connected properly? •... - Page 33 You can find your nearest authorized distributor or dealer on our website. JAPAN Marantz Japan, Inc. U.S.A. Marantz America, Inc. EUROPE Marantz Europe B.V. Printed in China 35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505, Japan 1100 Maplewood Drive, Itasca, IL 60143, U.S.A.
