Device addressing
Picture Perfect
Picture Perfect uses 2RP Board numbers to address
readers, DIs, and DOs on the 8RP Board. See Table 1 and
Table 2 for further information. Picture Perfect uses the
following addressing:
•
Reader ports 1 and 2 are configured as board number
1, reader address 0 and 1
•
Reader ports 3 and 4 are configured as board number
2, reader address 0 and 1
•
Reader ports 5 and 6 are configured as board number
3, reader address 0 and 1
•
Reader ports 7 and 8 are configured as board number
4, reader address 0 and 1
Table 1: 8RP device addressing - Picture Perfect Board 1
Board type: Board 1 [1}
Reader 1
and 2
Picture Perfect
1
board number
Readers
0 and 1
Door DIs
0 and 1
Exit DIs
8 and 9
Door DOs
0 and 1
[1] The first 8 readers out of 16. See Table 5 for board type settings.
Setting the DIP switches
Set the DIP switches as described in the tables below before installing and wiring the 8RP Board.
Table 4: DIP switch settings for reader technology and format
Reader technology and format
Magstripe - GE supervised F/2F
Magstripe - F/2F
2 of 6
Reader 3
Reader 5
Reader 7
and 4
and 6
and 8
2
3
4
0 and 1
0 and 1
0 and 1
0 and 1
0 and 1
0 and 1
8 and 9
8 and 9
8 and 9
0 and 1
0 and 1
0 and 1
SW 1-1
ON
ON
Table 2: 8RP device addressing - Picture Perfect Board 2
Board type: Board 2 [1]
Reader 9
and 10
Picture Perfect
5
board number
Readers
0 and 1
Door DIs
0 and 1
Exit DIs
8 and 9
Door DOs
0 and 1
[1] The second 8 readers out of 16. See Table 5 for board type settings.
Facility Commander Wnx and Secure Perfect
The Facility Commander Wnx and Secure Perfect systems
create the device addresses shown in Table 3. (Table 3 is
included for your reference only.)
The device address is in the format mmmm-b-pp where
mmmm represents the controller number, b represents the
board number, and pp represents the point or device
number.
Table 3: 8RP device addressing - FCWnx and Secure Perfect
Readers/Door DO
Door DIs
Exit DIs
SW 1-2
SW 1-3
OFF
ON
ON
ON
Reader 11
Reader 13
and 12
and 14
6
7
0 and 1
0 and 1
0 and 1
0 and 1
8 and 9
8 and 9
0 and 1
0 and 1
Standard/Board 1
Board 2
mmmm-1-01
mmmm-2-01 through
through
mmmm-2-08
mmmm-1-08
mmmm-1-01
mmmm-2-01 through
through
mmmm-2-08
mmmm-1-08
mmmm-1-01
mmmm-2-01 through
through
mmmm-2-08
mmmm-1-08
SW 1-4
OFF
OFF
P/N 460235001J • ISS 21MAR08
