- Page 1 EchoLife HG8145V5 Quick Start for QR code Issue Date 2022-11-08 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
EchoLife HG8145V5 Quick Start for QR code Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................4 3 Indicator Description......................6 4 Technical Specifications......................8 5 FAQs............................9 Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
● It is recommended that the computer and ONT be put far away from electric appliances that generate strong magnetic or electric fields, such as microwave ovens. Mounting an ONT on the desk The figure below shows an ONT that is horizontally placed on a desk. Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd. - Page 5 Use a screwdriver to fasten the screws into the expansion bolts, reserving 3 mm ends out of the wall, and mount the ONT onto the screws. Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd.
- Page 6 EchoLife HG8145V5 Quick Start for QR code 1 Placing the Device NO TE It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd.
-
Page 7: Connecting Cables
● To ensure normal use of fibers, make sure that the fiber bending radius is larger than 30 Item Description On/Off Powers the ONT on or off. Power Connects to a power adapter. Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd. - Page 8 NOTE Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to access the Internet. If an ONT cannot access the Internet after a reset, contact your Internet service provider.
-
Page 9: Indicator Description
Data is being transmitted on the USB port. The system is not powered on or the USB port is not connected. WLAN Steady on The WLAN function is enabled. Blinking Data is being transmitted over the WLAN port. Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd. - Page 10 The ONT is not connected to fibers or does once not receive optical signals. every 2 seconds Blinks once Blinks The hardware is faulty. every 2 once seconds every 2 seconds Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd.
-
Page 11: Technical Specifications
● Dimensions (H x W x D): 30 mm x 173 mm x 120 mm (without external antenna and pads) ● Weight: About 250g ● Maximum system power consumption: 18 W Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd. -
Page 12: Faqs
How do I log in to the Huawei ONT web page? ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. Enter the IP address in the address box of a browser and press Enter. On the displayed login page, enter the username and password. - Page 13 ● Wired login Use a network cable to connect a PC to the Huawei ONT. Set the IP address of the PC in the same subnet as the web address of the For example, if the web address of the Huawei ONT is Huawei ONT.
- Page 14 ● Change the initial password after logging in to the web page for the first time. How do I change the Wi-Fi password? Log in to the Huawei ONT web page using your mobile phone, pad, or PC. For details, see "How do I log in to the Huawei ONT web page?"...
- Page 15 -72dBm), it is recommended to adjust ONT positions or add new repeaters to enhance the Wi-Fi coverage. 3. Using the correct radio channel. Generally, the Huawei ONT selects channels adaptively. If the network is slow or the quality turns poor from time to time, you can use a WiFi scanner such as WiFi Stumbler or WiFi Analyzer to search for the optimal channel.
- Page 16 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
Need help?
Do you have a question about the EchoLife HG8145V5 and is the answer not in the manual?
Questions and answers
How do I install the device to start using it
The Huawei EchoLife HG8145V5 device should be installed as follows:
1. Placement:
- Do not install the ONT outdoors or in an outdoor cabinet.
- It can be mounted on a wall or placed on a desk.
- Do not install it on the ceiling or in other unsupported positions.
- Ensure a clearance of at least 10 cm on all sides for proper ventilation.
2. Connecting Cables:
- Follow the appropriate steps to connect power, fiber optic, Ethernet, and other necessary cables.
3. Indicator Check:
- Verify the status of the indicator lights to ensure proper operation.
These steps ensure safe and effective installation of the device.
