MAMMOMAT 3000 Modular
Service
Modification Instructions
Installation of the option W/Rh anode/filter
combination
Register 5
Print No.: SPB7-230.092.11.01.02
Replaces: N/A
SP
© Siem ens A G 1 998
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model
_or_ design,_are_
reserved.
English
Doc. Gen. Date: 04.98
65 02 004
Advertisement
Table of Contents
Related Manuals for Siemens MAMMOMAT 3000 Modular
Summary of Contents for Siemens MAMMOMAT 3000 Modular
- Page 1 MAMMOMAT 3000 Modular Service Modification Instructions Installation of the option W/Rh anode/filter combination © Siem ens A G 1 998 The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages.
- Page 2 0 - 2 Revision Chapter Page Revision MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 2 of 4 Siemens-Elema AB Service Rev. 01 04.98 SPS-UD Solna, Sweden...
- Page 3 0 - 4 Contents This page intentionally left blank. MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 4 of 4 Siemens-Elema AB Service Rev. 01 04.98 SPS-UD Solna, SWEDEN...
-
Page 4: Table Of Contents
Final procedure ........3 - 8 Siemens-Elema Register 5 SPB7-230.092.11 Page 3 of 4 MAMMOMAT 3000 Modular Solna, Sweden Rev. 01 04.98... -
Page 5: Purpose
Prerequisites 1 - 1 Purpose The purpose of this modification is to upgrade a MAMMOMAT 3000 Modular with Mo X-ray tube to Mo/W X-ray tube. Tools and expendables required • Standard assembly tools • Circlip pliers • Denatured ethanol, 99.5 % pure (may only be denatured with toluene, which does not leave any residues when evaporated) for cleaning the filters or tube window. -
Page 6: Symbols
1 - 2 Prerequisites Symbols Checks and adjustments requiring X-ray to be switched on are marked with the radiation- warning symbol. Protect yourself. MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 2 of 2 Siemens-Elema AB Service Rev. 01 04.98 SPS-UD... -
Page 7: Removal Of Collimator Cover
Disassembly 2 - 1 Removal of collimator cover Fig 2.1 Switch off the MAMMOMAT 3000 Modular. Remove the swivel-arm covers. Remove the collimator cover (1) by unscrewing four Allen screws (2). NOTICE Do not remove any other Allen screws than shown in figure 2.1. -
Page 8: Removal Of Diaphragm-Plate Assembly
To release the diaphragm-plate assembly, cut the cable ties on each side of the tube head Fig. 2.4 Lower the diaphragm-plate assembly and let it hang in the cables (7). MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 2 of 4... -
Page 9: Removal Of Old Filter Assembly
Remove the two front guides (10). The rear guide need not be removed. Remove the filter assembly. NOTICE Be careful not to damage the optical switch position sensor (11) during the removal. Siemens-Elema AB Register 5 SPB7-230.092.11 Page 3 of 4 MAMMOMAT 3000 Modular Solna, Sweden Rev. 01 04.98 SPS-UD Service... - Page 10 2 - 4 Disassembly This page intentionally left blank. MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 4 of 4 Siemens-Elema AB Service Rev. 01 04.98 SPS-UD Solna, Sweden...
-
Page 11: Installing The New Filter Assembly
Fit the lamp holder (4) to the diaphragm-plate holder and fasten with the two Allen screws (3). Replace the cable ties that were cut during the removal of the diaphragm-plate assembly. Siemens-Elema AB Register 5 SPB7-230.092.11 Page 1 of 8 MAMMOMAT 3000 Modular Solna, Sweden Rev. 01 04.98 SPS-UD Service... -
Page 12: Connecting The Service Pc
3 - 2 Installation Connecting the service PC Connect a service PC to the MAMMOMAT 3000 Modular. Switch on the MAMMOMAT 3000 Modular. Start the service program. Configuring and calibrating the tungsten (W) anode In “Main menu”, choose “Configuration”, then “Anode”. Set the value to “Enable”... - Page 13 Provide new cable ties at the rear mounting screws of the X-ray tube. System ON. Check the operation of the filter-assembly motor by selecting different anode/filter combinations on the control panel. Siemens-Elema AB Register 5 SPB7-230.092.11 Page 3 of 8 MAMMOMAT 3000 Modular Solna, Sweden Rev. 01 04.98 SPS-UD Service...
-
Page 14: Panel Programming
“CAUTION!!! Pressing <ALT> + <F6> releases exposure. Protect yourself.” is shown. Press <ALT> + <F6> to release exposure. After the exposure the divergence (%) from the correct adaptation value is shown. MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 4 of 8... -
Page 15: Small Focus W/Rh
Small tungsten focus Attach an 18 24 table. With the MAMMOMAT 3000 Modular switched off, make a connection between X813.9, board side, an D801 and +24 V. This will simulate the magnification table and small focus will be selected. To do this (see fig 3.4): 2.1 Unplug X813 on D801. - Page 16 Fig 3.4 Select W/Rh anode/filter combination. Check the light field/radiation field according to the Installation and Set-up Instructions for MAMMOMAT 3000 Modular. The beam limiting device must not run into its mechanical NOTICE endstop. If it does the value must be changed.
-
Page 17: Filter Purity Verification
“Configuration”, “Beam limiting device”, “Small tungsten, mm from edge”. Press <F2> to calibrate and then <F2> to save. With the MAMMOMAT 3000 Modular switched off, follow the procedure described in step 2 in the reversed order to remove the adapter cable and restore connector X813 to its original state. -
Page 18: Final Procedure
Fit the collimator cover (1) and fasten with the four Allen screws (2) (see fig 2.1). Check that all three anode/filter combinations can be chosen for both large/small focus and 24 30 table (if used). System OFF. Reinstall the swivel-arm covers. MAMMOMAT 3000 Modular Register 5 SPB7-230.092.11 Page 8 of 8 Siemens-Elema AB Service Rev.
