- Page 1 OWNERS MANUAL Lectric XP Lite V 1.2 | 2022 www.lectricebikes.com 602.715.0907 To prevent PROPERTY DAMAGE, SERIOUS INJURY, or DEATH, you should read, understand, and follow the warnings and instructions in this manual. Keep for future reference. L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 2 You should become thoroughly familiar with the proper operation of your Lectric eBike, its features, capabilities, and limitations. To ensure a long, trouble-free life for your Lectric eBike, provide it with the proper care and maintenance as described in this manual.
-
Page 3: Table Of Contents
Preparing to Ride Your First Ride Battery Pack Storing Your Lectric eBike Transporting Your Lectric eBike Disposal of Your Lectric eBike Troubleshooting Maintenance Legal L E CT R I C E B I K E S.C O M | 602.715.0907... -
Page 4: Important Safety Information
It is the rider’s responsibility to obey the regulations that apply to your Lectric eBike. The regulations covering the use of your Lectric eBike vary by state, and even municipality in certain locations. You must comply with the local regulations related to the minimum age of the rider, driver’s license, insurance, license plate, traffic, and maximum speed... - Page 5 Intended Use The intended use of your Lectric eBike is to be ridden by one adult rider (age 18 and up) at an appropriate time and place for general transportation and/or recreational use. Any other use is prohibited and may result in SERIOUS INJURY or DEATH.
- Page 6 • Read all safety warnings and all instructions. • Always ride within your limits and the limits of your Lectric eBike. • Bicycles are only for use by persons 18 years of age and above. Riders must have the physical coordination, reaction, and mental...
- Page 7 Helmets • Always wear a helmet. Wearing a helmet properly may reduce the risk of a severe head injury. When riding, always wear a helmet that meets or exceeds the standards of the Consumer Product Safety Commission (CPSC). Check the manual that comes with your helmet.
- Page 8 Follow eBike Regulations On and Off the Road • Be aware of eBike regulations in your area. Generally, the regulations for the use of an electric bicycle are the same as those for a standard bicycle. However, there may be local differences such as where you can ride, minimum rider age, or required equipment and license and registration regulations.
- Page 9 • Your electric bicycle can withstand light rain and small splashes, but it is not designed to be subjected to inclement weather, extremely heavy showers, or submersion in water. The electric bike’s components have an IP rating of 65. Water damage is not covered under the warranty.
- Page 10 On-Product Warning Labels There are warning labels on your Lectric eBike for your protection. If a label is missing or is not legible, contact Lectric eBikes for a replacement. Stem label Class 2 label...
- Page 11 L E CT R I C E B I K E S.C O M | 602.715.0907...
-
Page 12: Getting Started
2 Battery Manufacturer Keys Manuals If anything is missing or is damaged, contact Lectric eBikes immediately for assistance. For a video about how to unfold your bicycle, visit our YouTube page: Lectric eBikes. L E CT R I C E B I K E S.C O M | 602.715.0907... - Page 13 Serial Number Your serial number is located on the head tube of the bicycle as shown below. Please write it down inside the front cover of this manual. You may be asked for your bicycle’s serial number as part of a warranty request.
- Page 14 Stem Continued To fold: 1. Pull up on the silver button labeled “open” to unlock the latch. 2. Pull the latch away from the stem while still holding the “open” button. 3. Fold the stem by lowering it to the side. Frame To unfold: 1.
- Page 15 Pedals To unfold: 1. Push each pedal down until you hear an audible click as they lock into position. To fold: 1. Grasp pedal and push lightly toward bicycle. 2. Continue pushing while raising pedal into its folded position. 3. The pedal will click into the folded position.
- Page 16 Adjust Seat Height WARNING! • Always tighten fasteners to the correct torque to prevent serious injury or death. Bolts that are too tight can stretch and deform. Bolts that are too loose can move and fatigue. Either condition can lead to a sudden failure of the bolt and result in a crash. See Tightening Torque (p.
- Page 17 To adjust seat height: • Loosen the seatpost clamp. The open and closed positions of the seatpost clamp are shown below (open position on left, closed position on right); • Raise or lower the seat post in the seat tube; •...
- Page 18 Front and back adjustment: Loosen nuts on both sides of the seat. Make sure the clamp mechanism is clamping on the straight part of the seat rails and is not touching the curved part of the rails. Ensure that you are using the recommended torque on the clamping fastener(s).
- Page 19 Tightening Torque Spec Bottom Bracket 65 Nm Brake Caliper Mounting Bolts 7 Nm Brake Lever Clamp Bolts 7 Nm Chain Tensioner Torque 3 Nm Crank Bolts 45 Nm Disc Rotor Mounting Bolts 7 Nm Fender Mounting Bolts 6 Nm Headset Compression Cap 7 Nm Headlight Mounting Screw 7 Nm...
-
Page 20: Features
Battery pack removal should prevent unintentional activation of your Lectric eBike. • Do not make any modifications to your Lectric eBike or attach any other products that might increase the performance of your Lectric eBike. Doing so will generally reduce the service life of the system and risks damaging the drive unit and the bicycle. - Page 21 road users, thus running the risk of high personal liability costs and possibly even criminal prosecution in the event of accidents that can be attributed to manipulation of the bicycle. • Under extreme conditions, such as continuously high loads at low speed when riding up hills or carrying loads, parts of the motor can reach high temperatures.
- Page 22 Mechanical Disc Brakes Your Lectric XP is equipped with mechanical disc brakes. WARNING! To prevent serious injury or death: • ALWAYS apply right brake lever (rear wheel) before and during use of the front brake. • ALWAYS apply even pressure to both brake levers when slowing down or stopping.
- Page 23 Front and Rear Lights Your Lectric eBike comes with integrated front and rear lights. To turn lights ON: Hold plus (+) button on the display control pad for 3 seconds until the lights turn ON. To turn lights OFF: Hold plus (+) button on the display control pad for 3 seconds until the lights turn OFF.
-
Page 24: Cockpit System
Lectric eBike. When the speed falls below the maximum set speed, PAS automatically becomes available again. You can also use your Lectric eBike as a normal bicycle without assistance at any time, either by switching the Cockpit System power button OFF, or by setting PAS to 0. If the battery needs to be charged, PAS will not function. - Page 25 When the bicycle has not been used for 10 consecutive minutes, the display will automatically shut down. The PAS and throttle features will no longer work when the display is OFF. WARNING! To prevent serious injury or death: • Do not allow yourself to be distracted by the display. If you do not concentrate on the traffic around you, you risk being involved in a crash.
- Page 26 Range Estimates The range the bicycle can go on a single battery charge can vary significantly between riders, terrain, wind conditions, user input, and additional cargo weight. The following table shows estimates of potential ranges riders may expect in different conditions. All tests were performed with: •...
- Page 27 Display Functions Walk Mode, Cruise Control, and Pedal assist (PAS) Level Indicator Odometer, Trip A, Voltage, Current, Trip Timer (TM) readouts Battery level indicator bar Maximum and Average Speed Speedometer in MPH or KM/H Light On/Off Indicator Mile and kilometer indicators L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 28 Battery Level Indicator Bar The “Energy Bar” near the top of the display is your battery indicator and shows the estimated charge level remaining in your battery pack. As the battery charge depletes, the remaining marks will display the approximate remaining charge in the battery pack. The battery display will flash when there is no charge remaining.
- Page 29 Changing setting not listed in the following table may cause your bike to stop working properly. If you need the default setting values of setting not listed, contact Lectric eBikes. DO NOT ride your bicycle until the default settings have been restored.
- Page 30 Setting Function Default Explanation Backlight display brightness. Brightness The darkest level is 1 and the brightest level is 3. Distance Units 0: KM; 1: MILE. LCD Display sleep timer. The Sleep default setting will turn the display OFF after it has not been used for 10 minutes.
- Page 31 Setting Function Default Explanation When set to higher numbers, Strength the motor will come on stronger. Lower numbers will be more gentle. Odometer Hold the plus (+) button for 5 Reset seconds to reset odometer. Walk Mode 0: Walk Mode disabled Toggle 1: Walk Mode enabled L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 32 Walk Mode Electric bicycles are heavier than bicycles. To make walking the bicycle easier, your Lectric XP is equipped with Walk Mode, which can be toggled on or off in the settings menu. Walk Mode may be subject to local regulations. Check your local regulations to determine if allowed.
- Page 33 Cruise Control Cruise control on your Lectric XP works similarly to cruise control on a car. The bike will try to maintain a speed based on the position of the throttle when cruise control was activated. For example, if the throttle is twisted all the way from its resting...
-
Page 34: Preparing To Ride
• Properly secure your helmet. YOUR FIRST RIDE The acceleration of your Lectric eBike may be faster than anticipated, and may feel unusual at first. Before your first ride, you should use the lowest level of pedal assist (PAS 1) and become familiar with... - Page 35 ON, be careful not to twist the throttle or the bicycle could accelerate and cause you to crash. • Do not engage Walk Mode when riding or sitting on your Lectric eBike. Holding the minus (-) button will engage the motor up to a walking speed.
-
Page 36: Battery Pack
WARNING! Only use original Lectric eBike batteries for your eBike. Using other batteries can lead to injuries and pose a fire hazard. Lectric eBikes accepts no liability or warranty claims if other batteries are used. To prevent serious injury or death: •... - Page 37 • Always remove the battery pack before beginning work (e.g. inspection, repair, assembly, maintenance, work on the chain, etc.) on your Lectric eBike, transporting it via car or airplane, or storing it. Unintentional activation of the Lectric eBike poses a risk of injury.
- Page 38 • Only charge the battery using original Lectric eBikes chargers. When using chargers that are not made by Lectric eBikes, the risk of fire cannot be excluded. • Use the battery only in conjunction with your Lectric eBike. This is the only way in which you can protect the battery against dangerous overload.
- Page 39 The charger may get hot (>165ºF) when charging. Use caution and avoid touching the body of the charger. • To reduce risk of injury, charge only batteries of your Lectric eBike. Other types of batteries may burst, causing personal injury and damage.
- Page 40 Do not expose the charger to rain or wet conditions. If water enters a charger, there is a risk of electric shock. • Only use the original Lectric eBikes battery charger supplied with your eBike or one approved for your eBike by the manufacturer and purchased from a trusted source. Bypassing the battery charger or the use of a non-approved or counterfeit battery charger can lead to death or serious injury.
- Page 41 Use only the supplied input connection: standard AC power cord when connecting to the household electrical supply. Note: The charging process is only possible when the temperature of your Lectric eBike battery is within the permitted charging temperature range. Note: PAS is deactivated during the charging process.
- Page 42 *Point of view from bottom of bike* To install: 1. Fully insert battery pack into the bicycle frame with the key removed. The locking pin will be retracted. 2. Key position shown: UNLOCKED. Locking Pin retracted Insert the key into the battery through the hole in the bottom of the frame.
- Page 43 When unlocking and removing your battery pack from the frame, take care that it does not slide out while the bicycle is folded. If your battery impacts the ground and is damaged, discontinue use and contact Lectric eBikes immediately. Storing Charging Battery Pack Before and During Storage...
- Page 44 Storage Conditions If possible, store the battery pack in a dry, well-ventilated place. Protect it from moisture and water. Always store your Lectric eBike battery pack in a location that: • Is in a room with a smoke alarm; •...
- Page 45 Troubleshooting If you have any questions at all regarding the basic troubleshooting below, reach out to Lectric eBikes customer support by email at contact@lectricebikes.com, or call (602) 715-0907. Issue Most Common Solutions Charging indicator lights 1. Check that the cord is connected to the charger.
-
Page 46: Storing Your Lectric Ebike
Electric bicycles are generally heavier than bicycles. DISPOSAL OF YOUR LECTRIC EBIKE When your Lectric eBike is no longer usable, dispose of your eBike according to state and federal regulations. The motor, display, battery, speed sensor, accessories, and packaging should be disposed of in accordance with these regulations. -
Page 47: Troubleshooting
TROUBLESHOOTING If you have any questions at all regarding the basic troubleshooting below, reach out to Lectric eBikes customer support by email at contact@lectricebikes.com, or call (602) 715-0907. Issue Most Common Solutions Bicycle will not turn ON. 1. Charge the battery until the light on the charger turns from red to green. -
Page 48: Maintenance
Error Codes The components of your Lectric eBike are continuously monitored automatically. If a fault is detected, the corresponding error code will appear on the display. Error Code Meaning Most Common Solution Check PAS quick plug E003 PAS Sensor Fault... - Page 49 Take your bicycle to a bicycle repair shop for service. • Do not paint any components of your Lectric eBike as they may cause premature failure of the component. • Do not submerge your Lectric eBike or its components in water or use a pressure washer to clean.
- Page 50 Do not submerge your Lectric eBike or its components in water, or use a pressure washer to clean. Clean your Lectric eBike carefully with a soft, damp cloth (using only mild soap and water). Rinse with water. The electrical components on your Lectric eBike are IP 65 rated.
-
Page 51: Legal
ORIGINAL REGISTERED PURCHASER OF THIS BIKE, SUBSEQUENT OWNERS AND ALL OTHER INTENDED AND UNINTENDED USERS OF THIS BIKE, SHALL NOT BE ENTITLED TO RECOVER FROM LECTRIC eBIKES ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES. THERE IS NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. - Page 52 Lectric eBikes will replace any parts deemed to have been damaged during shipping. Shipping damage must be reported to Lectric eBikes within 14 days of shipment arrival. This applies to all products, including bikes and accessories. You will NOT be refunded as compensation for your time or efforts replacing damaged parts.
- Page 53 Lectric eBikes reserves the right to change its warranty at any time and without notice. Any action, lawsuit or other proceeding, under this warranty or otherwise related to the bike must be commenced within ninety (90) days after expiration of the one-year warranty period.
- Page 54 Under no circumstances is Lectric eBikes responsible for any damage resulting from damaged, defective, or improperly secured parts. This includes, but is not limited to, damage to personal property, personal injury, or death. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
- Page 55 This equipment should be installed and operated with a minimum distance of 5 mm between the device and the user or bystanders. This device must not be co-located or operating in conjunction with any other antenna or transmitter. L E CT R I C E B I K E S.C O M | 602.715.0907...
Need help?
Do you have a question about the XP Lite and is the answer not in the manual?
Questions and answers
Resetting the odometer
To reset the odometer on a Lectric XP Lite, hold the plus (+) button for 5 seconds.
This answer is automatically generated
how to properly install chain guard?
To properly install the chain guard on a Lectric XP Lite:
1. Remove the six screws around the perimeter of the pulley belt guard and take off the front part of the guard.
2. Use an 8 mm hex wrench to unscrew and remove the crank bolt.
3. Use a crank puller tool to remove the pulley.
4. Remove the rear part of the belt guard.
5. Place the new chain guard behind the chain stay.
6. Line up the front mounting tab with the mounting point behind the pulley and insert a 4 mm bolt.
7. Line up the rear mounting tab with the rear mounting point on the chain stay and insert another 4 mm bolt.
8. Reinstall the pulley, crank, and belt.
This process requires removing existing parts and using specific tools like a crank puller and hex wrench.
This answer is automatically generated
Serial number on XP Lite 2.0
