Ice Maker Instruction Manual
V1.0 (A)
Model: SLIM02
Thank you for choosing this Silonn product! At Silonn we strive to
provide you with the best quality products and services in the industry.
Should you have any issues, please don't hesitate to contact us at
Technical Support: 877-546-8603 Mon-Fri 8am - 8pm (CST)
Other Info: support@silonnus.com
Advertisement
Table of Contents
Related Manuals for Silonn SLIM02
Summary of Contents for Silonn SLIM02
- Page 1 V1.0 (A) Model: SLIM02 Thank you for choosing this Silonn product! At Silonn we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at Technical Support: 877-546-8603 Mon-Fri 8am - 8pm (CST) Other Info: support@silonnus.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..............SAFETY INFORMATION (FOR GROUNDING INSTRUCTIONS) PRODUCT DESCRIPTION ..............CLEANING AND MAINTAINING YOUR ICE MAKER .................. BEFORE FIRST USE ..............AFTER LONG-TERM USE ....................STORAGE OPERATION PANEL AND DISPLAY AREA ........USING YOUR ICE MAKER ................ -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PERSONAL SAFETY IS VERY IMPORTANT. To reduce the risk of fire, explosion, electrical shock, or injury when using the ice maker, follow these basic safety precautions. READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THE ICE MAKER. This is the safety alert symbol: All safety messages will follow the safety alert symbol and the word “DANGER”... - Page 4 • Do not operate the ice maker, or any other appliance with a damaged cord. Connect to properly polarized outlets only. Do not plug other electrical appliances into the same outlet. Be sure that the plug is fully inserted into the plug socket. •...
- Page 5 • Do not operate if any component, including the cord or plug, is dam- aged. • Unplug the ice maker before cleaning by hand and when not in use. • Do not immerse any part of the ice maker in water. •...
-
Page 6: Safety Information (For Grounding Instructions)
SAFETY INFORMATION (FOR GROUNDING INSTRUCTIONS) DANGER * Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged please call our customer service. 1. The ice maker must be properly grounded for your safety. The ice maker requires a standard 110-120volt, 60Hz electrical outlet. -
Page 7: Product Description
PRODUCT DESCRIPTION 1. Control Panel 2. Ice Basket 3. Evaporator 4. Water Separator Pipe 5. Top Cover 6. Cover For Water Reservoir 7. Support Seat For Water Bottle (Optional, Special For The Unit Supplied By Bottled Water) 8. Hot Air Outlet 9. -
Page 8: Cleaning And Maintaining Your Ice Maker
CLEANING AND MAINTAINING YOUR ICE MAKER BEFORE FIRST USE Before using the ice maker, it is highly recommended to clean it thor- oughly. 1. Remove the exterior and interior packaging. Check that the ice basket and ice scoop are included. If any parts are missing, please contact our customer service . -
Page 9: Storage
How to drain out the water from the water tank and water reservoir completely？ Because the water in the water reservoir is blocking to drain port by the draining plug, if you want to drain away all the water, please plug in the ice maker and but don’t turn on it, then remove the water draining cap at the bottom. -
Page 10: Operation Panel And Display Area
OPERATION PANEL AND DISPLAY AREA OPERATION PANEL AND DISPLAY AREA A. TIMER/CLEAN button Short press this button once to enter the timer setting program; Long press this button for more than 5 seconds to start the self-cleaning function. B. ON/OFF button When the ice maker is off, press this button to turn on the ice maker;... -
Page 11: Using Your Ice Maker
USING YOUR ICE MAKER PREPARING FOR USE 1. Find a location for the ice maker that is protected from direct sunlight and other sources of heat (i.e.: stove, furnace, radiator). Place the ice maker on a leveled surface. Maker sure that there is at least 6 inches of space between the back and sides of your ice maker and the wall. - Page 12 2. Turn On The Ice Maker ①. Plug the ice maker, the electric power symbol < > will start to flash, and the ambient temperature will display at the top left corner of the screen window. For example, < > digits means the 80 Fahrenheit ambient.
- Page 13 • When the < > symbol lights on, the ice maker will turn off by itself and it will turn on by itself if you take the ice cubes away from the water tank. 3. How To Set The Thickness Of The Ice Cubes Press the “+”...
- Page 14 Please Note: • If the lower left corner displays 5H in standby state, it means that the ice maker will automatically turn on after 5 hours; • If the lower left corner displays 5H in the ice-making process, it means that the ice maker will automatically turn off...
-
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES SOLUTION Turn off the unit and add water to <FULL> level, then re-start < > is on Lack of water the unit. Ice cubes overload- Remove the ice cube in the < > is on ing in the basket basket The water Need the technical service... -
Page 16: Technical Parameters & Circuit Diagram
TECHNICAL PARAMETERS & CIRCUIT DIAGRAM TECHNICAL PARAMETERS Model SLIM02 Protection Type Power 115V/60Hz Ice-Making Current 2.2A Ice-Harvest Current 2.5A R290 1.13Oz/32g Refrigerant Design Pressure High Side 260Psig Low Side 88Psig Net Weight 9.5kg Enclosure Stainless CIRCUIT DIAGRAM ELECTRICAL DIAGRAM Solenoid Valve...
