  • Page 1 Technical Reference Manual Hardware and BIOS HP Vectra XW...
  • Page 2 Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Conventions

    Preface This manual is a technical reference and BIOS document for engineers and technicians providing system level support. It is assumed that the reader possesses a detailed understanding of AT-compatible microprocessor functions and digital addressing techniques. Technical information that is readily available from other sources, such as manufacturer’s proprietary publications, has not been reproduced.

  • Page 4: Bibliography

    HP Vectra XW Familiarization Guide (D4514-90901). HP Network Administrator’s Guide (online). HP Vectra Accessories Service Handbook - 6th edition (5964-8495). HP Vectra PC Service Handbook (Volume 1) - 11th edition (to be announced). XW/XU Drivers and Documentation CD-ROM (5011-3816). HP Support Assistant CD-ROM (by subscription).

  • Page 5: Table Of Contents

    Contents Preface ..........Conventions .
  • Page 6 3 Interface Boards and Mass-Storage Drives HP Integrated OpenGL Interface Board ..... . . 22 Drivers........... .
  • Page 7 Contents HP I/O Port Map (I/O Addresses Used by the System)....5 Power-On Self-Test and Error Messages Order in Which the Tests are Performed ..... . 44 Error codes .
  • Page 8 Contents viii...

  • Page 9: System Overview

    System Overview This manual describes the HP Vectra XW, and provides detailed system specifications. This chapter introduces the external features, and lists the specifications and characteristic data of the system. It also summarizes the documentation which is available.

  • Page 10: Package

    1 System Overview Package Package Status Panel The status panel has the following features: a power on/off button with integrated on/error status light a press-and-hold RESET button a hard disk activity light. Power on/off button Disk activity light IDE 8 CD-ROM Volume control Headphones Microphone...

  • Page 11: Specifications And Characteristic Data

    Keyboard MIDI Stereo-in (Line-in) Stereo-out (Line-out) Parallel port External SCSI HP PCI Integrated 10/100 BT Interface Display connector for 3D AccelGraphics board Specifications and Characteristic Data Physical Characteristics Weight 33 lbs Dimensions 16.0 inches (D) by 8.3 inches (W) by 16.3 inches (H) 405 mm (D) by 210 mm (W) by 415 mm (H) Footprint 0.92 sq ft...

  • Page 12: Electrical Specification

    1 System Overview Specifications and Characteristic Data Electrical Specification Limit for the Power Parameter Supply Input voltage 100-127 Input current (max) Input power (max) 280 W Input power (typical) < 44 W < 29 W < 24 W < 3 W Input frequency 47 Hz to 63 Hz Heat dissipation...

  • Page 13: Environmental Specification

    Documentation The table below summarizes the documentation for the HP Vectra XW. Only selected publications are available on paper. Most are available as printable files from the HP division support servers, and as viewable files (which can also be printed) on the HP Support Assistant CD-ROM.

  • Page 14: Where To Find The Information

    1 System Overview Documentation Where to Find the Information The following table summarizes the availability of information within the HP Vectra XW documentation set. User Guide Product features Key features Product model numbers Connecting cables and Keyboard, mouse, turning on...
  • Page 15 System Board The next chapter describes the graphics, disk, audio and network devices which are supplied with the computer. This chapter describes the components of the system board, taking in turn the components of the Processor-Local Bus, the Peripheral Component Interconnect (PCI) bus and the Industry Standard Architecture (ISA) bus.

  • Page 16: System Board

    2 System Board System Board System Board Architectural View The following block diagram gives an architectural view (for frequencies, see the table on page 11).
  • Page 17 Core I-cache D-cache Front-side bus Back-side bus (128 bit, 200 MHz) PL/PCI Fast-20 bridge SCSI-2 PCI/ISA Ultra I/O bridge controller Cache 18 bit Mem/PL bridge Processor-Local bus (64 bit, 66 MHz) Graphics master controller Little Ben Audio ASIC controller 2 System Board System Board Memory modules 18 bit...

  • Page 18: Devices On The Processor-Local Bus

    2 System Board Devices on the Processor-Local Bus Devices on the Processor-Local Bus Intel Pentium Pro (P6) Microprocessor Each processor is packaged in a 387-way pin-grid-array (PGA), which is seated on the system board in a P6T overdrive zero-insertion-force (ZIF) socket 8.

  • Page 19: Chip-Set

    The two processors must be operating at the same bus speed and the same processor speed, with the switch settings set accordingly for the slower of the two. In fact, only 200 MHz processors are presently supported by HP. The two processors should have the same amount of level-two (L2) cache memory.

  • Page 20: Main Memory

    2 System Board Devices on the Processor-Local Bus Main Memory There are eight main memory module sockets, arranged in four banks (A to D). One or two banks are already occupied by the double interline memory modules (DIMMs) that contain the 64 MB or 128 MB of memory that is supplied with the computer (depending on the model).
  • Page 21 2 System Board Devices on the Processor-Local Bus Chip-Set Chips that are involved in Memory Access The Mem/PL bridge chip (OMC-DP, Intel 82452KX) interfaces between the Processor-Local (PL) bus, whose datapath is 64-bits wide, and the Intel proprietary memory bus, whose datapath is 72-bits wide. During a memory- write operation, the chip generates 8 ECC parity bits.

  • Page 22: Devices On The Pci Bus

    2 System Board Devices on the PCI Bus Devices on the PCI Bus PCI Device Device Number Mem/PL bridge (OMC-DP, 82452KX) PL/PCI bridge (OPB, 82454KX) PCI/ISA bridge (SIO-A, 82379AB) IDE controller (CMD646) SCSI controller (AIC-7880) PCI slot #1 PCI slot #2 PCI slot #3 PCI slot #4 The distribution of the interrupt lines is described more fully on page 41.
  • Page 23 automatically, the fastest configuration that it supports. However, in general, the primary channel cable is recommended for hard disk drives, and the secondary channel cable for CD-ROM drives. Indeed, if a CD-ROM is placed on the same channel as a hard disk drive, problems could be experienced activating the 32-bit access drivers.

  • Page 24: Devices On The Isa Bus

    It can operate the four modes: Standard mode (PC/XT, PC/AT, and PS/2 compatible). Bidirectional mode (PC/XT, PC/AT, and PS/2 compatible). Enhanced mode (enhanced parallel port, EPP, compatible). High speed mode (MS/HP extended capabilities port, ECP, compatible). ISA Device Index 370h...

  • Page 25: Audio Controller

    The integrated flexible drive controller (FDC) supports any combination of two from the following: tape drives, 3.5-inch flexible disk drives, 5.25-inch flexible disk drives. It is software and register compatible with the 82077AA, and 100% IBM compatible. It has an A and B drive-swapping capability and a non-burst DMA option.

  • Page 26: System Rom

    Updating the System ROM The System ROM can be updated with the latest BIOS. This can be ordered from HP or downloaded from one of HP’s online services. (For more information on HP’s electronic services, refer to the Hewlett-Packard Support and Information Services chapter in the User’s Guide that was supplied with the computer.)

  • Page 27: Little Ben

    If it is not the current version of the BIOS, as obtained from the HP Electronic Support services, the System ROM should be flashed with the new version, as described on the previous page. The computer should then be re-run to see if this has cleared the problem.

  • Page 28: Other Pci And Isa Accessory Devices Under Plug And Play

    2 System Board Devices on the ISA Bus • security protection (access, flash and anti-virus protection) For 128, 256 or 512 KB Flash EEPROMs. For the Ultra I/O space: the Serial EEPROM, serial ports, parallel port and mass storage drives (disable write on Flexible Disk Drive, disable boot on any drive, disable use of any embedded drive) •...

  • Page 29: Interface Boards And Mass-Storage Drives

    Interface Boards and Mass-Storage Drives This chapter describes the video, mass storage, audio and network devices which are supplied with the computer. It also summarizes the pin connec- tions on internal and external connectors.

  • Page 30: Hp Integrated Opengl Interface Board

    OpenGL is the current standard 3D application programming interface (API). It is a graphics language for describing three-dimensional objects. The HP Integrated OpenGL Interface Board has a processor that executes OpenGL 3D graphics instructions autonomously of the main processor. It...

  • Page 31: Drivers

    VGA mode, and hardware 3D acceleration will not be usable. The OpenGL drivers must be loaded, when installing the Windows NT 3.51 WS operating system, from the HP Vectra XW/XU Drivers and Documentation CD-ROM that was supplied with the computer. These...

  • Page 32: Video Memory

    3 Interface Boards and Mass-Storage Drives HP Integrated OpenGL Interface Board Video Memory There is 8 MB of video RAM (VRAM) consisting of 4 chips on the back of the board, and 16 chips on the front of the board. This is used for the frame...

  • Page 33: Hp Pci Integrated 10/100 Bt Interface Board

    HP PCI Integrated 10/100 BT Interface Board The HP PCI Integrated 10/100 BT Interface Board is I/O mapped, on the PCI bus, and has bus-master capability. It has a single RJ-45 unshielded- twisted-pair (UTP) connector, which supports two network standards: •...

  • Page 34: Board Layout

    3 Interface Boards and Mass-Storage Drives HP PCI Integrated 10/100 BT Interface Board Board Layout The analog MLT3 encoder chip is responsible for shaping the output signal to comply with the specification. The physical transceiver chip (PHY) converts analog signals to digital, sending its signals to the 82557, and controlling three status lights.

  • Page 35: Configuring The Board

    3 Interface Boards and Mass-Storage Drives HP PCI Integrated 10/100 BT Interface Board Configuring the Board The network board is able to ‘auto-negotiate’. If the hub also has this capability, the two are able to determine, automatically, the best mode at which to communicate (full or half duplex, 10 or 100 Mbits per second).

  • Page 36: Mass-Storage Drives

    The SCSI and IDE controllers are described on page 14. The flexible disk controller is described on page 17. Hard Disk Drives A 3.5-inch hard disk drive is supplied on an internal shelf in some models. HP product number Manufacturer Product name Interface...

  • Page 37: Connectors And Sockets

    Connectors and Sockets IDE Hard Disk Drive Data Connector Signal Reset# Ground HD10 HD11 HD12 HD13 HD14 HD15 Ground orientation key DMARQ Ground DIOW# Ground DIOR# Ground IORDY SPSYNC:CSEL DMACK# Ground INTRQ IOCS16# PDIAG# CS0# CS1# DASP# Ground Ultra SCSI Connector Signal 1-11 Ground Ground...
  • Page 38 3 Interface Boards and Mass-Storage Drives Connectors and Sockets 16-bit ISA Connector (8-bit ISA uses the A and B connectors) Signal Ground CHCHK# RESDRV +5 V IRQ9 -5 V DRQ2 -12 V NOWS# + 12 V Ground CHRDY SMWTC# AENx SMRDC# SA19 IOWC#...
  • Page 39 Signal Signal -12 V TRST# +12 V Ground +5 V +5 V +5 V INTA# INTB# INTC# INTD# +5 V Ground reserved reserved PRSNT# +3.3 V reserved orientation key orientation key reserved reserved Ground RESET# +3.3 V Ground GNT# REQ# Ground +3.3 V reserved...

  • Page 40: Vga Connector

    3 Interface Boards and Mass-Storage Drives Connectors and Sockets Power Supply Connector for System Board Socket Pin Layouts RJ-45 UTP Connector Keyboard and Mouse Connector Serial Port Connector Signal Signal PwrGood Remote_On VSTDBY -5 V supply +5 V supply -12 V supply +5 V supply +12 V supply +5 V supply...

  • Page 41: Hp Bios

    HP BIOS The Setup program and BIOS are summarized in the two sections of this chapter. The POST routines are described in the next chapter.

  • Page 42: Setup Program

    4 HP BIOS Setup Program Setup Program You can interrupt the POST to run the Setup program by pressing message appears on the initial “Vectra” logo screen. F2=Setup A complete list of fields, their meanings, and the options which are available, can be found in the User’s Guide that was supplied with the computer.

  • Page 43: Bios Addresses

    BIOS Addresses This section provides a summary of the main features of the HP system BIOS. This is software that provides an interface between the computer hardware and the operating system. The procedure for updating the System ROM firmware is described on page There is BIOS support for ISA “Plug and Play”...

  • Page 44: Product Identification

    Note that if you use DEBUG to look at the bytes, the numbers will be reversed (0106). Description System number for HP Vectra XW and XU 6/xxx Extended identification byte (14h = Pentium Pro) High processor clock frequency Low processor clock frequency HP Vectra computer ID (ASCII “FF”)
  • Page 45 0F000:00FFh = Week of the ROM BIOS release in Binary Coded Decimal (BCD) Length = one byte Encoding is as follows: where nn is the week in which the BIOS ROMs were released, expressed in BCD. The range is 01h to 52h. 4 HP BIOS BIOS Addresses...

  • Page 46: Hp I/O Port Map (I/O Addresses Used By The System)

    4 HP BIOS BIOS Addresses HP I/O Port Map (I/O Addresses Used by the System Peripheral devices, accessory devices and system controllers are accessed via the system I/O space, which is not located in system memory space. The 64 KB of addressable I/O space comprises 8-bit and 16-bit registers (called I/O ports) located in the various system components.
  • Page 47 03F8h - 03FFh Serial port 1 0678h - 067Bh Parallel port 2 if ECP mode is selected 0778h - 077Bh Parallel port 1 if ECP mode is selected 0CF8h - 0CFFh Configuration registers for PCI devices 4 HP BIOS BIOS Addresses...
  • Page 48 4 HP BIOS BIOS Addresses DMA Channel Controllers Only “I/O-to-memory” and “memory-to-I/O” transfers are allowed. “I/O-to-I/O” and “memory-to-memory” transfers are disallowed by the hardware configuration. The system controller supports seven DMA channels, each with a page register used to extend the addressing range of the channel to 16 MB. The following table summarizes how the DMA channels are allocated.
  • Page 49 Serial Port 2, Serial Port 4, or ISA accessory board Serial Port 1, Serial Port 3, or ISA accessory board SoundBlaster 1, Parallel Port 2, or ISA accessory board Flexible Disk Controller SoundBlaster 2, Parallel Port 1, or ISA accessory board 4 HP BIOS BIOS Addresses...
  • Page 50 4 HP BIOS BIOS Addresses All PCI devices with interrupt transfer support will use and share INTA#. A PCI device supporting multiple functionalities may use several INT lines. These devices will require more than one system interrupt request line. The PCI interrupt lines A, B, C and D are spread across the four inputs of the interrupt router (which is part of the SIO-A south bridge).

  • Page 51: Power-On Self-Test And Error Messages

    Power-On Self-Test and Error Messages This chapter describes the Power-On Self-Test (POST) routines, which are contained in the computer’s ROM BIOS, the error messages which can result, and the suggestions for corrective action.

  • Page 52: Order In Which The Tests Are Performed

    To see the tests performed during the POST, press when the initial HP “Vectra” logo appears, and the display will switch to text mode. In this mode, a summary configuration screen will be displayed at the end of the POST. Pressing the PAUSE/BREAK key at any time will allow you to inspect the screen contents.
  • Page 53 5 Power-On Self-Test and Error Messages Order in Which the Tests are Performed POST Test Description System BIOS Tests Tests the LEDs on the control panel. LED Test Calculates an 8-bit check-sum. Test failure causes the boot process to System (BIOS) ROM Test abort.
  • Page 54 Mouse Test microprocessor and for stuck mouse buttons. Test failure causes an error code to display. If the HP PCI Integrated 10/100 Interface is present, invokes a built-in self- LAN Test test. Test failure causes an error code to display.
  • Page 55 Tests of Flexible Disk Drive A Tests for proper operation of the flexible disk controller. Test failure Flexible Disk Controller causes an error code to display. Subsystem Test Checks for proper operation of the numeric coprocessor part of the Internal Numeric Coprocessor processor.

  • Page 56: Error Codes

    This SCA code can then be found in the list that is given in the next section of this chapter. Not all of these error codes can be generated by the HP Vectra XW. However, the complete list is given here, to allow for possible future changes to the models within this product line.
  • Page 57 0130 The system date and time has not been entered or has been lost or corrupted. 0240 The system configuration has been lost. 0241, 0280 The system configuration has been lost or corrupted. 0250 The Setup information does not match the hardware installed in the computer.
  • Page 58 5 Power-On Self-Test and Error Messages Error codes 0506 The built-in serial port's address is used by a serial port on an accessory board. 0507 The system board's serial port at address 3F8h has failed. 0508 The system board's serial port at address 2F8h has failed. 0509 The system board's serial port at address 3E8h has failed.
  • Page 59 0801 The boot ROM is enabled in Setup but a boot ROM is not present in the computer. 0811 The Integrated Ethernet Interface cannot be found at the I/O base address specified in Setup. 0812 The MAC address of the Integrated LAN Interface is corrupted. 0813 The Integrated Ethernet Interface registers cannot be initialized.
  • Page 60 5 Power-On Self-Test and Error Messages Error codes 20xA Two different sized memory modules are in the same bank. 201B, 202B, 204B, 208B A memory error occurred during your last session. 201C, 202C, 204C, 208C Several memory errors occurred during your last session. 2110..212F, 2210..221F The system board's DMA controller has failed.
  • Page 61 8400 The hard disk drive's boot sector has been corrupted. 9000..900F Flexible disk drive A, its cable, or the controller has failed. 9010 The built-in flexible disk controller's address is used by a flexible disk controller on an accessory board. 9100..910F The second flexible disk drive, its cable, or the controller has failed.

  • Page 62: Suggestions For Corrective Action

    5 Power-On Self-Test and Error Messages Suggestions for Corrective Action Suggestions for Corrective Action An exhaustive list of the suggestions for corrective action (SCA) is given here, to accompany the list of the error codes that is given in the previous section.
  • Page 63 SCA05 1 Run Setup to view your configuration and correct any obvious errors. 2 If this fails to correct the problem, ensure that your hardware (accessory boards, disk drives, switches, and jumpers) is configured correctly (refer to their manuals). In particular, check that the CONFG switch on the sys- tem board is set to Off.
  • Page 64 5 Power-On Self-Test and Error Messages Suggestions for Corrective Action SCA11 1 Re-start your computer. Do not press a key during the power-on tests. 2 If the problem persists, check visually if a key is stuck on the keyboard and try to loosen it gently.
  • Page 65 (in which case it was not identified on the POST screen). 3 Check cables are firmly plugged, and if the problem persists, contact your HP representative. SCA19 • Either disable the disk controller on the accessory board or run Setup to disable the built-in disk controller.
  • Page 66 5 Power-On Self-Test and Error Messages Suggestions for Corrective Action SCA26 • Your infra red interface may need to be replaced. Contact your service representative. As a temporary solution, if you do not need the defective infra red port, run Setup to disable it. SCA27 1 Run Setup to enter the serial number of your system.
  • Page 67 SCA34 • Re-configure your accessory board. Check your manual and Setup to see which resources are used by the internal devices. SCA35 • Replace the memory modules as follows: Error code Replace module in: SCA36 • Replace the memory modules as follows: Error code Replace module in: SCA37 •...
  • Page 68 • 32 MB single-density DIMMs (interleave 32) cannot be used with any • 16 MB single-density DIMMs, 32 MB double-density DIMMs • You need to replace some of your DIMMs. For details, please run the "HP Vectra XU6/VT6 Memory Configuration Utility", which is available from HP support. SCA40 •...

  • Page 69: Beep Codes

    Beep Codes If a terminal error occurs during POST, the system issues a beep code before attempting to display the error. Beep codes are useful for identifying the error when the system is unable to display the error message. Beep Boot Beep Pattern Code...

  • Page 70: Error Message Summary

    5 Power-On Self-Test and Error Messages Error Message Summary Error Message Summary Message Operating system not found Missing operating system Failure fixed disk (preceded by a 30” time-out) Diskette Drive A (or B) error System battery is dead Keyboard error Resource Allocation Conflict -PCI device 0079 on system board Video Plug and Play interrupted or...
