- Page 1 Extractor hood [en] User manual and installation instructions D49ML54X1,D49ML54N1B,D46ML54N1B,D46ML54X1...
-
Page 2: Table Of Contents
en Safety ¡ In private households and in enclosed Table of contents spaces in a domestic environment. ¡ Up to an altitude of max. 2000 m above sea level. USER MANUAL Do not use the appliance: Safety .............. 2 ¡ With an external timer. Avoiding material damage........ -
Page 3: Safety
Safety en Toxic gases from the flue or the extraction ▶ Never extinguish burning oil or fat with wa- shaft are sucked back into the living space. ter. Switch off the cooking zone. Extinguish flames carefully using a lid, fire blanket or something similar. -
Page 4: Avoiding Material Damage
en Avoiding material damage ▶ If the power cord of this appliance is dam- WARNING ‒ Risk of electric shock! aged, it must be replaced by the manufac- If the appliance or the power cord is dam- turer, the manufacturer's Customer Service aged, this is dangerous. or a similarly qualified person in order to ▶... -
Page 5: Operating Modes
Operating modes en Switch the appliance off when you are not using it. Clean or replace the filters at regular intervals. ¡ The appliance does not consume any energy. ¡ The effectiveness of the appliance is increased. Switch off the lighting if you no longer require it. Put the cooking lid on. -
Page 6: Familiarising Yourself With Your Appliance
en Familiarising yourself with your appliance 5 Familiarising yourself with your appliance 5.1 Controls The controls are used to configure all functions of your appliance and to obtain information about the operat- ing status. Switching the appliance on or off Increase the fan setting Switching noise reduction on or off Switching on intensive mode Decreasing the fan setting/... -
Page 7: Cleaning And Servicing
Cleaning and servicing en 6.12 Switching on the audible signal 6.14 Resetting the saturation indicator Requirement: The appliance is switched off. After cleaning the grease filter or after changing the odour filter, the saturation indicator can be reset. Press and hold at the same time for ap- ▶... -
Page 8: Troubleshooting
en Troubleshooting Observe the information regarding the cleaning ATTENTION! Falling grease filters may damage the hob below. agents. Grip below the grease filter with one hand. → "Cleaning products", Page 7 ▶ Place the grease filters loosely into the dishwasher. Note: Remove the grease filter in the filter pull-out first, then remove the grease filters in the appliance. -
Page 9: Customer Service
Customer Service en 8.1 Malfunctions Fault Cause and troubleshooting The appliance is not working. The mains plug of the power cord is not plugged in. Connect the appliance to the power supply. ▶ The circuit breaker is faulty. Check the circuit breaker in the fuse box. ▶... -
Page 10: Disposal
en Disposal Accessories vary from one appliance to another. When 10.1 Other accessories purchasing accessories, always quote the exact You can purchase other accessories from our after- product number (E no.) of your appliance. sales service, specialist retailers or online. You can find out which accessories are available for You will find a comprehensive range of products for your appliance in our online shop or from our after- your appliance in our brochures and online:... - Page 11 Installation instructions en Toxic gases from the flue or the extraction ▶ Observe the specifications for your cooking shaft are sucked back into the living space. appliance. If gas and electric hobs are be- ing operated together, the largest specified clearance applies. ▶...
- Page 12 en Installation instructions Flat ducts Incorrect repairs are dangerous. Use flat ducts with an inner cross-section that corres- ▶ Repairs to the appliance should only be ponds to the diameter of the round pipes: carried out by trained specialist staff. ¡ Diameter of 150 mm corresponds to ap- ▶...
- Page 13 Installation instructions en 19 mm wall thickness: Open up the spacers on 12.8 Installation both of the mounting parts. Checking the unit Check whether the fitted unit is level and has suffi- cient load-bearing capacity. The max. weight of the appliance is 18 kg. Ensure that the fitted unit is heat-resistant up to 90 °C.
- Page 14 en Installation instructions Installing the appliance Note: You can conceal the housing of the extractor hood Fit the appliance in the cabinet , lock the fastening within the upper cabinet. In doing so, observe the bolts and attach the protective caps ...
- Page 15 Installation instructions en Push in the fastening bolts using a flat-blade screw- driver and rotate by 90° until the fastening bolts un- clip. Push in and turn the fastening bolts gently with your fingers until the fastening bolts springs out of the housing.
- Page 16 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom *9001530500* 9001530500 Constructa-Neff Vertriebs-GmbH Carl-Wery-Straße 34 001222 81739 München GERMANY...
