Page 1
Operating Instructions Analog Input board AV-HS04M2 Model No. Before operating this product, please read the instructions carefully and save this manual for future use. 01.AV-HS04M2̲English.indd 1 01.AV-HS04M2̲English.indd 1 2007/10/01 18:31:57 2007/10/01 18:31:57...
TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD AND ANNOYING INTERFERENCE, USE THE RECOMMENDED ACCESSORIES ONLY. CAUTION: TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, REFER CHANGES OF SWITCH SETTINGS INSIDE THE UNIT TO QUALIFIED SERVICE PERSONNEL. indicates safety information. 1 (E) 01.AV-HS04M2̲English.indd Sec1:1 01.AV-HS04M2̲English.indd Sec1:1 2007/10/01 18:32:05 2007/10/01 18:32:05...
Page 3
To assure continued FCC emission limit compliance, the user must use only shielded interface cables when connecting to external units. Also, any unauthorized changes or modifications to this equipment could void the user’s authority to operate it. indicates safety information. 2 (E) 01.AV-HS04M2̲English.indd Sec1:2 01.AV-HS04M2̲English.indd Sec1:2 2007/10/01 18:32:05 2007/10/01 18:32:05...
Page 5
Information on Disposal in other Countries outside the European Union This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. 4 (E) 01.AV-HS04M2̲English.indd Sec1:4 01.AV-HS04M2̲English.indd Sec1:4 2007/10/01 18:32:05 2007/10/01 18:32:05...
An up-converter function is also incorporated in each of the two analog input lines for converting SD format signals into HD format signals. Accessory Operating instructions ....1 5 (E) 01.AV-HS04M2̲English.indd Sec1:5 01.AV-HS04M2̲English.indd Sec1:5 2007/10/01 18:32:06 2007/10/01 18:32:06...
When the product is to be discarded When the product is to be discarded at the end of its service life, ask a specialized contractor to dispose of it properly in order to protect the environment. 6 (E) 01.AV-HS04M2̲English.indd Sec1:6 01.AV-HS04M2̲English.indd Sec1:6 2007/10/01 18:32:06 2007/10/01 18:32:06...
Turn off the power of the AV-HS400N/E, and unplug the power cord. Loosen the two screws of SLOT1 or SLOT2 on the input side at the rear of the AV- HS400N/E, and remove the blank panel. SLOT2 SLOT1 Blank panel Screw Screw 8 (E) 01.AV-HS04M2̲English.indd Sec1:8 01.AV-HS04M2̲English.indd Sec1:8 2007/10/01 18:32:06 2007/10/01 18:32:06...
Page 10
Insert it all the way in. Take care not to use force to insert the board because the connectors may be damaged in the process. Attach the board using the two screws. Screw Screw After connecting the necessary cables, plug in the power cord, and turn on the power. 9 (E) 01.AV-HS04M2̲English.indd Sec1:9 01.AV-HS04M2̲English.indd Sec1:9 2007/10/01 18:32:08 2007/10/01 18:32:08...
Page 11
AV-HS400N/E. 4-1. Setting the SDI input signals and analog input signals 4-2. Setting the up-converter 5-2. Setting the crosspoints Removal procedure Remove this board by following the procedures for mounting it in reverse. 10 (E) 01.AV-HS04M2̲English.indd Sec1:10 01.AV-HS04M2̲English.indd Sec1:10 2007/10/01 18:32:09 2007/10/01 18:32:09...
Make the connection with this board while the power is off. For details on connecting individual devices, refer to the respective operating instructions. For details on operating individual devices, refer to the respective operating instructions. 11 (E) 01.AV-HS04M2̲English.indd Sec1:11 01.AV-HS04M2̲English.indd Sec1:11 2007/10/01 18:32:09 2007/10/01 18:32:09...
Power supply DC 12 V (supplied from the AV-HS400N/E) Power consumption ?? W Dimensions 6˝ × 1-1/16˝ × 5-2/16˝ (152.5 × 27 × 130 mm) (W H D) Weight 0.4 lbs. (0.2 kg) 13 (E) 01.AV-HS04M2̲English.indd Sec1:13 01.AV-HS04M2̲English.indd Sec1:13 2007/10/01 18:32:11 2007/10/01 18:32:11...
