GUILD
18V Lithium-Ion Drill Driver
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your Guild drill driver
These instructions contain important information that will help you get the best from your Guild
drill driver, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
UK/Ireland 0333 3201989
Help@guildpowertools.co.uk
CDT118GL
Advertisement
Table of Contents
Related Manuals for Guild CDT118GL
Summary of Contents for Guild CDT118GL
- Page 1 Important - Please read these instructions fully before operating or maintaining your Guild drill driver These instructions contain important information that will help you get the best from your Guild drill driver, ensuring it remains safe to operate. If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989...
-
Page 2: Table Of Contents
Contents Safety Information.....................3 In The Box........................8 Accessories.......................8 Operating Instructions....................9 Trouble Shooting......................13 Maintenance......................14 Technical Data......................14 Environmental Protection..................16 Guarantee........................16 Customer Helpline 0333 3201989... -
Page 3: Safety Information
Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembling and operating the drill driver. To reduce the risk of injury, Please read the instruction manual Warning Wear ear protection Wear eye protection... - Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
- Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach.
- Page 6 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
- Page 7 Safety Information Important - Please read these instructions fully before starting assembly Product safety p) Keep battery pack out of the reach of children. q) Retain the original product literature for future reference. r) Remove the battery from the equipment when not in use. s) Dispose of properly.
-
Page 8: In The Box
In The Box Parts Battery pack release button Keyless chuck Belt clip Torque adjustment ring On/off switch Forward/Reverse rotation control Sight light Soft grip handle Battery pack Accessories Li-ion battery pack 3-5hr Charger Double ended bit Belt clip Customer Helpline 0333 3201989... -
Page 9: Operating Instructions
Operating Instructions NOTE: Before using the tool, read the instruction book carefully. Intended Use This tool is intended for driving in and loosening screws as well as for drilling in wood, metal and plastic. 1. CHARGING PROCEDURE BEFORE PUTTING INTO OPERATION CHARGING THE TOOL OR BATTERY PACK (SEE FIG A) NOTE: a) Do not use any charger other than that specifically provided for use with the... - Page 10 Operating Instructions 2. INSTALLING AND REMOVING THE BATTERY PACK (SEE FIG B) a) TO REMOVE THE BATTERY PACK Press the Battery Pack Release Button (8) firmly first and then slide the Battery Pack out from your tool. b) TO INSTALL THE BATTERY PACK Slide the fully charged Battery Pack onto the tool with sufficient force until it clicks into position.
- Page 11 Operating Instructions the front chuck section in the opposite directions. Your drill bit is now clamped in the chuck. 7. TORQUE ADJUSTMENT (SEE FIG. E) (Screw driving force of your drill driver) The torque is adjusted by rotating the torque adjustment ring. The torque is greater when the torque adjustment ring is set on a higher setting.
- Page 12 Operating Instructions If you want to activate the drill function (For drilling metal wood or plastic), turn the torque adjustment ring on the drill position. Tungsten carbide drill bits should always be used for concrete and masonry. When drilling in metal, only use HSS drill bits in good condition. Always use a magnetic bit holder (not included) when using short screwdriver bits.
-
Page 13: Trouble Shooting
Trouble Shooting 1. WHY DOES THE DRILL NOT TURN ON WHEN YOU PRESS THE SWITCH? The forward/reverse rotation control, which is on top of the trigger, is positioned in the lock function. Unlock the forward/reverse rotation control by putting it into the required rotation position. -
Page 14: Maintenance
Maintenance Your tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. - Page 15 Technical Data Vibration Information Vibration total values (triax vector sum) determined according to EN 60745: Vibration emission value a = 2,0 m/s² h, ID Screw driving without impact Uncertainty K = 1.5 m/s² Vibration emission value a = 2,7 m/s² h, D Drilling into metal Uncertainty K = 1.5 m/s²...
-
Page 16: Environmental Protection
Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. Guarantee This product is selected for DOMESTIC USE ONLY and not for business use. This product is guaranteed against manufacturing defects for a period of 24 months.
