Precautions Please read the following operating precautions before use. Yamaha will not be held responsible for any damage and/or injury caused by not following the cautions below. 1. To assure the finest performance, please read this 1. Do not operate this unit upside down. It may overheat, manual carefully.
Page 3
Precautions • VOLTAGE SELECTOR (For China, Korea, Asia and General models) The voltage selector switch on the rear panel of this unit must be set to your local main voltage BE- FORE plugging this unit into the AC main supply. Voltages are 110-120/220-240 V AC, 50/60 Hz.
Attaching the speaker stands.......2 Troubleshooting ..........5 Specifications............6 Package contents Thank you for choosing the Yamaha NS-P285 5.1CH Speaker Package. Make sure the package contains the following items. ■ Subwoofer (NS-SW280 x1) The Subwoofer features a built-in power amplifier and utilizes Advanced Yamaha Active Servo Technology to provide high-quality sub-bass sound that adds real “punch”...
(5-7/8") Warnings • NS-B285 speaker weighs 0.45 kg (1 lbs.) and NS-C385 speaker weights 1 kg (2.2 lbs.). Do not mount the speakers on thin plywood or on a wall with a soft surface material. Otherwise, the screws may pull out of the surface and the speakers may fall, possibly damaging the speakers or causing personal injury.
Connecting the speakers Caution: Make sure the power cables for the subwoofer and your other AV components are disconnected from the AC wall outlets before making any connections. Connection diagram Surround speakers Center speaker Right Left SPEAKERS FRONT SURROUND CENTER Amplifier ANTENNA HDMI OUT...
(or “S”) for all of the NS-P285 speakers. Release the tab so that it closes securely on the If you’re connecting the subwoofer to a Yamaha DSP bare wire, not the insulation. amplifier or AV receiver, connect to its SUBWOOFER or LOW PASS output.
If this product doesn’t work as expected, look for a possible cause below. If the issue you are experiencing is not listed, or you cannot resolve it after reading through these instructions, disconnect the power cable and contact an authorized Yamaha dealer or service center. Issue...
(without stand) 90 x 120 x 123 mm (3-1/2" x 4-3/4" x 4-7/8") (with stand) NS-C385 .... 220 x 90 x 109 mm (8-5/8" x 3-1/2" x 4-1/4") Weight NS-B285......... 0.45 kg (1 lbs.)(without stand) NS-C385............1.0 kg (2.2 lbs.)
Page 10
Precauciones Lea las siguientes precauciones de funcionamiento antes de iniciar el uso del aparato. Yamaha no se responsabilizará de cualquier daño o lesión causada por no seguir las precauciones que aparecen a continuación. 1. Para asegurar el mejor rendimiento posible, lea con aten- 4.
Page 11
Solucionar problemas ........5 Especificaciones ..........6 Contenido del paquete Gracias por elegir el sistema de altavoces Yamaha NS-P285 5.1CH. Compruebe que el paquete contiene los siguientes elementos. ■ Subwoofer (NS-SW280 x1) El subwoofer integra un amplificador de potencia y utiliza la Advanced Yamaha Active Servo Technology para proporcionar un sonido subgrave de alta calidad que añade un “pinchado”...
150 mm Advertencias • El altavoz NS-B285 pesa 0,45 kg y el altavoz NS-C385 pesa 1 kg. No instale los altavoces en contrachapados de madera fina ni en paredes poco resistentes. Si lo hiciera, los tornillos podrían arrancarse de la superficie, caerse los altavoces y dañarse o provocarle lesiones personales.
Conectar los altavoces Precaución: Antes de realizar las conexiones, compruebe que los cables de alimentación para el subwoofer y los otros componentes AV no estén conectados a las tomas de CA. Diagrama de conexión Altavoces Surround Altavoz central Derecho Izquierdo SPEAKERS FRONT SURROUND...
Si conecta el subwoofer a un amplificador DSP de no la parte del aislamiento. Yamaha o a un receptor AV, conéctelo a su Compruebe que la conexión sea segura SUBWOOFER o a la salida LOW PASS.
Si este producto no funciona de la forma deseada, a continuación encontrará una lista con las posibles causas. Si el problema surgido no aparece en la lista, o bien si no puede solucionarlo después de leer estas instrucciones, desconecte el cable de alimentación y consulte con un centro de servicio o con un distribuidor Yamaha autorizado. Problema Posible causa Solución...
10 kΩ NS-B285........Altavoz con cono de 6,5 cm Respuesta de frecuencia........30 Hz–160 Hz NS-C385....Woofer: Altavoz con cono de 6,5 cm x 2 Sensibilidad de entrada..INPUT (jack de patilla 1P RCA): Tweeter: Altavoz con cúpula balanceada de 2,5 cm 80 mV (50 Hz, 50 W/5 Ω)
