INSTALLATION and OPERATION MANUAL
Submersible Dewatering Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
PROSSER
PROSSER
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Series: 6SED-L, 15 - 40HP
1750RPM
DISCONTINUED
Parts may
NOT be available
Form No. 097252-Rev. H
Advertisement
Table of Contents
Related Manuals for CRANE PUMPS & SYSTEMS 6SED-L Series
Summary of Contents for CRANE PUMPS & SYSTEMS 6SED-L Series
- Page 1 Manual Index PROSSER PROSSER ® INSTALLATION and OPERATION MANUAL Submersible Dewatering Pumps Series: 6SED-L, 15 - 40HP 1750RPM DISCONTINUED Parts may NOT be available IMPORTANT! Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY FIRST ....................3 PUMP SPECIFICATIONS ................4 GENERAL INFORMATION ................5 INSTALLATION ....................5 - 6 ELECTRICAL DATA ..................6 START-UP OPERATION ..................6 PREVENTATIVE MAINTENANCE ..............7 SERVICE and REPAIR ..................7 - 11 REPLACEMENT PARTS ..................11 TROUBLE SHOOTING ..................12 CROSS-SECTION (Fig. 9) ................13 EXPLODED VIEW, (Fig. -
Page 3: Safety First
SAFETY FIRST! Please Read This Before Installing Or Operating Pump. This information is provided for SAFETY and to PREVENT Do not block or restrict discharge hose, as discharge EQUIPMENT PROBLEMS. To help recognize this information, hose may whip under pressure. observe the following symbols: IMPORTANT! Warns about hazards that can result WARNING! - DO NOT wear loose clothing that may... -
Page 4: Pump Specifications
SECTION: A - PUMP SPECIFICATIONS: DISCHARGE ....6” 125lb ANSI Flange, Horizontal CORD ENTRY ....50 Ft. (15.2m) Cord, Epoxy sealed LIQUID TEMPERATURE . 104°F (40°C) Continuous housing with secondary pressure MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 grommet for sealing and strain relief VOLUTE ...... -
Page 5: General Information
SECTION B: GENERAL INFORMATION C-1.1 Submergence: It is recommended that the pump be operated in the sub- merged condition and the sump liquid level should never be B-1) To the Purchaser: less than dimension “A” in Figure 1. Congratulations! You are the owner of one of the fi nest pumps on the market today. -
Page 6: Start-Up Operation
C-3.2) Overload Protection : D-1) Check Voltage and Phase: Before operating pump, compare the voltage and phase Three Phase - The normally closed (N/C) thermal sensor is information stamped on the pump identifi cation plate to the embedded in the motor windings and will detect excessive available power. -
Page 7: Preventative Maintenance
SECTION E: PREVENTATIVE MAINTENANCE TABLE 1 - COOLING OIL - Dielectric SUPPLIER GRADE As the motor is oil fi lled, no lubrication or other maintenance is required, and generally will give very reliable service and Enerpar SE100 can be expected to operate for years on normal sewage Conoco Pale Paraffi... - Page 8 Position unit upright, using blocks to avoid resting unit on shaft. After removal of cable and box assembly (10) from motor housing (2), remove cable lead wires from motor lead wires and moisture and temperature sensors wires from control cable by unscrewing connectors (12) and (17). The wiring connections should be noted to insure correct connections when reassembling.
- Page 9 THREE PHASE, 230 VOLT AC Power Cable (10A) Motor Lead Number Green (3-Ground) * Green Black 1 & 7 2 & 8 White 3 & 9 4, 5 & 6 Together *Ground wires could be either 3 Green, or 1 Green and 2 Yellow or 2 Green and 1 Yellow. THREE PHASE, 460 VOLT AC Power Cable (10A) Motor Lead Number...
- Page 10 F-3.4) Conduit Box and Cable Assembly: Set unit upside down on blocks to avoid damaging cords. Refi ll with cooling oil as outlined in paragraph F-1.3. Position Remove socket head cap screws (39) and lift seal plate (25) vertically, being cautious to avoid seal damage, together with conduit box (10) and square ring (11) over opening, apply diaphragm (32), clamp (43) and outboard stationary member thread locking compound to cap screws (6) threads and torque...
-
Page 11: Replacement Parts
SECTION: G REPLACEMENT PARTS Stationary Member (46A) & (46E) Polished Face Out G-1 ORDERING REPLACEMENT PARTS: When ordering replacement parts, ALWAYS furnish the follow- ing information: 1. Pump serial number and date code. (Paragraph G-4) 2. Pump model number. (Paragraph G-3) 3. -
Page 12: Trouble Shooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”... - Page 13 FIGURE 9...
- Page 14 FIGURE 10...
-
Page 15: Parts List
PARTS KITS Seal Repair Kit...P/N-085205D ( ) 8, 10d, 10h, 11, 32, 33, 34, 35, 41, 42, 46 ( ) 3, 8, 10d, 10h, 10k, 10l, 11, 12, 16, 17, 18, 32, 33, 34, 35, 41, 42, 46, 47 Overhaul Kit....P/N-085208D Seal Tool Kit....P/N-085738 Pressure Gauge Kit...P/N-085343 PARTS LIST... - Page 16 002603 Lockwasher 15 -30HP, 5/16 Steel 018926 40HP, 3/8 Stainless 078660 Stud 15-30HP, 5/16-18 x 4-1/2” lg Steel 084885 40HP, 3/8-16 x 4-1/2” lg Steel 002501 15-30HP, 5/16-18 Steel 15-23-6 40HP, 3/8-16 Steel 036803 Soc. Hd. Cap Screw 1/4-20 x 3/4” lg Stainless 070257 Strainer Base 051936...
- Page 17 Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state.
-
Page 18: Returned Goods Policy
IMPORTANT! WARRANTY REGISTRATION Your product is covered by the enclosed Warranty. To complete the Warranty Registration Form go to: http://www.cranepumps.com/ProductRegistration/ If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. -
Page 19: Start-Up Report
START-UP REPORT FOR SUBMERSIBLE PUMPS This form is designed to provide assurance that customer service and a quality product are the number one priority with Crane Pumps & Systems, Inc (CP&S). Please fi ll out the following questions as completely and accurate as possible. When complete, mail this form to: In U.S.A Send To: In Canada Send To:... - Page 20 CP&S control panel part no. and brand Number of pumps operated by control panel NOTE: At no time should holes be made in top of control panel, unless proper sealing devices are utilized. Control panel manufactured by others Company name Model number Short circuit protection Type...
