KIT PART#
USE ON NorthStar ITEMS:
459212, 459222, 459392, 459232,
45933
25653, 25654
REF
PART#
DESCRIPTION
1
789355
Air Filter Element
2
789528
Pump Oil
Owner's Manual
Instructions for Proper Use of
Air Compressor Startup Kits
QTY
2
1
Any Questions, Comments, Problems, or Parts Orders
Call NorthStar Product Support 1-800-270-0810
M45933A.1
KIT NUMBER: 45933 & 45934
SERIAL NUMBER: _____________
KIT PART#
USE ON NorthStar ITEMS:
45934
459382, 459242
REF
PART#
DESCRIPTION
3
789376
Air Filter Element
2
789528
Pump Oil
QTY
1
2

Advertisement

Table of Contents
loading

Related Manuals for NorthStar 45933

Summary of Contents for NorthStar 45933

  • Page 1 M45933A.1 KIT NUMBER: 45933 & 45934 SERIAL NUMBER: _____________ Owner’s Manual Instructions for Proper Use of Air Compressor Startup Kits KIT PART# USE ON NorthStar ITEMS: KIT PART# USE ON NorthStar ITEMS: 459212, 459222, 459392, 459232, 45934 459382, 459242 45933...

  • Page 2: Table Of Contents

    Table of Contents TABLE OF CONTENTS ..............................2 INITIAL SET-UP ................................3 Kit# 45933 ....................................3 Kit# 45934 ....................................3 MAINTENANCE & REPAIR ............................4 MAINTENANCE SCHEDULE SUMMARY ........................4 DETAILED INSTRUCTIONS – MAINTENANCE & REPAIR ..................4 Inspect Safety/Relief Valve ..............................4 Inspect Air Filter ..................................

  • Page 3: Initial Set-Up

    For damaged components, contact the freight company that delivered the unit and file a claim.  If complete, fill out product serial number information. See “Limited Warranty” section of this manual.  Kit# 45933 Air Filter Element Pump Oil Part# 789355...

  • Page 4: Maintenance & Repair

    Change pump oil/ Clean magnetic drain plug  After first 50 hours of use  Every 3 months or 500 hours of use When using oil provided in NorthStar Start-  up Kit: Every 6 months or 1000 hours of use Inspect &...

  • Page 5: Change Air Filter Element

    Change Air Filter Element Schedule Summary” for recommended frequency of oil The compressor’s air filter element should be changed changes. See “Appendix A: Lubricants” for suitable every 12 months or after 1000 hours of use. alternatives. 1. Remove the oil fill and drain plugs. Collect the oil in a suitable container.

  • Page 6: Inspect & Clean Spark Arrestor (If Equipped)

    Major service, including installation or replacement of parts, should be made by a qualified Figure 4 electrical service technician. Contact NorthStar Product Support at 1-800-270-0810 For any questions, problems, or parts orders.

  • Page 7: Appendix A: Lubricants And Compatibility

    Heavy-duty Viton®, Teflon®, Epoxy Neoprene, Natural operating conditions require heavier viscosities. (Glass Filled), Oil Rubber, SBR Rubber, Refer specific operating conditions to NorthStar Product Resistant Alkyd, Acrylic Paint, Lacquer, Support at 1-800-270-0810. Fluorosilicone, Varnish, Polystyrene,...

  • Page 8: Limited Warranty

    NorthStar approved service centers may void this warranty. This warranty is in lieu of any other warranty expressed or implied and NorthStar assumes no other responsibility or liability outside that expressed within this warranty.
  • Page 9 This page has been left intentionally blank...
  • Page 10 Manufactured by Northern Tool + Equipment Co., Ltd Burnsville, MN 55306 NorthernTool.com...
