MODEL
JT-SB116JH2-W-NA
JT-SB116JH2-S-NA
Unit color
-W
(White),
INSTRUCTION MANUAL
■ Read this manual thoroughly before use to ensure the unit is used safely and correctly.
After reading the manual, store it in an easily accessible location for future reference.
You should not attempt to install the unit yourself, as this may affect the safety and functionality of the unit.
This product is intended for the purpose of drying hands and is not covered by the warranty if used for any other purpose.
It has no sterilizing or disinfecting functions.
INDEX
Safety Precautions ...................................................... 2
■ Names of Parts ...............................................................
How to use the unit ...................................................... 3
■ Turning the power on ......................................................
■ After washing hands .........................................................
■ If not using for a long period .............................................
Maintenance ............................................................... 4
1. Cleaning the unit and hand drying area ..................... 4
2. Cleaning the air fi lter ............................................. 5
3. Draining and cleaning the drain tank ........................... 5
4. Cleaning the drain pipe .......................................... 6
If you think something has gone wrong ........................... 7
Specifi cations ............................................................ 8
Hand dryer
-S
(Silver)
− NA - 1 −
Input Power: 120 Vac Single-phase
3
3
3
3
8
－ 1 －
1606876HE3501
Model Name
display position.
Power voltage
display position.
Indoor use only
For User
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric Jet Towel JT-SB116JH2-W-NA
Summary of Contents for Mitsubishi Electric Jet Towel JT-SB116JH2-W-NA
-
Page 1: Table Of Contents
1606876HE3501 Hand dryer Model Name MODEL display position. Power voltage JT-SB116JH2-W-NA display position. JT-SB116JH2-S-NA Unit color (White), (Silver) Input Power: 120 Vac Single-phase Indoor use only For User INSTRUCTION MANUAL ■ Read this manual thoroughly before use to ensure the unit is used safely and correctly. After reading the manual, store it in an easily accessible location for future reference. -
Page 2: Safety Precautions
Safety Precautions Warning The following may lead to death or serious personal injury if handled incorrectly • Do not modify or disassemble the unit. • Do not open the front panel. Doing so may result in an electric shock. Doing so may cause fi res, electric shocks or injury. •... -
Page 3: Names Of Parts
■ Names of Parts ※ Shaded areas in the fi gure indicate antibacterial material. Hand drying area Blue light Black wall area Main unit Sensor • The blue light does not have a sterilizing effect. • Do not look directly into the blue light. Side cover Front panel Tank cover... -
Page 4: Maintenance
Maintenance Warning Caution • Always turn off the power during maintenance work. • Wear rubber gloves when cleaning the unit. Failure to do so may result in an electric shock. Not doing so may result in injuries. • Do not douse the unit with excessive amounts of water. This may cause electric shocks or malfunctions. -
Page 5: Cleaning The Air Fi Lter
Cleaning the drain pipe At least once a week 1 Turn the ground-fault circuit interrupter "OFF". 2 Hook your fi ngers into the handle on the 3 Wipe the inside of the side cover and side cover, and pull it diagonally upwards drain pipe with a well-wrung wet cloth Drain collection outlet... -
Page 6: Cleaning The Drain Pipe
Cleaning the drain pipe At least once a week 1 Turn the ground-fault circuit interrupter "OFF". 2 Hook your fi ngers into the handle on the 3 Wipe the inside of the side cover and side cover, and pull it diagonally upwards drain pipe with a well-wrung wet cloth Drain collection outlet... -
Page 7: If You Think Something Has Gone Wrong
If you think something has gone wrong Perform the following checks and fi xes. Problem Check • Turn the ground fault circuit interrupter on. Are any lamps in the display on? Has a blackout occurred? • Place your hands all the way inside the hand drying area. Are you putting your hands in all the way? No air blows even if hands are inserted... -
Page 8: Specifi Cations
