Nokia ONT
XS-2426G-B Product Guide
3FE-49546-AAAA-TCZZA
Issue 1
December 2021
© 2021 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.

Advertisement

Table of Contents
loading

Related Manuals for Nokia XS-2426G-B

Summary of Contents for Nokia XS-2426G-B

  • Page 1 Nokia ONT XS-2426G-B Product Guide 3FE-49546-AAAA-TCZZA Issue 1 December 2021 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.
  • Page 2 This document is intended for use by Nokia’s customers (“You”/”Your”) in connection with a product purchased or licensed from any company within Nokia Group of Companies. Use this document as agreed. You agree to notify Nokia of any errors you may find in this document;...

  • Page 3: Table Of Contents

    XS-2426G-B unit data sheet ........................43 Overview ............................43 XS-2426G-B part numbers and identification..................43 XS-2426G-B general description ......................45 XS-2426G-B software and installation feature support ..............51 XS-2426G-B interfaces and interface capacity .................51 XS-2426G-B LEDs ..........................53 XS-2426G-B detailed specifications....................55 XS-2426G-B GEM ports and T-CONTs .....................56 XS-2426G-B performance monitoring statistics ................56...
  • Page 4 Overview ............................63 Purpose.............................63 General .............................63 Prerequisites .............................63 Recommended tools .........................63 Safety information ..........................64 Procedure............................64 Wall mount an XS-2426G-B indoor ONT ..................67 Replace a XS-2426G-B indoor ONT ......................73 Overview ............................73 Purpose.............................73 General .............................73 Prerequisites .............................73 Recommended tools .........................73 Safety information ..........................74 Procedure............................74...
  • Page 5 8.43 Configuring USB ..........................131 8.44 Configuring UPnP and DLNA ......................132 Maintenance ...............................133 8.45 Overview ............................133 8.46 Configuring the password .......................133 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 Issue 1 3FE-49546-AAAA-TCZZA...
  • Page 6 Viewing Residential Gateway (RG) troubleshooting counters............144 ONT configuration file over OMCI ......................147 Overview ............................147 Purpose............................147 Supported configuration file types....................147 ONT configuration file over OMCI ....................149 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...
  • Page 7 XS-2426G-B indoor ONT power consumption specifications ............56 Table 5-10 XS-2426G-B indoor ONT environmental specifications ..............56 Table 5-11 XS-2426G-B indoor ONT capacity for GEM ports and T-CONTs...........56 Table 5-12 XS-2426G-B ONT generic performance monitoring statistics............57 Table 5-13 XS-2426G-B ONT ONTL2UNI performance monitoring statistics..........57 Table 5-14 Responsible party contact information ...................59...
  • Page 8 Device Management parameters ....................137 Table 8-42 RG Troubleshooting Counters parameters ..................145 Table 9-1 Supported configuration files......................148 Table 9-2 Download configuration files ......................149 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...
  • Page 9 Figure 5-3 XS-2426G-B indoor ONT LEDs ......................53 Figure 5-4 XS-2426G-B ONT functional block ....................58 Figure 6-1 XS-2426G-B ONT connections......................65 Figure 6-2 XS-2426G-B ONT in wall mounting bracket ..................68 Figure 6-3 XS-2426G-B wall mount bracket ......................69 Figure 6-4 ONT to wall mount connection......................70 Figure 6-5 ONT in wall mount bracket—facing the room ...................71...
  • Page 10 Figure 8-36 Port Forwarding page ........................127 Figure 8-37 Port Triggering page ........................128 Figure 8-38 DDNS page ..........................129 Figure 8-39 NTP page............................130 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...
  • Page 11 Figure 8-50 Factory Default page ........................140 Figure 8-51 Diagnostics page ..........................141 Figure 8-52 Log page............................142 Figure 8-53 RG Troubleshooting Counters page .....................144 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 Issue 1...
  • Page 12 List of figures Nokia ONT © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...

  • Page 13: About This Document

    A note provides information that is, or may be, of special interest. Acronyms and initialisms The expansions and optional descriptions of most acronyms and initialisms appear in the glossary © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...
  • Page 14 If you are a new user and require access to this service, please contact your Nokia sales representative. Select Products. Type your product name in the Find and select a product field and click the search icon.
  • Page 15 If you are a new user and require access to this service, please contact your Nokia sales representative. Select Products. Type your product name in the Find and select a product field and click the search icon.
  • Page 16 Acrobat Reader displays the search results. You can expand the entries for each document by clicking on the + symbol. ND OF STEPS © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...
  • Page 17 For details, refer to the Nokia Support portal (https://customer.nokia.com/support/s/). For ordering information, contact your Nokia sales representative. How to comment Note to reviewers: The following "How to comment" text will appear in the final document when it is published. However, the feedback method described below is for use only on final documents.
  • Page 18 About this document Nokia ONT © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...

  • Page 19: What's New

    The Product guide is a new guide in BBD Release 21.04, issue 1. In future releases, this chapter will provide tables of the feature and document changes applicable to this guide. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.
  • Page 20 What’s new Nokia ONT What’s new in BBD Release 21.04 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...

  • Page 21: Etsi Ont Safety Guidelines

    Do not proceed beyond a warning until the indicated conditions are fully understood and met. The following is an example of the Caution box. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 22: Table 2-1 Safety Labels

    Install and use the equipment according to the instruction manual. Warning 19841 © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...

  • Page 23: Safety Standards Compliance

    Note: The ONTs comply with the U.S. National Electrical Code. However, local electrical authorities have jurisdiction when there are differences between the local and U.S. standards. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.

  • Page 24: Esd Safety Guidelines

    The use of any non-Nokia approved power supplies or power adapters is not supported or endorsed by Nokia. Such use will void any warranty or support contract with Nokia. Such use greatly increases the danger of damage to equipment or property.

  • Page 25: Figure 2-2 Laser Product Label

    Figure 2-3, “Laser classification label” (p. 26) shows a laser classification label. Laser classification labels may be provided in other languages. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 Issue 1...

  • Page 26: Figure 2-4 Laser Warning Labels

    • An instruction against staring into the beam or viewing directly with optical instruments • Wavelength • Normal output power • Maximum output power © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA...
  • Page 27 Risk of eye damage by laser radiation. 2.5.4 Location class Use cable supports and guides to protect the receptacles from strain. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 Issue 1...

  • Page 28: Environmental Requirements

    • When high humidity is present, installation of a cover or tent over the ONT helps prevent condensation when the door is opened. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 29: Etsi Environmental And Crohs Guidelines

    Concentration Limits for Certain Hazardous Substances in Electronic Information Products). Products with this label are recyclable. The label may be found in this documentation or on the product. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 30: Figure 3-2 Products Above Mcv Value Label

    The label may be found in this documentation or on the product. Figure 3-2 Products above MCV value label Together with major international telecommunications equipment companies, Nokia has determined it is appropriate to use an EFUP of 50 years for network infrastructure equipment and an EFUP of 20 years for handsets and accessories.

  • Page 31: Hazardous Substances Table (Hst)

    EU market after 1 July 2006, with various exemptions, including an exemption for lead solder in network infrastructure equipment. Nokia products shipped to the EU after 1 July 2006 comply with the EU RoHS Directive.

  • Page 32: Figure 3-3 Recycling/Take Back/Disposal Of Product Symbol

    There can be different requirements for collection and treatment in different member states of the European Union. In compliance with legal requirements and contractual agreements, where applicable, Nokia will offer to provide for the collection and treatment of Nokia products bearing the logo shown in Figure 3-3, “Recycling/take back/disposal of product symbol” (p. 32) at the end of their useful life, or products displaced by Nokia equipment offers.

  • Page 33: Ansi Ont Safety Guidelines

    Do not proceed beyond a warning until the indicated conditions are fully understood and met. The following is an example of the Caution box. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 34: Table 4-1 Safety Labels

    CE marking There are various CE symbols for CE compliance. The following table shows a sample safety label on the ONT equipment. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA...

  • Page 35: Safety Standards Compliance

    Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.

  • Page 36: Figure 4-2 Sample Laser Product Label Showing Cdrh 21 Cfr Compliance

    42 for ONTs containing Class 1 Laser modules certified by original manufactures. Per CDRH 21 CFR 10.40.10 (h) (1) (iv) distributors of Class 1 laser products, such as Nokia ONTs shall leave the following Laser Safety cautions with the end user.

  • Page 37: Laser Safety Guidelines

    Possibility of equipment damage. Risk of eye damage by laser radiation. Per CDRH 21 CFR 10.40.10 (h) (1) (iv) distributors of Class 1 laser products, such as Nokia ONTs shall leave the following Laser Safety cautions with the end user.

  • Page 38: Figure 4-3 Laser Product Label

    • an instruction against staring into the beam or viewing directly with optical instruments • wavelength • normal output power • maximum output power © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA...

  • Page 39: Figure 4-6 Sample Laser Product Safety Label On The Ont Equipment

    Figure 4-6, “Sample laser product safety label on the ONT equipment” (p. 40) shows a sample laser product safety label on the ONT equipment. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 40: Electrical Safety Guidelines

    Note: The ONTs comply with the U.S. National Electrical Code. However, local electrical authorities have jurisdiction when there are differences between the local and U.S. standards. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.

  • Page 41: Esd Safety Guidelines

    The use of any non-Nokia approved power supplies or power adapters is not supported or endorsed by Nokia. Such use will void any warranty or support contract with Nokia. Such use greatly increases the danger of damage to equipment or property.
  • Page 42 • When high humidity is present, installation of a cover or tent over the ONT helps prevent condensation when the door is opened. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 43: Xs-2426G-B Unit Data Sheet

    5.11 XS-2426G-B standards compliance 5.12 XS-2426G-B special considerations XS-2426G-B part numbers and identification Table 5-1, “Identification of XS-2426G-B indoor ONTs” (p. 43) provides part numbers and identification information for the XS-2426G-B indoor ONT. Table 5-1 Identification of XS-2426G-B indoor ONTs...

  • Page 44: Table 5-2 Xs-2426G-B Power Supply Ordering Information

    Table 5-2, “XS-2426G-B power supply ordering information” (p. 44) provides the power supply information for the XS-2426G-B ONT. For more information on power supplies, see the Nokia ONT Power Supply and UPS Guide. Table 5-2 XS-2426G-B power supply ordering information...

  • Page 45: Xs-2426G-B General Description

    ONT unit The XS-2426G-B ONT. Wall mount bracket The wall mount bracket is fastened to a wall. The XS-2426G-B ONT is seated in the wall mount bracket. With white color, 1 pc per box. (3FE 49471 AA) Wall mount bracket The wall mount bracket is fastened to a wall.

  • Page 46: Figure 5-1 Xs-2426G-B Ont

    W LA US B 36995 XS-2426G-B indoor ONTs provide the following functions: • Dual-band concurrent 4x4 802.11b/g/n/ac/ax 2.4 GHz and 4x4 802.11ac/ax MU-MIMO 5 GHz • Supports 802.11b/g/n/ac/ax 4x4 Wireless 2.4 GHz MIMO; Channel bandwidth 20, 40 MHz, auto • Supports 802.11ac/ax 4x4 Wireless 5 GHz Mu-MIMO; Channel bandwidth 20, 40, 80 MHz, auto •...
  • Page 47 • Caller ID, call waiting, call hold, 3-way calling, call transfer, message waiting • Forward Error Correction (FEC) • support for multiple SSIDs (private and public instances); contact your Nokia representative for further details. • Conductive power: 250 mW/24 dBm (2.4 GHz); 500 mW/27 dBm (5 GHz) •...
  • Page 48 • Remote software image downloading and activation • IP/MAC/URL filter • Multi-level firewall and ACL 5.3.1 TR-069 parameter support The XS-2426G-B ONT supports the following TR-069 features: • Host object • Port forwarding • Optical parameters • Object support for WiFi parameters •...
  • Page 49 If the URL is set to the https://... format, by default, the connection will use TLS without authentication mode. The ONT can also authenticate the ACS using a pre-installed CA certificate. The XS-2426G-B ONTs support TLSv1.3 for TR069. The ONT supports download certification from ACS.
  • Page 50 The vendor specific attribute is: X_ALU-COM_XML_File_Name_Path. 5.3.4 TR-104 voice-related alarms The XS-2426G-B ONT supports the following four TR-104 voice-related alarms on a per FXS port basis. These alarms all represent SIP registration failures with an alarm level of MAJOR. • SIPREGDNS: domain name could not be resolved •...

  • Page 51: Xs-2426G-B Software And Installation Feature Support

    — — — — Notes: 1. The XS-2426G-B ONTs provide Wi-Fi service that is enabled and disabled using a Wi-Fi on/off switch. 5.5.1 XS-2426G-B connections and components Figure 5-2, “XS-2426G-B indoor ONT physical connections (back)” (p. 52) shows the physical connections for XS-2426G-B indoor ONTs.

  • Page 52: Table 5-5 Xs-2426G-B Indoor Ont Physical Connections

    T E L On/off button O N /O P O W Power 36736 Table 5-5, “XS-2426G-B indoor ONT physical connections” (p. 52) describes the physical connections for XS-2426G-B indoor ONTs. Table 5-5 XS-2426G-B indoor ONT physical connections Connection Print Letters Description...

  • Page 53: Xs-2426G-B Leds

    INTERNET POWER INTERNET WLAN WLAN 36997 Table 5-6, “XS-2426G-B indoor ONT LED descriptions” (p. 54) provides LED descriptions for XS- 2426G-B indoor ONTs. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...
  • Page 54 XS-2426G-B unit data sheet Nokia ONT XS-2426G-B LEDs Table 5-6 XS-2426G-B indoor ONT LED descriptions Indicator LED color and LED behavior description behavior Power Green solid Power on Blinking green Software team to update Power off Red solid Light failed on startup (for example corrupt flash), or self test failed on startup, or self test...

  • Page 55: Xs-2426G-B Detailed Specifications

    XS-2426G-B unit data sheet Nokia ONT XS-2426G-B detailed specifications XS-2426G-B detailed specifications The following table lists the physical specifications for XS-2426G-B indoor ONTs. Table 5-7 XS-2426G-B indoor ONT physical specifications Description Specification Depth 6.29 in. (160 mm) Width 3.34 in. (85 mm) Height (including antenna) 8.85 in.

  • Page 56: Xs-2426G-B Gem Ports And T-Conts

    Storage: -4°F to 158°F (-20°C to 70°C) XS-2426G-B GEM ports and T-CONTs Table 5-11, “XS-2426G-B indoor ONT capacity for GEM ports and T-CONTs” (p. 56) lists the maximum number of supported T-CONTs and GEM ports. See the appropriate release Customer Release Notes for the most accurate list of supported devices.

  • Page 57: Xs-2426G-B Functional Blocks

    5.10 XS-2426G-B functional blocks XS-2426G-B indoor ONTs are single-residence ONTs that support Wireless (Wi-Fi) service. Wi-Fi service on these ONTs is compliant with the IEEE 802.11 standard and enabled or disabled using a WLAN button. In addition to the Wi-Fi service, these ONTs transmit Ethernet packets to four RJ-45 Ethernet ports and voice traffic to two RJ-11 POTS port.

  • Page 58: Xs-2426G-B Standards Compliance

    37000 5.11 XS-2426G-B standards compliance XS-2426G-B indoor ONTs are compliant with the following standards: • CE marking for European standards for health, safety, and environmental protection • EN 300-328 v1.9.1 wide band data transmission standards for 2.4GHz bands • G.984 support GPON interface (framing) •...

  • Page 59: Table 5-14 Responsible Party Contact Information

    The XS-2426G-B ONTS qualify as equipment with high network availability (HiNA) functionality. Since the main purpose of XS-2426G-B ONTs is to provide network functionality with HiNA 7 days /24 hours, the modes Off/Standby, Power Management, and Networked Standby are inappropriate.

  • Page 60: Xs-2426G-B Special Considerations

    5.12.1 Wi-Fi service XS-2426G-B indoor ONTs feature Wi-Fi service as well as voice and data services. Wi-Fi is a wireless networking technology that uses radio waves to provide wireless HSI and network connections. This ONT complies with the IEEE 802.11 standards, which the Wi-Fi Alliance defines as the basis for Wi-Fi technology.

  • Page 61: Table 5-15 Xs-2426G-B Ont Considerations And Limitations

    XS-2426G-B indoor ONTs have HTML-based Wi-Fi configuration GUIs. 5.12.2 XS-2426G-B ONT considerations and limitations Table 5-15, “XS-2426G-B ONT considerations and limitations” (p. 60) lists the considerations and limitations for Package P XS-2426G-B ONTs. Table 5-15 XS-2426G-B ONT considerations and limitations...
  • Page 62 XS-2426G-B unit data sheet Nokia ONT XS-2426G-B special considerations © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...

  • Page 63: Install A Xs-2426G-B Indoor Ont

    Purpose This chapter provides the steps to install a XS-2426G-B indoor ONT. General The steps listed in this chapter describe mounting and cabling for a XS-2426G-B indoor ONT. Prerequisites You need the following items before beginning the installation: • all required cables...

  • Page 64: Safety Information

    Chapter 5, “XS-2426G-B unit data sheet” for the temperature ranges of these ONTs. Procedure Use this procedure to install a XS-2426G-B indoor ONT. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 65: Figure 6-1 Xs-2426G-B Ont Connections

    Nokia ONT Procedure Place the indoor ONT unit on a flat surface, such as a desk or shelf. Note: The XS-2426G-B cannot be stacked with another ONT or with other equipment. The ONT mounting requirements are: • allow a minimum 100 mm clearance above the top cover •...
  • Page 66 Install a XS-2426G-B indoor ONT Nokia ONT Procedure Wi-Fi security/ on/off buttons W P S W L A U S B L A N Ethernet ports (4) L A N (RJ-45) L A N POTS L A N ports (2)

  • Page 67: Wall Mount An Xs-2426G-B Indoor Ont

    ND OF STEPS Wall mount an XS-2426G-B indoor ONT This chapter provides the steps to mount an XS-2426G-B indoor ONT on a wall using a wall mount bracket (3FE 49471 AA). The XS-2426G-B indoor ONT is shipped without the wall mount bracket.

  • Page 68: Figure 6-2 Xs-2426G-B Ont In Wall Mounting Bracket

    6.8.2 Procedure Use this procedure to mount an XS-2426G-B ONT on a wall. Two installation options are available: • Option 1—facing the room for the LEDs to be visible • Option 2—facing the wall for the connectors and buttons to be visible Place the indoor ONT unit: a.
  • Page 69 Connect the power cord to the XS-2426G-B ONT. h. Install the ONT into the wall mount bracket by lifting the unit above the bracket and sliding it downward onto the bottom ledge of the bracket.

  • Page 70: Figure 6-4 Ont To Wall Mount Connection

    Install a XS-2426G-B indoor ONT Nokia ONT Wall mount an XS-2426G-B indoor ONT Figure 6-4 ONT to wall mount connection PO W PO N IN TE RN ET TE L W PS W LA US B 36748 i. Seat the ONT into the wall mount bracket by engaging the hooks on the base of the unit with those on the bracket;...
  • Page 71 Install a XS-2426G-B indoor ONT Nokia ONT Wall mount an XS-2426G-B indoor ONT Figure 6-5 ONT in wall mount bracket—facing the room PO W PO N IN TE RN ET TE L W PS W LA US B 36994 Mount the ONT facing the wall using the wall mount bracket (3FE 49471 AA).

  • Page 72: Figure 6-6 Ont In Wall Mount Bracket-Facing The Room / Wall

    Install a XS-2426G-B indoor ONT Nokia ONT Wall mount an XS-2426G-B indoor ONT i. Connect the cables. See Chapter 6, “Install a XS-2426G-B indoor ONT”. Figure 6-6, “ONT in wall mount bracket—facing the room / wall” (p. 71) shows the mounted unit facing the wall with the cables (including the fiber) installed.

  • Page 73: Replace A Xs-2426G-B Indoor Ont

    Purpose This chapter provides the steps to replace a XS-2426G-B indoor ONT. General The steps listed in this chapter describe mounting and cabling for a XS-2426G-B indoor ONT. Prerequisites You need the following items before beginning the installation: • all required cables...

  • Page 74: Safety Information

    Chapter 5, “XS-2426G-B unit data sheet” for the temperature ranges of these ONTs. Procedure Use this procedure to replace a XS-2426G-B indoor ONT. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021...

  • Page 75: Figure 7-1 Xs-2426G-B Indoor Ont Connections

    If the ONT is in service, place the ONT in OOS state. Example: ED-ONT::ONT-1-1-1-1-1; If used, disable the Wi-Fi service by pressing the WLAN button; see the following figure for the location of the WLAN button. Figure 7-1 XS-2426G-B indoor ONT connections WLAN LAN1 LAN2 LAN3...

  • Page 76: Figure 7-2 Xs-2426G-B Indoor Ont Connections (Labelled)

    Replace a XS-2426G-B indoor ONT Nokia ONT Procedure Figure 7-2 XS-2426G-B indoor ONT connections (labelled) Wi-Fi security/ on/off buttons W P S W L A U S B L A N Ethernet ports (4) L A N (RJ-45) L A N...
  • Page 77 If required, have approved service personnel who are trained to work with optic fiber clean the fiber optic connection. See the Nokia ONT Configuration, Management, and Troubleshooting Guide for more information about fiber optic handling, inspection, and cleaning.
  • Page 78 If the old SLID is used, no changes need to be made at the P-OLT; see the operations and maintenance documentation for the OLT for more details. Verify the ONT LEDs, voltage status, and optical signal levels; see the Nokia ONT Hardware and Cabling Installation Guide.

  • Page 79: Configure A Xs-2426G-B Indoor Ont

    Configure a XS-2426G-B indoor ONT Nokia ONT Overview 8 Configure a XS-2426G-B indoor ONT Overview 8.1.1 Purpose 8.1.2 Contents 8.1 Overview GUI configuration 8.2 General configuration 8.3 HGU mode GUI configuration 8.4 Log in to web-based GUI 8.5 Viewing overview information Viewing device information and connection status 8.6 Overview...
  • Page 80 Configure a XS-2426G-B indoor ONT Nokia ONT Overview 8.22 Configuring Wireless 2.4GHz 8.23 Configuring Wireless 5GHz 8.24 Configuring wireless scheduling 8.25 Configuring IP routing 8.26 Configuring DNS 8.27 Configuring TR-069 8.28 Configuring GRE tunnel 8.29 Configuring Upstream (US) Classifier 8.30 Configuring QoS Security configuration 8.31 Overview...
  • Page 81 Configure a XS-2426G-B indoor ONT Nokia ONT Overview 8.50 Backing up the configuration 8.51 Restoring the configuration 8.52 Upgrading firmware 8.53 Rebooting the device 8.54 Resetting to factory defaults 8.55 Diagnosing WAN connections 8.56 Viewing log files RG Troubleshooting Counters 8.57 Overview...

  • Page 82: Gui Configuration

    Troubleshooting Guide. HGU mode GUI configuration Use the procedures below to use the web-based GUI for the XS-2426G-B in HGU mode. This mode is preset at delivery. A home gateway unit (HGU) is a home networking device, used as a gateway to connect devices in the home through fiber to the Internet.

  • Page 83: Viewing Overview Information

    Configure a XS-2426G-B indoor ONT Nokia ONT GUI configuration Viewing overview information Figure 8-1 Web login page Note: If you forget the current username and password, press the reset button for 5 seconds and the default values for the username and password will be recovered at startup.

  • Page 84: Table 8-1 Overview Parameters

    Description Overview Information WiFi-Networks Home Network Name of the IP WAN connection of the Nokia WiFi beacon. You can edit the name. Wi-Fi points Indicates the number of active routers. Family Profile Displays the profile of the members connected to the network topology Devices Displays the type of device connected.

  • Page 85: Viewing Device Information And Connection Status

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Overview Viewing device information and connection status Overview 8.6.1 Purpose This chapter describes procedures to view device information and connection status on the XS- 2426G-B. 8.6.2 Contents 8.6 Overview...

  • Page 86: Table 8-2 Device Information Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing device information Figure 8-2 Device Information page Note: Upon login, the Home Gateway page displays the WAN status block on the bottom left part of each page. This block shows the WAN connection ID, the WAN status, and any WAN errors.

  • Page 87: Viewing Lan Status

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing LAN status Viewing LAN status Click Status LAN Status from the left pane. The LAN Status page displays the following information. Figure 8-3 LAN Status page...

  • Page 88: Viewing Wan Status

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing WAN status Table 8-3 LAN Status parameters (continued) Field Description Ethernet Rx packets Number of packets received on the Ethernet connection Ethernet Tx packets Number of packets transmitted on the Ethernet connection...

  • Page 89: Viewing Wan Ipv6 Status

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing WAN IPv6 status Table 8-4 WAN Status parameters (continued) Field Description Ethernet link status Indicates whether the Ethernet link is up or down Tx packets Number of packets transmitted on the WAN connection...

  • Page 90: Viewing Sta Information

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing STA information Table 8-5 WAN Status IPv6 parameters (continued) Field Description Connection mode Indicates the mode of connection. VLAN VLAN ID WAN Connection List Drop-down menu listing all WAN connections. The connection shown is the connection for which WAN status will be shown.

  • Page 91: Viewing Neighboring Access Points

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing Neighboring Access Points Figure 8-6 STA Information page Table 8-6 STA information parameters Field Description MAC Address MAC address of the Ethernet connection SSID Name Name of each SSID...

  • Page 92: Viewing Home Networking Information

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing home networking information Figure 8-7 Neighboring AP page Table 8-7 Neighboring AP parameters Field Description Index Name of the index SSID name Name of each SSID...

  • Page 93: Viewing Optics Module Status

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing optics module status Figure 8-8 Home Networking page Table 8-8 Home Networking parameters Field Description Local Interface Ethernet Table displays the number of Ethernet connections and their settings Wireless Table displays the number of wireless connections and their settings (2.4GHz and 5GHz)

  • Page 94: Viewing Statistics

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing statistics Figure 8-9 Optics Module Status page Table 8-9 Optics Module Status parameters Field Description Laser Bias Current (ONT ANI-ONT-Side Optical Measurements) Laser bias current, measured in uA...

  • Page 95: Figure 8-10 Lan Statistics Page

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing statistics Figure 8-10 LAN Statistics page Figure 8-11 WAN Statistics page Figure 8-12 WLAN Statistics page © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.

  • Page 96: Viewing Voice Information

    Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing voice information You can click to update the displayed information. ND OF STEPS 8.16 Viewing voice information Click Status Voice Information from the left pane. The Voice Information page displays the...
  • Page 97 Configure a XS-2426G-B indoor ONT Nokia ONT Viewing device information and connection status Viewing voice information Table 8-10 Voice Information parameters (continued) Field Description Line 1 registration error code SIP standard error code for the register status; for example, 401, 403, 503...

  • Page 98: Network Configuration

    Nokia ONT Network configuration Overview Network configuration 8.17 Overview 8.17.1 Purpose This chapter describes the network configuration tasks supported by XS-2426G-B ONTs. 8.17.2 Contents 8.17 Overview 8.18 Configuring LAN 8.19 Configuring LAN IPv6 8.20 Configuring WAN 8.21 Configuring WAN DHCP 8.22 Configuring Wireless 2.4GHz...

  • Page 99: Table 8-11 Lan Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring LAN Figure 8-14 LAN page Configure the following LAN parameters: Table 8-11 LAN parameters Field Description Port Mode IPv4 address Enter the IPv4 address of the ONT. Subnet Mask Enter the subnet mask of the ONT.

  • Page 100: Configuring Lan Ipv6

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring LAN IPv6 Configure the Static DHCP parameters. Click Add. You can click Delete to delete a Static DHCP MAC address or IPv4 address. ND OF STEPS 8.19 Configuring LAN IPv6 Click Network LAN_IPv6 from the left pane.

  • Page 101: Configuring Wan

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring WAN Table 8-12 LAN IPv6 parameters (continued) Field Description Prefix Config Select a prefix config option from the list: • WANConnection (prefix will be obtained from the WAN), or • Static (enables you to enter the prefix) Interface This field displays if you select the WanConnection option from the Prefix Config field.

  • Page 102: Table 8-13 Wan Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring WAN Configure the following parameters: Table 8-13 WAN parameters Field Description WAN connection list Select a WAN connection from the list to set the connection parameters. Enabled Tap the Enable / Disable toggle to enable or disable the WAN connection.

  • Page 103: Configuring Wan Dhcp

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring WAN DHCP Table 8-13 WAN parameters (continued) Field Description Echo Value Indicates the number of times, the device sent messages to the server to check if the IP address is available or not.

  • Page 104: Configuring Wireless 2.4Ghz

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Wireless 2.4GHz Table 8-14 WAN DHCP parameters (continued) Field Description Enable DHCP Option 60 Click to enable DHCP Option 60 (vendor class identifier ). Enable DHCP Option 61 Click to enable DHCP Option 61 (client identifier).

  • Page 105: Table 8-15 Wireless (2.4Ghz) Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Wireless 2.4GHz Table 8-15 Wireless (2.4GHz) parameters Field Description Enable Click to enable Wi-Fi. Mode Select a Wi-Fi mode from the list: • auto (b/g/n/ac/ax) • b/g/n • b • g •...

  • Page 106: Configuring Wireless 5Ghz

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Wireless 5GHz Table 8-15 Wireless (2.4GHz) parameters (continued) Field Description WPA version Select a WPA version from the list: • WPA2 • WPA/WPA2 WPA Encryption Mode Select a WPA encryption mode from the list: •...

  • Page 107: Table 8-16 Wireless (5Ghz) Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Wireless 5GHz Configure the following parameters: Table 8-16 Wireless (5GHz) parameters Field Description Enable Click to enable Wi-Fi. Bandwidth Select the bandwidth range from the list: • 20 MHz • 40 MHz •...

  • Page 108: Configuring Wireless Scheduling

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring wireless scheduling Table 8-16 Wireless (5GHz) parameters (continued) Field Description WPA Key Enter the WPA key. Enable WPS Click to enable or disable WPS. Domain Grouping Click to enable domain grouping Click Save.

  • Page 109: Configuring Ip Routing

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring IP routing A separate panel displays for configuring wireless schedule rules. Enter a start time and end time for the period in which you want the wireless signal off. Select Everyday or Individual Days from the list.

  • Page 110: Configuring Dns

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring DNS Table 8-17 IP Routing parameters Field Description Enable IP routing Click to enable routing. Destination IP address Enter the destination IP address. Destination netmask Enter the destination network mask.

  • Page 111: Configuring Tr-069

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring TR-069 Table 8-18 DNS parameters Field Description DNS Proxy Click to enable or disable DNS proxy and click Save. Domain Name Enter the domain name. IPv4 address Enter the domain IP address and click Add.

  • Page 112: Configuring Gre Tunnel

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring GRE tunnel Table 8-19 TR-069 parameters Field Description Periodic inform enable Click to enable periodic inform updates. Periodic inform interval(s) Enter the time between periodic inform updates, in seconds. Enter the URL of the auto-configuration server.

  • Page 113: Configuring Upstream (Us) Classifier

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Upstream (US) Classifier Table 8-20 GRE Tunnel parameters Field Description Tunnel Name Select Create new GRE Tunnel or select an existing tunnel from the list. The tunnel name is automatically assigned by the system.

  • Page 114: Table 8-21 Us Classifier Policy Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Upstream (US) Classifier Figure 8-25 US Classifier Policy page Configure the following parameters: Table 8-21 US Classifier Policy parameters Field Description Tunnel Type The tunnel type is set to GRE and cannot be modified.

  • Page 115: Table 8-22 Us Classifier Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Upstream (US) Classifier Click Network US Classifier from the left pane and select the Classifier tab. All classifiers are displayed in the classifier table in the page. Figure 8-26 US Classifier page Configure the following parameters: At least one field must be selected to create a classifier.

  • Page 116: Table 8-23 Us Classifier Rules Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring Upstream (US) Classifier Click Save. You can click Reset to reset the configured values. To delete a classifier, click Delete for the applicable classifier in the classifier table. A classifier can only be deleted if it is not associated with any classifier rules.

  • Page 117: Configuring Qos

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring QoS Table 8-23 US Classifier Rules parameters (continued) Field Description Destination IP Enter a destination IP address. Source Port Enter a source port. Destination Port Enter a destination port. IP Protocol Type Enter a value between 0 and 254.

  • Page 118: Figure 8-28 Qos Config Page (L3 Packet Sizes)

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring QoS Figure 8-28 QoS Config page (L3 packet sizes) Figure 8-29 QoS Config page (L3 packet sizes) continued © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.

  • Page 119: Table 8-24 Qos Config Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Network configuration Configuring QoS Configure the following parameters: Table 8-24 QoS Config parameters Field Description QoS Setting Type Select a QoS service layer type from the list L2 Criteria or L3 Criteria. Classification Criteria Source MAC Enter the source MAC address.

  • Page 120: Security Configuration

    Security configuration Overview Security configuration 8.31 Overview 8.31.1 Purpose This chapter describes the security configuration tasks supported by XS-2426G-B ONTs 8.31.2 Contents 8.31 Overview 8.32 Configuring the firewall 8.33 Configuring the MAC filter 8.34 Configuring the IP filter 8.35 Configuring the URL filter 8.36 Configuring DMZ and ALG...

  • Page 121: Configuring The Mac Filter

    Configure a XS-2426G-B indoor ONT Nokia ONT Security configuration Configuring the MAC filter Table 8-25 Firewall parameters Field Description Security level Select the security level from the list: High: Traffic denied inbound and minimally permit common services outbound Low: All outbound traffic and pinhole-defined inbound traffic is allowed...

  • Page 122: Configuring The Ip Filter

    Configure a XS-2426G-B indoor ONT Nokia ONT Security configuration Configuring the IP filter Table 8-26 MAC Filter parameters (continued) Field Description MAC filter mode Select the MAC filter mode from the list: Blocked or Allowed. LAN port Click on either one of the ports : LAN1, LAN2, LAN3, LAN4 MAC address Select the MAC address from the list or enter the address in the text field.

  • Page 123: Configuring The Url Filter

    Configure a XS-2426G-B indoor ONT Nokia ONT Security configuration Configuring the URL filter Table 8-27 IP Filter parameters Field Description Enable IP Filter Click to enable an IP filter. Mode Select an IP filter mode from the list: • Drop for upstream •...

  • Page 124: Configuring Dmz And Alg

    Configure a XS-2426G-B indoor ONT Nokia ONT Security configuration Configuring DMZ and ALG Configure the following parameters: Table 8-28 URL Filter parameters Field Description Enable URL filter Click to enable the URL filter. URL filter type Select the option to block the URL or allow the URL.

  • Page 125: Configuring Access Control

    Configure a XS-2426G-B indoor ONT Nokia ONT Security configuration Configuring access control Click Save ALG. Configure the following parameters: Table 8-30 DMZ parameters Field Description WAN connection list Select a WAN connection from the list. Enable DMZ Click to enable DMZ on the selected WAN connection.

  • Page 126: Table 8-31 Access Control Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT Security configuration Configuring access control Configure the following parameters: Table 8-31 Access Control parameters Field Description WAN connection list Select a connection from the list. Enable trusted network Click to enable or disable trusted network.

  • Page 127: Configuring The Application

    Configuring the Application Overview Configuring the Application 8.38 Overview 8.38.1 Purpose This chapter describes the application configuration tasks supported by the XS-2426G-B ONTs. 8.38.2 Contents 8.38 Overview 8.39 Configuring port forwarding 8.40 Configuring port triggering 8.41 Configuring DDNS 8.42 Configuring NTP 8.43 Configuring USB...

  • Page 128: Configuring Port Triggering

    Configure a XS-2426G-B indoor ONT Nokia ONT Configuring the Application Configuring port triggering Table 8-33 Port Forwarding parameters Field Description Application Name Select an application name from the list. The default is Custom settings. WAN Port Enter the WAN port range.

  • Page 129: Configuring Ddns

    Configure a XS-2426G-B indoor ONT Nokia ONT Configuring the Application Configuring DDNS Table 8-34 Port Triggering parameters Field Description Application Name Select an application name from the list. The default isCustom settings. Open Port Enter the open port range. Triggering Port Enter the triggering port range.

  • Page 130: Configuring Ntp

    Configure a XS-2426G-B indoor ONT Nokia ONT Configuring the Application Configuring NTP Configure the following parameters: Table 8-35 DDNS parameters Field Description WAN Connection List Select a WAN connection from the list. Enable DDNS Click to enable DDNS on the selected WAN connection.

  • Page 131: Configuring Usb

    Configure a XS-2426G-B indoor ONT Nokia ONT Configuring the Application Configuring USB Table 8-36 NTP parameters Field Description Enable NTP Service Click to enable the NTP service. Current date& time Enter the current local date and time. Primary Time Server Select a time server from the list or select Custom settings and enter the address of the time server.

  • Page 132: Configuring Upnp And Dlna

    Configure a XS-2426G-B indoor ONT Nokia ONT Configuring the Application Configuring UPnP and DLNA Configure the following parameters: Table 8-37 USB parameters Field Description Enable FTP server Click to enable using an FTP server. Username Enter the username for the FTP server.

  • Page 133: Maintenance

    Nokia ONT Maintenance Overview Maintenance 8.45 Overview 8.45.1 Purpose This chapter describes the maintenance tasks supported by XS-2426G-B ONTs. 8.45.2 Contents 8.45 Overview 8.46 Configuring the password 8.47 Configuring LOID 8.48 Configuring SLID 8.49 Managing the device 8.50 Backing up the configuration 8.51 Restoring the configuration...

  • Page 134: Configuring Loid

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Configuring LOID • The first character cannot be a special character • There are not enough character classes Click Maintenance Password from the left pane. The Password page displays. Figure 8-42 Password page...

  • Page 135: Configuring Slid

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Configuring SLID Figure 8-43 LOID Config page Configure the following parameters: Table 8-39 LOID Configuration parameters Field Description LOID authetication LOID Enter the LOID; the maximum number of characters is 24 If the password is null, this field may be left blank.

  • Page 136: Managing The Device

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Managing the device Figure 8-44 SLID Configuration page Configure the following parameters: Table 8-40 SLID Configuration parameters Field Description Current SLID Displays the current SLID. Enter New SLID Enter the new SLID.

  • Page 137: Backing Up The Configuration

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Backing up the configuration Figure 8-45 Device Management page Configure the following parameters: Table 8-41 Device Management parameters Field Description Host Name Select a hostname from the list. MAC address Indicates the MAC address.

  • Page 138: Restoring The Configuration

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Restoring the configuration Figure 8-46 Backup and Restore page Click Select to select the file to export. Click Export to export the current ONT configuration to a backup file. ND OF STEPS 8.51...

  • Page 139: Upgrading Firmware

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Upgrading firmware Click Import to restore the ONT to the saved backup. ND OF STEPS 8.52 Upgrading firmware Click Maintenance Firmware Upgrade from the left pane. The Firmware Upgrade page displays. Figure 8-48 Firmware Upgrade page Click Select and select the firmware file.

  • Page 140: Resetting To Factory Defaults

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Resetting to factory defaults Figure 8-49 Reboot Device page Click Reboot to reboot the ONT. ND OF STEPS 8.54 Resetting to factory defaults Click Maintenance Factory Default from the left pane. The Factory Default page displays.

  • Page 141: Diagnosing Wan Connections

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Diagnosing WAN connections 8.55 Diagnosing WAN connections Click Maintenance Diagnostics from the left pane. The Diagnostics page displays. Figure 8-51 Diagnostics page Select a WAN connection to diagnose from the list. Enter the IP address or domain name.

  • Page 142: Viewing Log Files

    Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Viewing log files Click Cancel to cancel the test. ND OF STEPS 8.56 Viewing log files Click Maintenance Log from the left pane. The Log page displays. Figure 8-52 Log page Select a write level from the list to determine which types of events are recorded in the log file: •...
  • Page 143 Configure a XS-2426G-B indoor ONT Nokia ONT Maintenance Viewing log files • Error • Warning • Notice • Informational • Debug The log file is displayed at the bottom of the page. Click Save. You can click to update the displayed information.

  • Page 144: Rg Troubleshooting Counters

    Configure a XS-2426G-B indoor ONT Nokia ONT RG Troubleshooting Counters Overview RG Troubleshooting Counters 8.57 Overview 8.57.1 Purpose This section describes the RG troubleshooting counters GUI procedures. 8.57.2 Contents 8.57 Overview 8.58 Viewing Residential Gateway (RG) troubleshooting counters 8.58 Viewing Residential Gateway (RG) troubleshooting counters The Troubleshooting Counters feature enables service providers and end users to monitor the performance of their broadband connection.

  • Page 145: Table 8-42 Rg Troubleshooting Counters Parameters

    Configure a XS-2426G-B indoor ONT Nokia ONT RG Troubleshooting Counters Viewing Residential Gateway (RG) troubleshooting counters Configure the following parameters: Table 8-42 RG Troubleshooting Counters parameters Field Description WAN Connection List Select a WAN connection from the list. WAN Status Indicates whether the broadband connections is active (UP) or not (DOWN).
  • Page 146 Configure a XS-2426G-B indoor ONT Nokia ONT RG Troubleshooting Counters Viewing Residential Gateway (RG) troubleshooting counters © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use. December 2021 3FE-49546-AAAA-TCZZA Issue 1...

  • Page 147: Ont Configuration File Over Omci

    Supported configuration file types Table 9-1, “Supported configuration files” (p. 148) describes the configuration file types that are supported from Nokia ONT R05.02.00 and later. © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.
  • Page 148 XML file. Nokia recommends using this procedure, rather than embedded voice XML files. The Nokia defined index for the Voice XML file is: "XML" © 2021 Nokia. Nokia Confidential Information Use subject to agreed restrictions on disclosure and use.

  • Page 149: Ont Configuration File Over Omci

    9.3.1 Filename conventions Nokia provides the raw configuration files, which must be saved by the operator in a TAR file to be uploaded. TAR file names must be unique. The filenames of the raw configuration files may not adhere to the naming conventions outlined below.
  • Page 150 XMLXXXXXX1 Configure equipment interface pland-cfgfile2=XMLXXXXXX2 and dnload-cfgfile2 XMLXXXXXX2 Although the OLT permits the above two steps without reporting an error, Nokia does not recommend executing them, because the ONT may exhibit unexpected behavior. f. If pland-cfgfileX=Auto and dnload-cfgfileX= Auto The OLT will download the XML file from "sw-ctr-list" (configure equipment ont sw-ctrl)
  • Page 151 Generate the TAR file to be uploaded to the OLT. Using the raw configuration file(s) provided by Nokia, generate the TAR file as follows: a. On a Linux platform, rename the raw configuration file to adhere to the naming convention, as described in section 9.3 “Supported configuration file types”...
  • Page 152 XMLXXXXXX1 Configure equipment interface pland-cfgfile2=XMLXXXXXX2 and dnload-cfgfile2 XMLXXXXXX2 Although the OLT permits the above two steps without reporting an error, Nokia does not recommend executing them, because the ONT may exhibit unexpected behavior. f. If pland-cfgfileX=Auto and dnload-cfgfileX= Auto The OLT will download the XML file from "sw-ctr-list" (configure equipment ont sw-ctrl)

Table of Contents
