Adding the Intercom Setup in Protege GX

1. Log in to your Protege GX system.
2. Navigate to Expanders | Keypads and select the controller the intercom will connect to.
3. Click Add and enter a Name that describes the intercom.
4. Assign the intercom an available Physical Address.
5. In the Commands section add the command:
If the default IP of the intercom has changed, update the IP address in the above command accordingly.
6. Click Save. The Configure Module pop-up window will be displayed.
7. Set the Inputs to 1, Outputs to 0 and check Add Trouble Inputs, then click Add Now.
8. Navigate to Programming | Inputs and assign Areas And Input Types to the keypad's input record as
required, then click Save.
9. Navigate to Sites | Controllers and select the controller the intercom is connected to. In the Commands
section add the following command:
10. When the controller download is complete, right click the controller and select Module Addressing.
11. In the pop-up window, locate the new
12. Check that the Registered

Adding the Intercom Setup in Protege WX

1. Log in to your Protege WX system.
2. Navigate to Expanders | Keypads.
3. Click Add and enter a Name that describes the intercom.
4. Assign the intercom an available Physical Address.
5.
In the Commands section add the command:
If the default IP of the intercom has changed, update the IP address in the above command accordingly.
6. Click Save.
7. Navigate to Programming | Inputs and create a record for the intercom's input.
8. Set the Module Address to the keypad address assigned above.
9. Assign Areas And Input Types as required, then click Save.
10. Navigate to System | Settings.
11.
In the Commands section add the following command:
12. Click Save.
Intercom keypad records can also be added via the Expanders Wizard, however it will not
intercoms so they will need to be added manually as
PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual
IPICV2_IP=192.168.1.128
IPICV2=1
Keypad record, identified by the Address assigned above.
and Online columns display True. If so the intercom is successfully connected.
IPICV2_IP=192.168.1.128
Additional
IPICV2=1
Modules.
Auto Detect the
