3. Location of the labels

Take a close look at the labels found in the following locations.
10
1.
6.
2.
4.
3.
9.
7.
8.
Caution
If any label is worn/damaged or peeled during use, immediately purchase and apply a new
one correctly.
5.
8
No. Type
1. Danger/warning label
2. Caution/inspection label
3. Nameplate
4. M-side safety device label
5. S-side safety device label
6. Restraint device label
"Lift up/down" indication label
7.
"Hook engaged/disengaged"
8.
indication label
M-side chain safety device
9.
label
Wiring label
10.
*Car washing lifts only
Remarks
Also indicates the lifting
capacity.
Used for the lowering stop
hook and the chain break
safety device.
Used for the chain break
safety device.
Used for wiring
(earthing/earth leakage
breaker)
