Chapter 7: Functional description
1
Hopper volume
2
Total volume
Total volume + 1.7 L flask
AlSi10Mg
Ti6Al4V
SS 316L
M300
In718
CoCr
In625
Height to top of hopper
Height to top of flask
1
Volume of powder contained within the hopper only.
2 Volume of powder contained within the hopper and silo parts.
3 Mass of powder contained within Total volume + 1.7 L flask, assuming 60% packing density.
4 Height from floor to top KF flange on the hopper. Space to allow filling from powder flask will also be required.
5
Height from floor to top of 1.7 L powder flask fitted to hopper (341 mm from flask base to top of flange clamp).

7.14 Dosing silo (RenAM 500Q/S excluding Flex)

There are level sensors located in the dosing silo (Figure 13). They accurately sense the level of powder to
ensure the dosing silo is at the optimum level. When the powder level goes down to halfway, the mid-level
sensor is triggered and requests more metal powder from the load hopper. This sets off the powder sieving
and pneumatic transfer processes which deliver powder to the dosing silo. A low-level sensor, if triggered,
will alert the system that there is not enough powder, pausing the build process.
7-10
Small hopper
7.5 L
10.2 L
11.9 L
19.1 kg
31.6 kg
57.0 kg
57.8 kg
58.5 kg
59.3 kg
60.3 kg
4
2 358 mm
5
2 699 mm
Figure 13 Dosing silo behind system panels
Medium hopper Large hopper
10.6 L 22.1 L
13.6 L 24.8 L
15.3 L 26.5 L
24.6 kg 42.6 kg
40.6 kg 70.3 kg
73.3 kg 127.0 kg
74.4 kg 128.8 kg
75.2 kg 130.2 kg
76.2 kg 132.0 kg
77.5 kg 134.4 kg
2 523 mm 2 604 mm
2 864 mm 2 945 mm
H-5800-3693
Issue 03-C
