To wire up a Gocator 2075:
1. Connect the Gocator Power to Master cordset between the Power connector and
an unused port on the Master.
2. Connect the Gocator Ethernet cordset between the LAN connector and an
Ethernet switch.
Refer to the Master 400/800 and the Master 1200/2400 sections for more information on
how to install a Master.

2.3 Software Configuration

Each sensor is shipped with the default IP address of 192.168.1.10. Before putting a
sensor into a multi-sensor system, its firmware version must match with that of the other
sensors and its IP address must be unique.
To configure a Gocator 2075 for the first time:
1. Setup the sensor's IP address.
a. Follow the steps in the Running a Standalone Sensor System section.
b. Make sure that there is no other sensor in the network with the IP address
192.168.1.10.
2. Upgrade the firmware.
a. Follow the steps in the Firmware Upgrade section.
b. Visit http://www.lmi3d.com/product/gocator-2000-family/support/files/all
download the latest firmware.
3. Setup profiling parameters.
a. Follow the steps in the Setup and Calibration chapter on how to setup
profiling parameters. Typically Trigger, Active Area and Exposure will
need to be adjusted.
