Checking The Ip Address Or The Mac Address Of The Printer; Checking The Ip Address Of The Computer - Canon PIXMA IP4000R Setup Manual

Problem
Checking the IP
address or the MAC
address of the printer
Checking the IP
address of the
computer
78
Possible Cause and Measures
To check the IP address or the MAC address of the printer, print out the printer
setup information or use BJ Network Tool.
For information on how to print out the printer network setting information,
"Printing and Initializing Network Settings" on page 67.
To display the Network Information dialog box, in the BJ Network Tool, select
Network Information from the View menu.
To check the IP address assigned to the computer, follow the procedure below.
• When using Windows XP/Windows 2000
1
From the Start menu, select (All) Programs, Accessories, and then
Command Prompt.
2
Enter "ipconfig" and press the Enter key. The IP addresses of the
network devices installed in your computer are displayed.
• When using Windows Me/Windows 98
1
From the Start menu, select Run.
2
Enter "winipcfg" in the Name text box and click OK.
Select the network device to display the IP address.
1
From the Apple menu, select System Preferences, and then Network.
2
From the Show pop-up menu, select the interface to use.
Select AirPort when using wireless LAN.
3
Select the TCP/IP tab.
The currently assigned IP address is displayed.
