Page 1: Active Speaker System
Crystal Surround Air Track (Active Speaker System) user manual imagine Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register the possibilities HW-D550 HW-D551... - Page 2 Dolby Digital for richer sound. Wireless Subwoofer Samsung’s wireless module does away with cables running between the main unit and the subwoofer. Instead, the subwoofer connects to a compact wireless module that communicates with the main unit. 3D Depth Sound The 3D sound feature adds depth and spaciousness to your listening experience.
-
Page 3: What's Included
WHAT’S inclUDED Check for the supplied accessories below. HDMi cable (A to c type) (AH39-01135A) (AH59-02330A/ 4301-000116) User Manual (AH68-02334A) ▪ The accessories may look slightly different than those pictured above. POWER TV POWER TV INFO MUTE SOUND SOUND MODE INPUT S.VOL SELECT AUTO DIMMER POWER SPK CONTROL HDMI S/W LEVEL AV SYNC... -
Page 4: Safety Information
safety information SAFETy WARningS TO REDUcE THE RiSK OF ElEcTRic SHOcK, DO nOT REMOVE THE cOVER(OR BAcK). nO USER-SERVicEABlE PARTS ARE inSiDE. REFER SERVicing TO QUAliFiED SERVicE PERSOnnEl. The lighting flash and Arrowhead within Triangle Is a warning sign alerting you of dangerous voltage Inside the product COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO WARNING • To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. •... -
Page 5: Precautions
PREcAUTiOnS 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots are not covered. -
Page 6: Table Of Contents
contents feATuReS SAfeTy InfoRMATIon geTTIng STARTeD DeSCRIpTIonS ReMoTe ConTRol ConneCTIonS funCTIonS TRoubleSHooTIng AppenDIx Features What’s included Safety warnings Precautions Before reading the user’s manual Front panel Rear panel 10 Tour of the remote control 11 Installing the wall mount 12 Connecting the wireless subwoofer 13 Attaching the toroidal ferrite core to the power cord of the subwoofer 13 Installing toroidal ferrite to subwoofer 14 Use iPod/iPhone with a wireless dock cradle for iPod/iPhone (Sold Separately (HT-WDC10)) 14 How to link the wireless transmitter with the main unit 15 Connecting the Crystal Surround Air Track 17 Basic functions 17 Advanced functions 20 Software upgrade 21 Troubleshooting... -
Page 7: Getting Started
If a problem occurs, check the Troubleshooting. ( See page 21 ) copyright ©2011 Samsung Electronics Co.,Ltd. All rights reserved; no part or whole of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. Definition... -
Page 8: Descriptions
descriptions FROnT PAnEl DiSPlAy inPUT MODE SOUnD MODE VOlUME +/- POWER BUTTOn ▪ When you turn on the power of this unit, there will be a 4 to 5 second delay before it reproduces sound. Displays the current mode. Selects the HDMI, Optical, Audio or W.iPod input. Selects the sound mode. -
Page 9: Rear Panel
REAR PAnEl AU D IO IN D IG IT A A U D IO IN 2 O P T IC A D IG IT A A U D IO IN 1 (T V ) USB PORT (FOR S/W UPDATES Only) AUDiO in JAcK DigiTAl AUDiO in HDMi OUT JAcK HDMi in 1,2 JAcKS POWER SUPPly cABlE ▪... -
Page 10: Remote Control
(Standard, MAX, MIN). ▪ The remote control can operate TVs made by SAMSUNG only. ▪ Depending on the TV you are using, you may not be able to operate your TV with this remote control. -
Page 11: Connections
connections inSTAlling THE WAll MOUnT You can use the wall mount bracket to mount this unit on a wall. Installation precautions • Do not install on a place other than a vertical wall. • For the installation, avoid a location with high temperature or humidity, or wall that cannot sustain the weight of the set. -
Page 12: Connecting The Wireless Subwoofer
cOnnEcTing THE WiRElESS SUBWOOFER The Subwoofer's linking ID is preset at the factory and the main unit and sub should link (connect wirelessly) automatically when main unit is turned on. If the link indicator does not light when main unit and subwoofer are turned on, please set the ID by following the process below. -
Page 13: Attaching The Toroidal Ferrite Core To The Power Cord Of The Subwoofer
aTTaCHInG THE TOROIDaL FERRITE CORE TO THE POWER CORD OF THE SubWOOFER If you attach a Toroidal ferrite core to the power cord of the Subwoofer, it will help to prevent RF interference from radio signals. Pull the fi xing tab of the Toroidal ferrite core to open it. Make three loops in the power cable of the subwoofer. -
Page 14: Use Ipod/Iphone With A Wireless Dock Cradle For Ipod/Iphone (Sold Separately (Ht-Wdc10))
1. Turn off your Home Theater (HW-D550, HW-D551). 2. Press the hold "3D SOUnD" button on the remote control for 5 seconds. The standby light on the HW-D550, HW-D551 will blink once. 3. Connect the iPod/iPhone to the Wireless transmitter. 4. Turn on the iPod/iPhone. Press the "iD SET" button on the back of the Wireless transmitter for 5 seconds. -
Page 15: Connecting The Crystal Surround Air Track
cOnnEcTing THE cRySTAl SURROUnD AiR TRAcK HDMI is a standard digital interface for connection to such devices as a TV, projector, DVD player, Blu-ray player, set top box and more. HDMI removes any loss of signal from analog conversion, enabling you to enjoy video and audio sound quality as it was originally created in the digital source. - Page 16 cOnnEcTing THE cRySTAl SURROUnD AiR TRAcK This section explains two ways (digital and analog) of connecting the unit to the TV. This unit is equipped with two optical digital jacks and one audio analog jack for connecting a TV. AUDIO IN A U D IO IN DIGITAL AUDIO IN 1, 2 D IG IT A A U D IO...
-
Page 17: Basic Functions
functions bASIC funCTIonS Turning the power on/off POWER TV POWER POWER TV POWER TV INFO 1. Touch poWeR ( MUTE SOUND TV INFO SOUND MODE INPUT S.VOL SELECT AUTO DIMMER POWER Press poWeR on the remote control to turn on the power. MUTE SPK CONTROL HDMI... - Page 18 ▪ When you choose the Sound Mode (except PASS), the 3D Depth Sound will automatically be turned OFF. ▪ The remote control can operate TVs made by SAMSUNG only. AUTO POWER linK POWER LINK ON POWER LINK OFF ▪...
-
Page 19: Using The Dimmer Function
POWER TV POWER TV INFO MUTE SOUND SOUND MODE using the AV SynC function POWER TV POWER INPUT S.VOL SELECT TV INFO Video may look slower than the audio if it is connected with digital TV. AUTO MUTE DIMMER POWER POWER TV POWER If this occurs, adjust the audio delay time to match the video. -
Page 20: Software Upgrade
POWER TV POWER INPUT S.VOL SELECT TV INFO AUTO MUTE DIMMER POWER Anynet+ is a function that enables you to control other Samsung Devices with SOUND SOUND MODE your Samsung TV's remote control. INPUT S.VOL SPK CONTROL HDMI SELECT AUTO... -
Page 21: Troubleshooting
troubleshooting Before requesting service, please check the following. Symptom The unit will not turn on. A function does not work when the button is pressed. Sound is not produced. Picture does not appear on a TV when the function is selected. Remote control does not work. The sound from the left/right channels is reversed. check • Is the power cord plugged • Connect the power plug to into the outlet? the outlet. • Is there static electricity in •... -
Page 22: Appendix
* S/N ratio, distortion, separation and usable sensitivity are based on measurement using AES (Audio Engineering Society) guidelines. *: Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. AC 120V, 60Hz 0.75W... - Page 23 SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the responsibility of the purchaser.
- Page 24 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Area Contact Center ` North America Canada 1-800-SAMSUNG (726-7864) www.samsung.com Mexico 01-800-SAMSUNG (726-7864) www.samsung.com U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com...
- Page 25 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT WRITE Samsung Electronics America, Inc. 1-800-SAMSUNG IN THE US www.samsung.com/us 85 Challenger Road Ridgefield Park, (7267864) NJ 07660-0511 Code no. AH68-02334A(00)
