1
2
1 Cover Screws
2 Top Cover
3 Screw Terminals
4 SCC Modules

Step 4. Set Up the SC-2345/SC-2350 Carrier

Procedure 1: Install the Connectors and Panelettes

Panelette
Mini-thermocouple jack
Thermocouple jack
BNC
SMB
Banana jack
SCC Quick Start Guide
11
5 Strain-Relief Panelette
6 Screw Terminal Block
7 68-Pin Shielded Cable
8 Power LEDs
Figure 5. Installing a Side Cabled SC-2345 with Configurable Connectors
The following section describes how to set up common to both the SC-2345
and the SC-2350 carriers.
If you have selected an SC carrier with configurable connectors, install the
connector and interface panelettes. Some panelettes occupy more than one
panelette slot. Table 1 lists the panelette specifications.
Table 1. Panelette Options
Description
J- or K-type
Uncompensated
J- or K-type
Uncompensated
BNC connector
SMB connector
Banana jack
3
CH
1
CH
2
10
9
9 SCC-PWRXX
10 BNC Panelette
11 SCC Connector Block Socket
Connectors/Units
per Panelette
8
4
5
6
7
8
Slot Width
2
1
2
1
1
1
1
1
2
1
4
1
2
1
ni.com
