  • Page 1 Oxygen Analyzer DF-150 E OPERATOR MANUAL...
  • Page 2 No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form, or by any means including electronic, mechanical, photocopying, recording or otherwise without prior written permission of Servomex Corporation. Stab-El and Bi-Strata are trademarks of Servomex Corporation.
  • Page 3 Your Process Oxygen Analyzer has been designed, manufactured and is supported under ISO-9001 controls, thus helping to insure the highest possible standards of quality. Every analyzer that Servomex manufactures is tested and operated on a variety of gas concentrations to insure that it functions properly when you receive it.
  • Page 4 1. Examine the condition of the packaging and its contents. If any damage is apparent, immediately notify the carrier and Servomex. Do not proceed with the installation. 2. Check the contents against the packing slip to make sure the shipment is complete.

  • Page 5: Table Of Contents

    Adjusting the Gas Scale Factor Pot for Light Gases (He or H ) .....26 7.11.2 Adjusting the Gas Scale Factor Pot for Gases Heavier Than Nitrogen...28 7.12 Panel Mount......................30 7.13 Rack Mount......................31 7.14 Remote Sensor Installations.................32 7.14.1 Sensor on Remote Bracket with Optional Pump........32 Table of Contents DF-150E...
  • Page 6 Negative Pressure Operation ..............55 12.2.4 Temperature Effects on Sensor Performance ........56 12.2.5 Flow Rate Effects on Sensor Performance ..........56 12.3 Replaceable Parts....................57 12.4 Fuse Replacement ....................58 Shipping the Analyzer ............59 DF-150E Table of Contents...

  • Page 7: Table Of Figures

    Figure 26: Remote Sensor Connector Pin-out ..........44 Figure 27: Pump Control Connector ............. 45 Figure 28: Calibration Controls ..............49 Figure 29: Calibration Adjustment with GSF installed ........50 Figure 30: Schematic of DF Series Oxygen Sensor ........51 Table of Figures DF-150E...

  • Page 8: Cautions

    There are a number of warnings and cautions that must be observed to avoid damage to the analyzer as well as insuring the safety of its users. The analyzer must be operated in a manner specified in this manual. Servomex cannot be responsible for direct or consequential damages that result from installing and/or operating the analyzer in a manner not described in this manual.

  • Page 9: Important Warnings

    Do not connect this Analyzer to a power source until all signal and plumbing connections are made. CAUTION This analyzer must be operated in a manner consistent with its intended use and as specified in this manual. CAUTIONS DF-150E...

  • Page 11: Specifications

    131-P5 0 to 100 ppm 131-100 0 to 1% 131-P1 0 to 50 ppm 131-50 0 to 10 ppm 131-10 DF-150E Single Range Analyzer DF-150E DF-150E Range (ppm) Range (%) Model # Model # 0 to 5,000 ppm 151-5000 0 to 25%...
  • Page 12 Overall Dimensions: 20.3cm w X 21.6cm h X 27.9cm d Weight: 6 kg Overall Dimensions: 8.0”w X 8.5”h X 11”d Weight: 15 lbs Miscellaneous Store and operate between 0°C and 45°C (32°F and 112°F). 100-120/200-240 VAC, 50-60Hz, 1.0/0.5A maximum. Nominal power consumption: 20 Watts ETLc Approved DF-150E Specifications...
  • Page 13 Figure 1: DF Series Oxygen Analyzer Specifications DF-150E...

  • Page 15: Analyzer Start-Up Procedure

     Do not operate a trace level analyzer for more than a few minutes while exposed to air.  Do not exceed the pressure and flow limits The electrolyte is a caustic solution. Review the Material Safety Data Sheet (MSDS) on page 71 before handling the electrolyte solution. Analyzer Start-Up Procedure DF-150E...

  • Page 16: Charging The Sensor

    RE-FILL LIQUID LEVEL WITH DELTA F REPLENISHMENT SOLUTION ONLY, NOT -LECTROLYTE. AVOID SPLASHING AND DRIPPING. REPLENISHMENT SOLUTION MAY BE ADDED WHILE ANALYZER IS ON-LINE. KEEP ANALYZER IN VERTICAL POSITION WHEN FILLED WITH -LECTROLYTE. Figure 2: Major Internal Components DF-150E Analyzer Start-Up Procedure...

  • Page 17: Add Electrolyte

    You may have an optional Flow Control Valve mounted on the sensor bracket and accessible behind the door (see “Flow Control Valve” on page 24). For gas pressures above 5 psig use a high quality pressure Analyzer Start-Up Procedure DF-150E...

  • Page 18: Gas Connection

    5.3 Making Output Signal Connections The following considerations are important when performing this step:  The analog output signal is factory-set to 0 to 10 VDC unless otherwise specified. DF-150E Analyzer Start-Up Procedure...

  • Page 19: Powering Up The Analyzer

    5. Turn the analyzer on using the power switch. See Figure 5 6. Allow several minutes for the analyzer to come “on range”. 7. Progressively switch to a lower range as the reading allows. Figure 4: Sensor Off Switch Analyzer Start-Up Procedure DF-150E...

  • Page 20: Additional Capabilities

     Gas Scale Factor Also, see the Outputs and Remote Connections section on page 41 for information regarding:  CE Qualified Analyzer Outputs  Remote Sensor Operation  Remote Pump Operation  Remote Control of On-board Pump DF-150E Analyzer Start-Up Procedure...

  • Page 21: Standard Features

    The indicator marked Electrolyte will light if the electrolyte level falls too low or, in some cases, becomes contaminated. If the electrolyte is low, simply add Hummingbird Brand Replenishment Solution to the sensor. Do not add more electrolyte after the initial bottle is installed! Figure 6: Electrolyte Condition Indicator Standard Features DF-150E...

  • Page 22: Analog Output

    The analog output is proportional to the oxygen reading of the analyzer. The analog output on a three range analyzer will be scaled to the “selected” range. Figure 7: Analog Output Setting DF-150E Standard Features...

  • Page 23: Options

    One percent is equivalent to 10,000 ppm. Table 2: Maximum Acid Gas Concentrations with Stab-El (in ppm) Contact Servomex for recommendations on using the Stab-El sensor on acid gases other than those listed above. If the acid gas components in your gas exceed the limits in Table 2 several approaches can be taken: ...

  • Page 24: Alarms

    In the “No Alarm” condition the NC contact is connected to the C contact. In the “Alarm” condition the NO contact is connected to the C contact. If the analyzer is equipped with a Low Flow Alarm (see page 23), it will be wired to Alarm 1. DF-150E Options...

  • Page 25: Pressure Regulators

    Not to be used for switching AC voltage. 7.3 Pressure Regulators The Standard Regulator is rated for 3000 psig inlet pressure. The Absolute Regulator is rated to 1000 psig inlet pressure. All brackets and plumbing are provided with this option. Figure 9: Regulator Installation Options DF-150E...

  • Page 26: Filter

    7.4 Filter The Gas Sample Particle Filter is mounted externally and upstream of the sensor. The following filter elements can be purchased from Servomex. Filter Element Part Number Fine grade (BQ) (< 1 micron) 64005012 Standard grade (DQ) (> 1 micron)

  • Page 27: Low Flow Indication

    When a low flow alarm occurs the oxygen sensor power is automatically disconnected. The sensor power will be automatically reconnected when the flow is restored to normal. Analyzers equipped with this modification also have the Low Flow Alarm installed as described above. Options DF-150E...

  • Page 28: Flow Control Valve

    If the pump is not in use, (positive pressure application) always control the gas flow with an upstream valve or regulator and leave all down stream valves wide open. DF-150E Options...

  • Page 29: Pump Control

    (and reach the measurement electrode) than through nitrogen. The scale factor option allows the analyzer to automatically correct the oxygen reading for this background gas effect. Correspondingly, if the background gas has a higher molecular size and weight than nitrogen the concentration of Options DF-150E...

  • Page 30: Adjusting The Gas Scale Factor Pot For Light Gases (He Or H 2 )

    (depending upon the configuration ordered). For gases heavier than Nitrogen the specific gas must be specified at time of order, and many heavy gases may be accommodated, with a few limitations. Consult Servomex, prior to ordering, for details. The scale factor adjustment control will be labeled with the factory configured scale factor (example: % N in Ethylene).
  • Page 31 Disclaimer The method used to correct the calibration of the Servomex Oxygen Analyzer for measurement in non-nitrogen background gases is derived from a well known theoretical mass transfer equation. This equation accounts for the change in oxygen diffusion rates through different gases.

  • Page 32: Adjusting The Gas Scale Factor Pot For Gases Heavier Than Nitrogen

    5) Once the toggle switch lever is released allow ten seconds for the analyzer to return to normal operation. NOTE: During this ten second timeout period if the switch is thrown upward again the display will not show the scale factor value. DF-150E Options...
  • Page 33 Sulfur Hexaflouride (SF6) 1.84 2.27 2.06 2.27 1.56 Freon 318 (C4F8) 2.54 3.31 2.93 3.31 2.03 Tetraflouromethane (CF4) 1.61 1.91 1.76 1.91 1.40 Carbon Monoxide (CO) 1.01 1.02 1.01 1.02 1.01 Table 4: Gas Scale Factor Correction Values Options DF-150E...

  • Page 34: Panel Mount

    7.12Panel Mount Figure 14: Panel Mount Dimensions and Layout Figure 15: Panel Mount Cut-out Dimensions DF-150E Options...

  • Page 35: Rack Mount

    7.13Rack Mount Figure 16: Rack Mount Dimensions and Layout Figure 17: Double Rack Mount Dimensions and Layout Options DF-150E...

  • Page 36: Remote Sensor Installations

    Refer to Table 6 and Table 7 for wire sizes and lengths. Following are three remote sensor configurations and wiring diagrams. Contact Servomex for additional information on remote sensor installations. CAUTION Always use a backing wrench when connecting the gas sample line to a remote sensor.

  • Page 37: Sensor In Nema 7 Enclosure

    Figure 19: Remote Sensor Bracket Mounting Holes 7.14.2 Sensor in NEMA 7 Enclosure Figure 20: NEMA 7 Remote Sensor Enclosure and Wiring Pin-out Options DF-150E...
  • Page 38 Ø.44 [Ø11.11] THRU CONTROL VALVE 4 PL (OPTIONAL) SAMPLE OUTLET 1/4" COMPRESSION 8.50 [215.90] 9.75 [247.65] 11.00 [279.40] 7.25 [184.15] 2.50 [63.50] 2.50 [63.50] 9.00 [228.60] 3.00 [76.20] 10.25 [260.35] 8.38 [212.73] Figure 21: NEMA 7 Enclosure Mounting Detail DF-150E Options...

  • Page 39: Sensor In Nema 4 Enclosure

    SENSOR VALVE SAMPLE SAMPLE INLET OUTLET SIGNAL OUTPUT 7.42 [188.58] 4.71 [119.75] 2.96 [75.30] 2.96 [75.25] 1.23 [31.36] 1.93 [49.02] AC POWER 2.75 [69.85] 7.00 [177.80] 9.00 [228.60] Figure 22: NEMA 4 Remote Sensor Enclosure and Wiring Pin-out Options DF-150E...

  • Page 40: Temperature Control In R4/R7 Enclosures

    See Figure 23 Turn it clockwise to increase the temperature and counter-clockwise to decrease it. After each adjustment re-cover the enclosure and allow at least an hour for it to stabilize at the new temperature. Figure 23: NEMA 7 Enclosure Temperature Control DF-150E Options...

  • Page 41: Sample Gas And Plumbing Cautions

    There are several issues to be aware of during the installation and operation of any gas analyzer. Contact Servomex for specific sample conditioning recommendations. 8.1 Normal Operating Conditions Note: Sample pressure and temperature measured at sensor inlet...

  • Page 42: Temperature

    “on-range”. If the exposure is prolonged, it may take as long as 12 to 24 hours for the residual oxygen to fully purge. DF-150E Sample Gas and Plumbing Cautions...

  • Page 43: Reactivity With Koh Electrolyte

    For applications containing modest amounts of acid gases, the STAB-EL sensor can be used See page 19 for details. Sample Gas and Plumbing Cautions DF-150E...

  • Page 45: Outputs And Remote Connections

     The Remote Sensor connector is not available on the DF-130 or on CE Qualified DF-150 analyzers.  The Pump connector is optional, and is not available on CE Qualified analyzers. Figure 24: Rear Panel Connections Outputs and Remote Connections DF-150E...

  • Page 46: The I/O Connector

    5 Amps resistive load. 9.1.1.3 CE Qualified Analyzers Each alarm has an SPDT relay rated at 30 VDC at 5 Amps. Exceeding this rating may cause damage to the analyzer. Not to be used for switching AC voltage. DF-150E Outputs and Remote Connections...

  • Page 47: To 20 Ma Isolated Output (4-20+, 4-20-)

    The Remote Range Indication is a contact closure between Range Com and the selected range with the lowest range being contact #1 and the highest range being contact #3. The contacts are rated at 24 VDC, .5 Amps. Outputs and Remote Connections DF-150E...

  • Page 48: Sensor Off (Sensor Off Com, Sensor Off)

    If the sensor is located remotely from the analyzer, it should be wired through a shielded, twisted pair cable of sufficient size for the required run. The shield should be terminated at the Ground stud on the rear of the analyzer. To avoid DF-150E Outputs and Remote Connections...

  • Page 49: Secondary Electrodes (Sec El +, Sec El -)

    The specific analyzer configuration is indicated on the label above the pump control connector. An on-board pump can always be controlled by the pump switch located behind the front door. Outputs and Remote Connections DF-150E...

  • Page 50: Analyzer Control Of A Remote Pump

    The pump connector will have 110 VAC present even if the analyzer is running on 220 VAC. The pump connector is intended to power the Servomex 5 watt pump only. The pump control wires should be in a shielded cable (separate from the sensor signal) with the shield attached to the ground stud on the back of the analyzer.

  • Page 51: Maintenance And Calibration Checks

    10 Maintenance and Calibration Checks 10.1Sensor Maintenance Servomex analyzers require no routine maintenance other than the occasional addition of Servomex Hummingbird Brand Replenishment Solution to the sensor. Exposure to dry gas samples will gradually extract liquid from the sensor. Under these conditions, the frequency of solution additions will be slightly higher.

  • Page 52: Calibration

    10.2Calibration All Servomex analyzers are calibrated with certified gas standards at the factory prior to shipment. No additional calibration is required before use. Depending on the application, the span calibration should be checked approximately every twelve months using a gas of known concentration and high quality plumbing components.

  • Page 53: Adjusting Calibration (With The Gas Scale Factor Option Installed)

    10.2.2 Adjusting Calibration (with the Gas Scale Factor Option installed) For analyzers that have Scale Factor installed, the Span calibration potentiometer is located to the right of the Sensor Off switch. Maintenance and Calibration Checks DF-150E...

  • Page 54: Cleaning The Analyzer

    Before attempting to clean the analyzer, turn off all power and unplug the cord. Clean the outside of the enclosure with a soft cloth dampened slightly with water. Avoid the use of solvents or ammonia based cleaners. DF-150E Maintenance and Calibration Checks...

  • Page 55: Theory Of Operation

    11 Theory of Operation The Servomex Coulometric Sensor uses an ambient temperature oxygen reaction that is non-depleting. The cell produces a current flow that is determined by the number of oxygen molecules that are reduced at the cathode. The sensor reaction is driven by 1.3 Volts applied across the electrodes.

  • Page 57: Troubleshooting

    5. Analyzer reads 0.00 or less at all times D H K L 6. Slow speed of response G C D E L 7. Electrolyte residue visible on the sensor 8. Electrolyte Condition indicator ON Table 8: Problems and Observations Troubleshooting DF-150E...

  • Page 58: Remedy Table

    For example, if the analyzer is calibrated for nitrogen, a helium sample gas will not be measured accurately. Be sure Sensor Off switch is not pushed in. Contact your local Servomex Business Center for assistance. Table 9: Possible Solutions DF-150...

  • Page 59: Troubleshooting Considerations

    If there is a valve or regulator up stream of the analyzer, it should be kept fully open and flow rate adjustments should be made with the downstream flow control valve in the flowmeter. NOTE All negative pressure flow control must be accomplished downstream of the sensor. Troubleshooting DF-150E...

  • Page 60: Temperature Effects On Sensor Performance

    As a result, if the analyzer is recalibrated at lower than normal flow rates, the new flow rate must be held within +/- 10%. The normal insensitivity of Servomex sensors to flow rate changes is the basis for the Flow Sensitivity Leak Check Method described in the section on Leaks found on page 38.

  • Page 61: Replaceable Parts

    Hummingbird Brand Replenishment Solution – 100ml 210515 Hummingbird Brand Replenishment Solution – 0.5l 210514 Hummingbird Brand Replenishment Solution – 1.0l 210513 Hummingbird Brand Replenishment Solution – 2.0l 210516 Ribbon Cable – Display to Main PCB 210385 Sensor Call Servomex Table 11: Replaceable Parts Troubleshooting DF-150E...

  • Page 62: Fuse Replacement

    12.4Fuse Replacement DANGER The instrument power switch must be in the OFF position and the power cord unplugged before removing the fuse holder cap. Failure to do so may expose the operator to hazardous voltages. All fuses within the analyzer are user replaceable. The main power fuse is located on the rear panel above the AC power connector.

  • Page 63: Shipping The Analyzer

    13 Shipping the Analyzer If it becomes necessary to ship the analyzer for service contact your local Servomex Business Center to obtain a Return Material Authorization (RMA) number. Be sure to mark the Return Material Authorization number on the outside of the shipping carton and on the packing list.
  • Page 64 13. Screw the lid securely onto the sensor. Re-install the Sensor 1. Carefully slide the sensor into the analyzer a few inches. 2. Re-connect the quick disconnect at the top of the flowmeter. (Skip this step if the analyzer is equipped with the stainless steel outlet tubing option.) 3.
  • Page 65 The sensor may be damaged if exposed to high levels of oxygen, for example air, for long periods of time (>15 minutes) while on power. If an exposure is unavoidable, turn off power to the sensor or the instrument. Safety and Operating Notices DF-150E...
  • Page 66 General Warnings  Do not expose this equipment to rain or water spray unless it is housed in a rated NEMA 4 enclosure.  Do not operate this analyzer above 45°C (113°F).  Do not expose this analyzer to temperatures above 50°C (122°F). ...
  • Page 67 (>15 min) a niveles altos de oxígeno, por ejemplo aire, mientras que esté encendido. Si no se puede evitar que uno este expuesto a esto, apague la corriente eléctrica del instrumento.. Safety and Operating Notices DF-150E...
  • Page 68 Avisos Generales  No exponga este instrumento a la lluvia ni a alguna rociada de agua, almenos que esté encerrado en una caja clasificada como NEMA 4.  No use este analizador en temperaturas más altas de 45°C (113°F).  No exponga el analizador a temperaturas de mas de 50°C (122°F). ...
  • Page 69 Zeiträume sind. Die Sensoren können beschädigt werden, wenn sie hohen Sauerstoffniveaus, bzw. Luft, für längere Zeiträume (> 15 Minuten) ausgesetzt werden, während sie eingeschaltet sind. Schalten Sie den Strom an dem Gerät ab, wenn dieses Ausgesetztsein unvermeidlich ist. Safety and Operating Notices DF-150E...
  • Page 70 Allgemeine Warnhinweise  Setzen Sie diese Geräte keinem Regen oder Wassersprühung aus, sofern dieses sich nicht in einer NEMA-4-geprüften Hülle befindet.  Bedienen Sie diesen Analysator nicht bei über 45 Grad Celsuis (113 Grad Fahrenheit).  Setzen Sie diesen Analysator keinen Temperaturen über 50 Grad Celsuis (122 Grad Fahrenheit) aus.
  • Page 71 être endommagés s’ils sont exposés à des haut niveau d’oxygène, c’est a dire, de l’air, pendant de longues périodes (>15 minutes) lorsque reliés au courant. Si l’exposition est inévitable, coupez le courant qui les relie à l’instrument. Safety and Operating Notices DF-150E...
  • Page 72 Precautions à prendre en general  Ne pas exposer l’appareillage à l’eau de pluie ou d’arrosage, à moins qu’il ne soit enfermé dans un enclos classifié: NEMA 4”.  Ne pas opérer cet analyseur à une temperature au dessus de 45°C (113°F). ...
  • Page 73 (più di 15 minuti) quanto collegati alla corrente electrica. Se l’esposizione è inevitabile, si dovrebbe disinserire lo strumento dalla corrente. Safety and Operating Notices DF-150E...
  • Page 74 Precauzioni da prendere in generale  Non si deve esporre l’apparecchiatura all pioggia o ai getti d’acqua, a meno che essa sia involta in una chiusura stimata al livello” “NEMA 4”.  Non si deve operare l’analizzatore ad una temperature al di là di 45°C (113°F).
  • Page 75 Hummingbird Brand Electrolyte Solution, E-lectrolyte Gold, Trade Name E-lectrolyte Blue, E-lectrolyte Black, DF-E05, DF-E06, DF- E07, DF-E09 Manufacturer Servomex Corp., 4 Constitution Way, Woburn, MA 01801-1087, USA, Tel + 1-781-935-4600 USA: 1-800-424-9300 Emergency Contact International: 1-813-979-0626 (collect) Supplier and contact in UK (for use in the UK only) 2.
  • Page 76 Skin Contact In case of skin contact, remove contaminated clothing and shoes immediately. Wash affected area with soap or mild detergent and large amounts of water for at least 15 minutes. Obtain medical attention immediately. Eye Contact If the substance has entered the eyes, wash out with plenty of water for at least 15 - 20 minutes, occasionally lifting the upper and lower lids.
  • Page 77 Draize test, rabbit, skin: 50 mg/24H Severe Oral, rat: LD50 = 273 mg/kg Carcinogen Status CAS# 7732-18-5 Not listed by ACGIH, IARC, NIOSH, NTP, or OSHA CAS# 1310-58-3 Not listed by ACGIH, IARC, NIOSH, NTP, or OSHA Safety and Operating Notices DF-150E...
  • Page 78 Potassium Hydroxide Solution is a severe eye, mucus membrane, and skin irritant. 12. Ecological Information Completely soluble in water Mobility Will degrade by reaction with carbon dioxide from the atmosphere to produce a Degradability non-hazardous product. Accumulation Ecotoxicity Information not available. No long-term effects expected due to degradation. The preparation is already in dilute solution and adverse aquatic effects are not expected due to further dilution.
  • Page 79 Classified in accordance with the hazard criteria of the Controlled Products Regulations and the MSDS contains all of the information required by those regulations. CAS# 1310-58-3 Listed on the Canadian Ingredient Disclosure List Canadian Ingredient Disclosure List Safety and Operating Notices DF-150E...
  • Page 80 14.4Material Safety Data Sheet – Replenishment Solution 1. IDENTIFICATION OF THE SUBSTANCE Hummingbird Brand Replenishment Solution, RS-A Trade Name Manufacturer Servomex Corp., 4 Constitution Way, Woburn, MA 01801-1087, USA, Tel + 1-781-935-4600 USA: 1-800-424-9300 Emergency Contact International: 1-813-979-0626 (collect) Supplier and contact in UK (for use in the UK only) 2.
  • Page 81 Physical State 6.0-8.0 Solubility Complete (100%) Boiling Point Melting Point Flash Point Not applicable Not flammable Flammability Not applicable Explosion Limits Specific Gravity 1.00 Vapor Pressure 17.5 mm Hg @ 20 10. Stability & Reactivity Safety and Operating Notices DF-150E...
  • Page 82 Chemical Stability Stable Conditions/Materials to Avoid Strong reducing agents, acid chlorides, phosphorus trichloride, phosphorus pentachloride, phosphorus oxychloride. Hazardous Decomposition Products Not applicable. Has not been reported Hazardous Polymerization 11. Toxological Information Toxicity (water) CAS# 7732-18-5: Oral, rat: LD50 >90 mL/kg Carcinogen Status Not listed by ACGIH, IARC, NIOSH, NTP, or OSHA 12.
  • Page 83 15 Warranty Servomex Corporation warrants each instrument manufactured by them to be free from defects in material and workmanship at the F.O.B. point specified in the order, its liability under this warranty being limited to repairing or replacing, at the Seller's option, items which are returned to it prepaid within one year from delivery to the carrier and found, to the Seller's satisfaction, to have been so defective.
  • Page 85 Cleaning the Analyzer, 50 Remote Sensor, 44 Draining the Sensor, 59 Sample Gas, 13 Fuse Replacement, 58 Sensor, 59 Replaceable Parts, 57 coulometric, 51 Restoring electrolyte level, 47 Shipping the Analyzer, 59 Material Safety Data Sheet - Electrolyte, 71 Index DF-150E...
  • Page 86 Material Safety Data Sheet – Replenishment Pump Control, 45 Solution, 76 Pump Control, 25 purge, 15 NEMA 4, 35, 62 NEMA 7, 33 Rack Mount, 31 Range, 43 Remote Operation, 32, 41 Remote Range Indicator, 43 Remote Sensor, 32, 44 Operating Conditions, 37 NEMA 4, 35 Options, 19...
  • Page 87 15 Upsets Oxygen Shock, 44 Warranty, 79 Voltage, 15, 46 Index DF-150E...
