COMPACT SERIES | COMPACT70
Installation & Operation Instructions
The Santa Fe Compact70 is designed for
superior basement and crawl space
dehumidification. Tight spaces are no problem
for the Santa Fe Compact70 dehumidifier. Its
compact size works perfect in low crawl spaces
and small basements without sacrificing power
and performance. Designed to fit in a variety of
small spaces, the Compact70 provides multiple
installation options for greater flexibility.
Santa-Fe-Products.com | 800.533.7533
Part Number
4033600
Serial Number
Install Date
Sold By
MA DISON, WI
TS-1082 6/18 Rev A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Santa Fe COMPACT70
Summary of Contents for Santa Fe COMPACT70
- Page 1 COMPACT SERIES | COMPACT70 Installation & Operation Instructions The Santa Fe Compact70 is designed for Part Number 4033600 superior basement and crawl space Serial Number dehumidification. Tight spaces are no problem Install Date for the Santa Fe Compact70 dehumidifier. Its...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions ..................3 Intended Applications ................3 Registrations ....................3 Specifications ..................4 Dehumidifier Set Up .................5 Items Included In Box.................5 Important Precautions ................5 Location Considerations ................5 Installing Leveling Feet ................5 Ducting to Finished Areas (Optional) ............6 Attaching Duct Collars ................6 Recommended Installations ..............7 Drain Installation ..................8 Operation ....................9... -
Page 3: Safety Instructions
Intended Application(s) The Santa Fe Compact70 is intended for use in crawl spaces or basements: however, the unit can be placed in almost any residential setting where dehumidification is desired. Use in non-residential applications and pool areas may void warranty. -
Page 4: Specifications
4027415 8" Flex Duct 25' 4020177 8" Flex Insulated Duct 25' FRONT FRONT BACK 4020175 Remote Dehumidistat Santa Fe Compact70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533 W/ OUT C OLLARS WITH C O LLARS Width: 12" 12" 15 5/8"... -
Page 5: Dehumidifier Set Up
Important Precautions • Do not install the Santa Fe Compact70 with the intake or exhaust of the unit within 1' of a wall or other obstruction. Avoid directing the discharge air at people. The dehumidifier should be used in the upright position. -
Page 6: Ducting To Finished Areas (Optional)
8" Supply Air Outlet 8" Supply Air Outlet 8" Supply Air Outlet Front View Rear View Front View Rear View Front View Rear View Front View Rear View Top View Top View Santa Fe Compact70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533... -
Page 7: Recommended Installations
• Place the Santa Fe Compact70 in the unfinished area of the basement, near a drain access (condensate will • Place the Santa Fe Compact70 in the unfinished area of drain via gravity or with an optional pump kit). the basement, near a drain access (condensate will drain •... -
Page 8: Drain Installation
Pitch of drain should be 1" per 10'. An optional condensate pump kit is available for use with the Santa Fe Compact70 and may be installed if lift is required to dispose of condensate. Condensate is automatically pumped to a remote location when the water level in the pump’s reservoir rises to close the float switch. -
Page 9: Operation
This function is desirable if the unit is used for air circulation or filtration. Turning the fan switch to “FAN AUTO” will cause the unit’s internal blower to run only while the unit is dehumidifying. 800.533.7533 | Santa-Fe-Products.com Santa Fe Compact70 Installation & Operation Instructions... -
Page 10: Air Filtration
Air Filtration The Santa Fe Compact70 is equipped with a pre-filter and a MERV-13 air filter. An optional MERV-8 or MERV-11 filter is available at www.thermastorfilters.com. The filters should be checked and replaced every three to six months. Operating the unit with a dirty filter will reduce dehumidifier capacity and efficiency. -
Page 11: Merv Rating Chart
Washable - Aluminum Mesh. <20% 70-75% Dust Mites Residential Sanding Dust <20% 65-70% Spray Paint Dust Electrostatic - Self charging Textile Fibers Window A/C Units woven panel filter. <20% <65% Carpet Fibers http://www.mechreps.com/PDF/Merv_Rating_Chart.pdf 800.533.7533 | Santa-Fe-Products.com Santa Fe Compact70 Installation & Operation Instructions... -
Page 12: Electrical Requirements
The unit should not be used in areas prone to flooding. Consult local electrical codes for any further information. An optional remote dehumidistat is available for use with the Santa Fe Compact70 and is to be located remotely from the dehumidifier. -
Page 13: Service
Service WARNING! SERVICING THE SANTA FE COMPACT70, WITH ITS HIGH PRESSURE REFRIGERANT SYSTEM AND HIGH VOLTAGE CIRCUITRY PRESENTS A HEALTH HAZARD WHICH COULD RESULT IN DEATH, SERIOUS BODILY INJURY, AND/OR PROPERTY DAMAGE. ONLY QUALIFIED SERVICE PEOPLE SHOULD SERVICE THIS UNIT. - Page 14 7. Collecting the water removed in a 24 hour period will give a measurement of performance. Santa Fe Compact70 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533...
-
Page 15: Warranty
Warranty Limited Warranty. Therma-Stor, LLC (“Therma-Stor”) warrants as follows: (i) the Santa Fe Compact70 dehumidifier (“Product”) will be free of material defects in workmanship or materials for a period of 2 years (“Two-Year Warranty”) following the date of initial purchase of such Product by an original customer purchasing from Therma-Stor or an authorized reseller (“Customer”);... - Page 16 D E H U M I D I F I E R S Santa-Fe-Products.com 800.533.7533...
