TORO™ LOW PROFILE INSTRUCTION MANUAL
a. Congratulations
b. Pictures of Components
c. Family Info
d. How to Fill with Line
e. Drag Adjustment
f. Spool Tension Knob
g. Removing the Sideplate
h. Reel Function
i. Maintenance
j. Revo® Shop Accessories
k. Warranty Information
A. CONGRATULATIONS:
Thank you for purchasing one of the world's most advanced low-profile reels. The combination
of low profile design, ultra-lightweight materials and precision engineering makes Abu Garcia®
THE choice for serious anglers around the globe. These reels are widely used by pros on the
tournament circuit, guides, record seeking experts and anglers who demand the very best from
their equipment. Rely on Abu Garcia® quality and dependability to keep the fun in fishing.
The following guide will explain how to get the most out of your new Revo® low profile reel.
Each element is described by its name and function. Some features are not found on every reel
model. Read these instructions carefully before using your reel to ensure a proper understanding
of its operation.
B. COMPONENTS:
Include:
Star drag
Palm Sideplate
Handle Sideplate
Maintenance Port Screw
Line guide
Thumbscrew
Gear Box
Nut Retainer Screw
Handle
Spool
Knobs
Thumb Bar
Frame
Brake Dial
Trim Ring
Handle Knob Caps
Spool Tension Knob
Brake Dial
Handle Nut
Advertisement
Summary of Contents for Toro MaxToro
- Page 1 TORO™ LOW PROFILE INSTRUCTION MANUAL a. Congratulations b. Pictures of Components c. Family Info d. How to Fill with Line e. Drag Adjustment f. Spool Tension Knob g. Removing the Sideplate h. Reel Function i. Maintenance j. Revo® Shop Accessories k.
- Page 3 The new ergonomic design delivers greater line capacity, high max drag and the ability to fish larger baits. The Toro™ family of low profile reels include the MaxToro™, Revo® Toro™ S, Revo® Toro™ Rocket, and the Revo® Toro™ Beast.
- Page 4 G. REMOVING THE SIDEPLATE Toro™ reels are equipped with a removable palm sideplate that allows access to the spool and centrifugal brake system. To open the sideplate, turn the spool access thumbscrew counterclockwise until it disengages from the sideplate.
- Page 5 - InfiniMax™ Brake System (Toro™ Rocket, Toro™ Beast) – The InfiniMax™ brake system allows almost limitless adjustability to handle any fishing situation. It combines a sealed centrifugal brake system with a magnetic brake, giving anglers superior casting control. This is sometimes referred to as a dual brake system.
- Page 6 Turn the exterior brake dial to fine tune spool tension. Rotate the dial towards the “MAX” label to increase braking force or in the opposite direction to reduce braking force. - MagTrax™ Brake (Toro™ S, MAX Toro™) - The MagTrax™ magnetic brake delivers consistent braking pressure throughout the entire cast resulting in smooth, controlled casts.
-
Page 7: Maintenance
(picture of oil and grease points). Toro™ Reels are equipped with a main gear access door called the Maintenance Port. This feature allows anglers to easily grease the main gear without taking the reel completely apart. -
Page 8: One-Year Limited Warranty
Abu Garcia Precision Grease. Once maintenance has been completed, reposition the door over the maintenance port and reinstall the maintenance port screw. Tighten the screw with a Philips head screwdriver by rotating it clockwise. Do not over tighten. To keep your reel working at peak efficiency, clean and lubricate after each use. At least once a season your reel should be disassembled for a thorough cleaning and re-lubrication. - Page 9 (unless an Abu Garcia Authorized Center) are not authorized to make in-warranty repairs or adjustments on behalf of Abu Garcia. The terms of the Warranty cannot be changed except in writing by an officer of Abu Garcia. Abu Garcia rods or reels requiring warranty repair should NOT be returned to the store of purchase.
