Page 1 6F8C1625 Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 2 (4) All possible measures have been taken to prepare the information herein. If you have any question, comment, or find any error, please contact us. TC-net, PROSEC, TOSLINE, TOSDIC, CIEMAC are registered trademarks of Toshiba Corporation. Ethernet is registered trademarks of Fuji Xerox Co., Ltd.
Page 3 Indicates “Mandatory Action” or “Do as indicated”. Specific details are indicated near the symbol with pictures and text. Mandatory Indicates Warning. Specific details are indicated near the symbol with pictures and text. Warning Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 4 1. Safety Precautions on Installation WARNING Ground the device. Turn off the power before wiring cables Otherwise, it may cause an electric shock Ground Mandatory or fire. Otherwise, it may cause electric shock or failure. Configure the emergency stop circuit and the interlock circuit wiring module, outside the controller.
Page 5 Wipe off stain on the device, module, or board with a soft cloth. For severe stain, use a wet cloth Mandatory wrung tightly. Leaving them stained may cause wrong decision or malfunction. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 6 Mandatory device, stop using the device, turn It may cause an electric shock. off the power, and contact one of Toshiba's service representatives. Before using, check that the Using it as it is may cause fire due to power capacity, frequency, overheat.
Page 7 When disposing the product, observe the and packaging box Mandatory Mandatory ordinances and rules of the local government. Otherwise it will cause failure. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 8 (e.g. employing fool-proof design, fail-safe design, or redundant design). Disclaimer ■ Toshiba shall not be responsible for any damage caused by fire or earthquake, acts of a third party, other accidents, the user's willful acts or negligence, misuse, or use in abnormal conditions.
Page 9 6. Exercise care not to drop the product during transportation or the like. 7. FL654A complies with FL-net protocol Version 3.01 Class 1.Protocol version 3.01 Class 1 can be mixed with protocol version 2.00, but FL-net protocol version 1.00 compliant equipment and protocol version 2.00 / 3.01 class 1 compliant equipment cannot be operated on the same...
Page 10 Introduction This manual explains the function, installation and setting method, maintenance and inspection etc. of the unified controller nv series FL-net remote I / O station module FL654A (hereinafter referred to as "FL654A") doing. Be sure to read "Safety Precautions" before use in order to use the equipment properly and safely.
Page 11 In addition, we are sorry that we may carry out improvements without particular notice in order to improve performance and functions, so please be forewarned. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 12 Hardware Describes the appearance and parts of the FL654A. ・Chapter 3 System construction Describes the system configuration of FL654A and installation and wiring to start-up. ・Chapter 4 Maintenance and Inspection Describes the system inspection and replacement and disposal of modules.
Page 13: Table Of Contents
································· 28 Chapter 5 5.2 Connecting PC ······························································ 29 I/O configuration 5.3 Starting Terminal Software ············································· 29 information 5.4 Procedure for Checking I/O Configuration Information ······· 30 …27 Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 14 6.1 Setting up the Talker and Listener Areas ·························· 34 Chapter 6 6.2 Restriction on I/O Expansion ·········································· 38 Talker and Listener Areas …33 7.1 LED Indication ······························································ 40 Chapter 7 7.2 G2 I/O Module Status ···················································· 40 RAS Function 7.3 Operation in the Event of I/O Module Abnormality ·············...
Page 15 Appendix B Outside Dimensions …89 C.1 Accessories ·································································· 92 Appendix C C.2 Related Products ··························································· 93 Accessories and Related Products …91 Appendix D Decimal- hexadecimal Conversion Table …95 xiii Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 16 6F8C1625...
Page 17 Chapter 1 Overview Describes the functions and features and operations of the FL654A. Functions and Features ····················································· 2 1.1.1 Functions ···························································· 2 1.1.2 Features ····························································· 3 Input/Output and Send/Receive Operation ····························· 4...
Page 18: Functions And Features
FL654A is a remote I/O station module that connects G2 I/O module to FL-net. By using the FL654A, you can connect the G2 I/O module to the FL-net system without the controller, and update the input / output data of the remote I/O by cyclic transmission between the host controller and the remote I/O station.
Page 19: Features
(2) Cyclic transmission The FL654A can perform I / O data communication with cyclic transmission of 50 ms / 32 units and 2 K words + 2 K bits targeted for performance target of FL-net.
Page 20: Input/Output And Send/Receive Operation
Chapter 1 Overview 1.2 Input/Output and Send/Receive Operation The FL654A takes one continuous talker area and one continuous listener area in Area 1 or Area 2 of FL-net cyclic transmission common memory. The talker and listener areas are independent of one another.
Page 21 Chapter 2 Hardware Describes the appearance and parts of the FL654A. Appearance and Names of Parts ········································· 6 LED Indicators ································································· 7 RUN/HALT Switch ···························································· 8 Node Address Switches (NA-H, NA-L) ··································· 8 Mode Setting Switch (MODE) ·············································· 9 FL-net Communication Connector (FL-net) ····························· 9 Tool Connection Connector (TOOL) ·····································...
Page 22: Appearance And Names Of Parts
Operation Talker Block Listener Block Setting Head Setting Head Setting Switch Switches Switches Figure 2-1 Appearance and parts of the FL654A ■ Differences between FL654A and FL654 Table 2-1 Differences between FL654A and FL654 Differences FL654A FL654 － Mode Setting Switch...
Page 23: Led Indicators
RUN/HALT switch is HALT. for 500ms or more Indicates the link test state. The cause of turning OFF is as follows. ・ Transmission line fault On: Normal (green) (green) OFF: Abnormal Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 24: Run/Halt Switch
FL654A go down mode. Moreover, because node address setting is read when power to the FL654A is turned ON, if you wish to change the setting, turn OFF the power, change the address, and then turn ON the power again.
Page 25: Mode Setting Switch (Mode)
Indicates the send/receive status of FL-net. The cause of turning OFF is as follows. ・ Transmission line fault On: Send and received (orange) (orange) Off: Not sent or received Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 26: Tool Connection Connector (Tool)
I/O and collect RAS information by the terminal software of PC. It is used for setting and maintenance of the FL654A module by nV-Tool. For how to use it, see Chapter 5, I/O configuration information, Chapter 7, RAS Function, Chapter 8, Startup Using nV-Tool and Chapter 9, Maintenance Using nV-Tool.
Page 27: Operation Setting Switch
Figure 2-8 Operation Setting Switch This is an 8-bit DIP switch that sets up FL654A operations, and is located in the lower left side face of the module when facing the module. It is set using a small flat-head screwdriver. Because this setting is read at power-ON of the FL654A, if you wish to change the setting, turn OFF the power, change the setting, and then turn ON the power again.
Page 28: Talker Block Head/Listener Block Head Setting Switches (Tbh, Tbl, Lbh, And Lbl)
The switches are set using a small flat-head screwdriver. Because the settings are read at power-ON of the FL654A, if you wish to change a setting, turn OFF the power, change the setting, and then turn ON the power again.
Page 29 Chapter 3 System Construction Describes the system configuration of FL654A and installation and wiring to start-up. Configuration of the FL654A Remote I/O Station ····················· 14 Installation and Wiring of the FL654A Remote I/O Station ·········· 17 Connecting the Communication Cable ·································· 17 Safety Circuit ··································································...
Page 30: Configuration Of The Fl654A Remote I/O Station
The FL654A remote I/O station consists of only the basic unit, or basic unit and expansion unit. The basic unit consists of the power supply module, the FL654A, and the G2 I/O module on the dual-purpose basic and expansion base. To extend the unit, install the expansion interface.
Page 31 Standard version IF661 Cover Empty module PS600 Unit cover PS601 Expansion cable (standard version) 0.3m CS6R3 0.5m CS6R5 0.7m CS6R7 1.2m CS6R1 FL-net remote I/O station I/O station FL654A Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 32 DA672 Supplement ・ When connecting up to 32 modules of I / O, FL654A sends data size of maximum 256 words + 4 words by the number of input words and receives data size of maximum 128 words depending on the number of output words.
Page 33: Installation And Wiring Of The Fl654A Remote I/O Station
3.2 Installation and Wiring of the FL654A Remote I/O Station 3.2 Installation and Wiring of the FL654A Remote I/O Station For installation and wiring of the FL654A remote I/O station, refer to Chapter 3 of the following instruction manual. ・ " Unified Controller nv Series type1 light Controller Unit User's Manual - Basic Hardware -"...
Page 34: Safety Circuit
・ " Unified Controller nv Series type1 light Controller Unit User's Manual - Basic Hardware -" (6F8C1497) 3.5 Starting and Stopping In order to use the FL654A more safely, please set the order outside the FL654A to start (turn on the power) and stop (turn off the power). 3.5.1 Starting Turn ON the FL654A power supply and the I/O control power supply.
Page 35 Share the external power supply to the G2 I/O module with the load power supply wherever possible. If this is impossible, configure the system so that the external power supply and the load power supply turn off simultaneously. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 36: Startup Procedure
3.6 Startup Procedure There are the following two modes for I/O module input/output operations: (1) FL654A recognizes the I/O module composition when the power supply is turned on, and FL654A executes the input/output operation by this module composition. (AUTO) (2) After confirming the I/O module composition when the power supply is turned on, the user saves the I/O module composition in non-volatile memory in FL654A.
Page 37: Auto Designation Startup
I/O module configuration I/O status setting in down mode: Depends on the system. (iii) Turn ON the power. Start up Figure 3-4 AUTO designation startup procedure Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 38 Chapter 3 System Construction 6F8C1625...
Page 39 Chapter 4 Maintenance and Inspection Describes the system inspection and replacement and disposal of modules. Daily Inspection ······························································ 24 Periodic Inspection ·························································· 25 Maintenance Parts··························································· 26 Replacing Modules ·························································· 26 Disposing Modules ·························································· 26...
Page 40: Daily Inspection
・ Check that the modules are installed securely. Checking the RUN/HALT switch: RUN Change the switch to the correct position described switch position of Node address switches (NA-H, NA-L): in this manual. the FL654A module A predetermined node number Mode setting switch (MODE): All OFF 6F8C1625...
Page 41: Periodic Inspection
Check that wiring cable is not damaged No damages to cables Environment Check that the temperature, humidity, vibration, dust, etc. Within general specifications are within the specified range Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 42: Maintenance Parts
To recover from failure quickly, it is recommended to keep the following spare parts. Table 4-3 Maintenance parts Part Quantity Remarks FL654A module and Spare at least one for minimum system power supply module down-time. G2 I/O module One for each...
Page 43 Chapter 5 I/O configuration information Describes I/O configuration information setting by I/O automatic recognition function of FL654A. I/O Automatic Recognition Function ····································· 28 Connecting PC ······························································· 29 Starting Terminal Software ················································· 29 Procedure for Checking I/O Configuration Information ·············· 30...
Page 44: I/O Automatic Recognition Function
・ Operation setting switch (8-bit DIP switch): “Checks the I/O module installation status (CONF).” Then check if the information automatically recognized by the FL654A is correct according by the terminal software of the PC. Completing this check allows the I/O configuration information to be saved in the FL654A’s nonvolatile memory.
Page 45: Connecting Pc
5.2 Connecting PC 5.2 Connecting PC Connect a PC to the FL654A using the cable between the PC’s USB port and the FL654A’s TOOL connection port. (For the connection cable, see Chapter 2.) 5.3 Starting Terminal Software Start the terminal software, select the port, configure it, and configure the ASCII terminal.
Page 46: Procedure For Checking I/O Configuration Information
Chapter 5 I/O configuration information 5.4 Procedure for Checking I/O Configuration Information When entering [Enter] on the terminal software startup screen, the I / O configuration information will be displayed on the PC screen. If there is no problem with the I / O configuration information, please press [Enter] with [Y].
Page 47 SLOT(7): Y 4W Listen C2 0012W UNIT[3] SLOT(0): X 8W Talk C1 0052W Is this I/O-CONFIGURATION saved? [Yes or No] ? y saved OK! Figure 5-2 Example of the I/O Configuration Checking Screen Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 48 Chapter 5 I/O configuration information 6F8C1625...
Page 49 Chapter 6 Talker and Listener Areas Describes setting of talker and listener areas and assignment of data. Setting up the Talker and Listener Areas ······························· 34 Restriction on I/O Expansion ·············································· 38...
Page 50: Setting Up The Talker And Listener Areas
6.1 Setting up the Talker and Listener Areas The FL654A’s talker and listener areas are provided in Area 1 or Area 2 of the FL-net cyclic transmission common memory. Setup of the talker and listener areas is achieved using the talker block head/listener block head setting switches at the lower left side face of the module.
Page 51 Figure 6-2 Information of the Head of the Talker Area (a) Healthy counter This counter indicates that the FL654A performs inputs and outputs normally. When an input/output cycle is normally executed, one count is incremented. Input/output cycles vary depending on the I/O module configuration, and one count is incremented in 200 ms at worst.
Page 52 Status 2 3-8 (5) Correspondence between the I/O modules and common memory The FL654A allocates the installed I/O modules to the common memory talker and listener areas in the order of the I/O modules. Allocation is made in the ascending order of unit numbers and, in the same unit, it is made in the ascending order of slot numbers.
Page 53 Unit 1 slot 1 AD624(4W) 208h Unit 1 slot 2 DA622(2W) Unit 1 slot 2 AD624(4W) Figure 6-3 Assignment of specific example of I/O module configuration to common memory Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 54: Restriction On I/O Expansion
Chapter 6 Talker and Listener Areas 6.2 Restriction on I/O Expansion To expand I/O modules, add the module(s) after the configuration of the I/O modules already installed. This allows the I/O modules to be expanded without affecting the existing allocated I/O configuration.
Page 55 Chapter 7 RAS Function Describes the RAS function of FL654A and how to check information. LED Indication ································································ 40 G2 I/O Module Status ······················································· 40 Operation in the Event of I/O Module Abnormality ··················· 40 Operation in the Event of FL-net Failure ································ 41 LED Indication in the Event of Module Down ··························...
Page 56: Led Indication
The FL654A checks whether the I/O modules are normal or abnormal each time input/output cycle is complete. If any I/O module is detected to be faulty, the FL654A stops input to or output from such an I/O module and sets the noted module status to abnormal.
Page 57: Operation In The Event Of Fl-Net Failure
If an update of the overall listener area of the local station is stopped for more than 500 ms, the FL654A holds or clears outputs to the output modules. Selection of hold or clear is set using the operation setting switch.
Page 58: Led Indication In The Event Of Module Down
Chapter 7 RAS Function 7.5 LED Indication in the Event of Module Down Table 7-1 LED display when FL654A is down Status Format error ● ◎ ● － ● (ii) FL-network entry failure Failure of Ethernet setting (operation setting ●...
Page 59: Initial Setting
7.6 Gathering RAS information using Terminal software 7.6 Gathering RAS information using Terminal software When FL654A is operated by "LOCK" or "AUTO", RAS information on FL654A can be gathered by connecting the personal computer that operates the terminal software with the serial cable.
Page 60 DPADR Display of the detection of duplicated node number Detected (ON) / Not detected (OFF) TEST Always turning off When FL654A is down mode, the down code is displayed under "mode". Table 7-4 Down code Down code Description 0x0000 NMI occurrence...
Page 61: Version Display
SLOT( 2): X 2W Talk C1 0036W SLOT( 3): Y 2W Listen C2 0000W SLOT( 8): X 2W Talk C1 0038W SLOT( 9): Y 2W Listen C2 0002W UNIT[1] UNIT[2] UNIT[3] Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 62: In-Ring Node Map
Chapter 7 RAS Function 7.6.5 In-ring Node Map Input form DISP OLM Execution result (example) Command> disp olm Online Map FEDCBA9876543210 0 0000000011111110 node 15 … node 0 1 0000000000000000 node 31 … node 16 2 1111111111111111 3 0000000000000000 4 0000000000000000 5 0000000000000000 6 0000000000001111 7 1111000000000000...
Page 63: Common Memory Area Data
Transmission request frequency RAS_CNT[10] : 0 Nonuse RAS_CNT[11] : 0 Nonuse RAS_CNT[12] : 0 Nonuse RAS_CNT[13] : 0 Nonuse RAS_CNT[14] : 0 Nonuse RAS_CNT[15] : 0 Recovery execution frequency Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 64: Event Log
160, it is deleted from an old log. A correct value doesn't enter if time information doesn't execute the time setting (Refer to "9.1.6, Callender/Time Setting") first. When the power supply is turned on, an internal clock of FL654A starts operating from "0:0:0, January 1, 1999".
Page 65 I/O parity error (input module) 0x0003 0x0002 I/O parity error (output module) 0x0000 Join in FL-net 0x0090 0x0001 Secede from FL-net 0x0000 Listener area updating 0x00A0 0x0001 Listener area stop update Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 66: Fl-Net Log
Chapter 7 RAS Function 7.6.10 FL-net Log Input form MSTCLOG Execution result (example) Command> mstclog [Send_Recv] SendCount Total socket transmission frequency SendErr Total socket transmission error frequency EthSendErr : 0 Nonuse RecvCount Total socket reception frequency RecvErr Total socket reception error frequency EthRecvErr : 0 Nonuse [Frame]...
Page 67 Startup Using nV-Tool Describes the setup and startup procedure of the remote I/O station when operating the FL654A with "TOOL designation". In nV-Tool, FL654A and FL654 are handled as FL654. Outline of Operation ························································· 52 8.1.1 Settable Range ···················································· 52 8.1.2...
Page 68: Outline Of Operation
Figure 8-1 Setting using nV-Tool Note ・ FL654A cannot be set by way of FL-net by connecting nV-Tool with FL622 module. The item that can be set by nV-Tools is as follows. (1) FL-net transmission parameter of FL654A (2) Registration of G2 I/O module...
Page 69: Allocation Of G2 I/O Module Data To Common Memory
(1) Input module data can be allocated freely to FL654A talker area by each input module. FL654A talker area can be allocated in both area1 and area2 in FL-net common memory. (2) Output module data can be allocated freely to the areas other than FL654A talker area by each output module.
Page 70: Remote I/O Startup Procedure
654A Node Node Input Output 16pt 16pt Figure 8-2 Sample system configuration FL622 FL654A Area 1 512 Words Talker area of 5 words from address 0 Area 2 8192 Words Talker area of 1 word from address 8160 Figure 8-3 Common memory allocation of sample system...
Page 71 ・ Treat the area 1 talker area head address as "0" and the area 2 talker area head address as "512". Note ・ If transmission can not be performed due to transmission line failure, reset the minimum allowable frame interval to a value larger than the default value. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 72: About "Fl-Net Lan" And "Fl-Net Control Lan
The data that FL622 transmits is treated as data that "FL-net Control LAN Dummy station" transmits in the “FL-net Control LAN” network. The data that FL654A transmits is treated as data that "FL-net LAN Dummy station" transmits in the “FL-net LAN” network.
Page 73: Startup Flow
(Task performed with nV-Tool connected to the FL654A) Start up the module (Operation using FL654A) Figure 8-6 Startup Procedure if the Remote I/O Module is set up Using nV-Tool Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 74: System Registration Procedure
Chapter 8 Startup Using nV-Tool 8.2.4 System Registration Procedure System registration is performed off-line using nV-Tool at system design. The following describes this procedure in details. After system registration, the master station creates user programs using the network variables. Creating the system folder Create the target system folder (e.g., FL654A_TEST).
Page 75 8.2 Remote I/O Startup Procedure (3) Set the PUM12 and FL622 parameters. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 76 Chapter 8 Startup Using nV-Tool (4) Create the dummy station for the master station. The dummy station needs to be registered to use data that send from FL654A in master station. Example: (i) Register dummy station “oth_stn2(other station)” (ii) Register “FLStn” as unit and “FL_X” as module Registration of dummy station Registering the remote side (FL654).
Page 77 The dummy station needs to be registered to use data that send from FL622 in remote I/O station. Example: (i) Register dummy station “oth_stn1(other station)” (ii) Register “FLStn” as unit and “FL_Y” as module Registration of dummy station Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 78 Chapter 8 Startup Using nV-Tool Registering LAN configuration (1) Create an FL-net Control LAN folder below the Networks folder. (2) Register the FL654 and the dummy station “FL_Y” for the remote station in the “Modules” folder below the FL-net Control LAN folder. (3) Create an FL-net LAN folder below the Networks folder.
Page 79 (7) Select "Set AS Tool Communication" of FL-net Control LAN. FL654A subordinate's I/O module registration FL654A subordinate's I/O module is registered. When the check is put on "Add I/O Variable" on the Add Module window, the I/O variable that agrees with the content of the I/O module is registered.
Page 80 Registering the talker blocks Talker blocks are registered on "Scanning memory folder" of "FL-net Control LAN". Talker block of the dummy station for the remote I/O station and talker block of FL654A are registered respectively. Talker block of dummy station for remote I/O station Talker block of dummy station for remote I/O station is set to the place of FL-net common memory area allocated in FL654A subordinate's output module.
Page 81 IO01001_02 ARRAY[0..15] OF BOOL Important ・ The network variable of FL654A must be allocated as "one mass" in "module unit". ・ When the above-mentioned rule is not observed, the download of I/O configuration information becomes an error (text parameter error).
Page 82 Registering network variables The network variable is registered at every talker block. (1) Talker block registration of FL622 → FL654A data In the following example, I/O variable (=IO01001_02) output to DO633 is allocated to "Talker block: 1 (the dummy station for a remote I/O talker area in FL-net common memory area2)".
Page 83 "Listener block of dummy station for remote I/O”. After the variable of the transmission block is selected, "Allocated to the input variable" is clicked. Allocated to Input variables Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 84: Preparing Remote I/O Modules
8.2.5 Preparing Remote I/O Modules Prepares the FL654A for downloading I/O configuration information to it. (1) Preparation for download (a) Set the FL654A operation setting switch so that SW3 is ON and SW4 is OFF (TOOL designation). (b) Turn ON the power.
Page 85: Download
10 seconds or more.) 8.2.8 Starting the Module (1) DIP switch setting Set the operation setting switch of the FL654A so that SW3 is ON and SW4 is OFF. (2) Set the RUN/HALT switch to RUN. (3) Turn ON the power.
Page 86: Master Station Startup Procedure
Chapter 8 Startup Using nV-Tool 8.3 Master Station Startup Procedure The following procedure is necessary on the FL622 side besides download to FL654A. (1) Talker block is registered on "Scanning memory folder" of "FL-net LAN". The talker block of the dummy station for the master station and the talker block of FL622 are registered respectively.
Page 87 ・ The network variables must have unique name in one system. ・ The I/O variables (= network variables) on a remote I/O side cannot be used in the master side. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 88 Chapter 8 Startup Using nV-Tool 6F8C1625...
Page 89 Chapter 9 Maintenance Using nV-Tool Describes the maintenance of the remote I/O station when operating the FL654A with "TOOL designation". In nV-Tool, FL654A and FL654 are handled as FL654. Maintenance Function ······················································ 74 9.1.1 Download Function ··············································· 74 9.1.2 Memory Clear Function ········································· 75 9.1.3...
Page 90: Maintenance Function
9.1.1 Download Function The FL654A recognizes I/O configuration information that is downloaded using nV-Tool. The FL654A setup procedure is described in Chapter 8, Startup Using nV-Tool. This chapter describes the download procedure using nV-Tool. (1) Select the relevant module (FL654) in the system’s station configuration of the nV-Tool and right click on it to display a menu.
Page 91: Memory Clear Function
9.1 Maintenance Function 9.1.2 Memory Clear Function Initialize the FL654A. When FL654A used in AUTO / LOCK specification is changed in TOOL specification, please switch specification after executing “memory clear” for deleting inside information. Even an opposite usage is similar.
Page 92: Version Read-Out Function
Chapter 9 Maintenance Using nV-Tool 9.1.3 Version Read-out Function Display the version of the hardware/software composing the remote I/O station. (1) Click on the “Tool” menu in the System View/Station Status screen to display the menu. (2) In this menu, click on the “Version” item. Version information is displayed as shown below: 6F8C1625...
Page 93: Event Log Read-Out Function
• Occurrence of error (provided that there is no problem in cyclic area registration, operation setting switch registration, module registration/installation status, and transmission line) • The FL654A is used in the nV-Tool mode Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 94 Chapter 9 Maintenance Using nV-Tool Table 9-1 Event log information Event Description Details C002 NMI occurrence AUX1 Address at which NMI occurred AUX2 = 0 (NMI) = 2 (external WDT error) = 4 (bus stall) = 5 (SRAM access error) 0004 Startup AUX1...
Page 95: Operation Mode Setting
(2) In this menu, click ”Set Time...” item. “Set Time” screen appears. (3) Click “Set Time” button to write the nV-Tool’s current time of day to the FL654A. If the function of setting calendar/time from the master station is not used, set the time of day from this screen at the time when the FL654A recovers from power OFF.
Page 96 Chapter 9 Maintenance Using nV-Tool ■ FL654A’s calendar/time setting by master station This function is to set the FL654A’s calendar/time from one of the master stations. Calendar/time setting can be made only when the operation setting switch bit 8 is set to ON.
Page 97: Lan Management Information
9.1 Maintenance Function 9.1.7 LAN Management Information Refer to the FL654A’s LAN management information and scan healthy map from the nV-Tool. (1) Click on the “Tool” menu in the System View (Station Status) screen to display the menu. (2) In this menu, click on the “LAN Manager Information” item. The talker and listener counters and other items are displayed.
Page 98 Chapter 9 Maintenance Using nV-Tool 6F8C1625...
Page 99: Nv-Tool Error
Clear Memory, Read out Operation history log, Error reset command, RUN command, HALT command, FL654A is set to TOOL specification, FL654A is I/O run mode, the following command was received from nV-Tool. Writing of Cyclic transmission specification, Message transmission specification, Token watch time, Minimum permissible frame interval, Talker area, Node name, I/O module configuration information setting, I/O data allocation Information setting.
Page 100 IReceive RUN command from nV-Tool in a state where I/O configuration information is abnormal. 0x3102 Memory clear FL654A is set to TOOL specification; FL654A is received “memory clear” when FL654A is command error I/O run mode or Down mode. 0x6102 FRAM write Writing in FRAM is failure or read-out from FRAM is failure.
Page 101 Appendix A Specifications General specifications ······················································ 86 FL654A module specifications ············································ 87...
Page 102 Appendix A Specifications A.1 General specifications Table A-1 General specifications Item Specification Remark Operating Ambient 0 to 55℃ conditions temperature Relative humidity 10 to 95%RH, level RH2 (no condensation) Altitude Up to 2000m above sea level Pollution degree 2 (usually, no conductive contamination) or less Dust 0.3mg/m (no conductive dust)
Page 103 1.56 ms after receiving the token. Important ・ The FL654A is applied to systems within the range of cyclic transmission performance according to FL-net standard. Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 104 Appendix A Specifications Table A-3 Connectable G2 I/O modules I/O type Model Digital input module DI632D/DI633/DI634/DI635/DI635H/DI653/IN653/IN663 Digital output module DO633/DO633P/DO634/DO635/AC663/RO662S/RO663 Analog input module AD624L/AD634L/AD624/AD674/AD628S/AD638S Analog output module DA622L/DA622/DA672 6F8C1625...
Page 105 Appendix B Outside Dimensions...
Page 106 Appendix B Outside Dimensions FL654A RUN FLN LNT PER I/O HALT NA-H NA-L MODE FL-net TOOL FL-net Unit: mm 25.3 62.5 Figure B-1 Outside Dimensions 6F8C1625...
Page 107 Appendix C Accessories and Related Products Accessories ··································································· 92 Related Products····························································· 93...
Page 108 Appendix C Accessories and Related Products C.1 Accessories The following accessories are included in the FL654A. Table C-1 Accessories Item Quantity Remark FL-net connection connector protective cap 1 piece Implemented in the product Tool connection connector protective cap 1 piece...
Page 109 C.2 Related Products C.2 Related Products In order to build a system using FL654A, in addition to the configuration described in Chapter 3, the following related products are required, please prepare. Table C-2 Related Products Product name Rating Remark FL-net connection cable UTP cable (Cat5e or more) Max.
Page 110 Appendix C Accessories and Related Products 6F8C1625...
Page 111 Appendix D Decimal-hexadecimal Conversion Table...
Page 112 Appendix D Decimal-hexadecimal Conversion Table Table D-1 Decimal-hexadecimal Conversion Table Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal 6F8C1625...
Page 113 Table D-1 Decimal-hexadecimal Conversion Table Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual...
Page 114 Appendix D Decimal-hexadecimal Conversion Table 6F8C1625...
Page 115 Unified Controller nv Series FL-net Remote I/O Station Module FL654A User's Manual October, 2018 First Edition Industrial Systems Division 72-34, Horikawa-cho, Saiwai-ku, Kawasaki 212-8585, Japan ©2018 Toshiba Infrastructure Systems & Solutions Corporation. No part of this document may be reproduced without permission.
Page 116 1625.1.1810...
