MOBILETT Plus HP
Installation and Setting Instructions
From Serial No. 30900
Print No.: SPR8-220.033.03.02.02
Replaces: SPR8-220.033.03.01.02
SP
© S iem ens AG 2002
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model
_or_ design,_are_
reserved.
English
Doc. Gen. Date: 10.02
66 31 753

Advertisement

Table of Contents
loading

Related Manuals for Siemens MOBILETT Plus HP

Summary of Contents for Siemens MOBILETT Plus HP

  • Page 1 MOBILETT Plus HP Installation and Setting Instructions From Serial No. 30900 © S iem ens AG 2002 The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages. All rights,...
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho- rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service procedures.

  • Page 3: Table Of Contents

    List of compatible components ......2 - 11 3 _______Changes to previous version _____________________________________ 3 - 1 4 _______Test certificate, MOBILETT Plus HP _______________________________ 4 - 1 Siemens-Elema AB SPR8-220.033.03...
  • Page 4 0 - 4 Contents This page intentionally left blank. MOBILETT Plus HP SPR8-220.033.03 Page 4 of 4 Siemens-Elema AB Rev. 02 10.02 SPS-UD Solna, Sweden...

  • Page 5: Training Of Customer Support Engineers

    Training of customer support engineers Due to the technology, used in this equipment, the setup, service and maintenance is only allowed to be performed by a customer support engineer with a Work Permit for MOBILETT Plus HP. Text emphasis DANGER DANGER indicates when there is an immediate danger that leads to death or serious physical injury.

  • Page 6: Required Documents

    (works with the filter comparison method) • Protective ground/earth meter • Equivalent leakage current meter • Storage oscilloscope with ± 2.5 % accuracy • Dose meter MOBILETT Plus HP SPR8-220.033.03 Page 2 of 8 Siemens-Elema AB Rev. 02 10.02 SPS-UD Solna, Sweden...

  • Page 7: Safety Information And Protective Measures

    - the product-specific safety information in the documents, - as well as the general safety information contained in ARTD Part 2. • Connect the MOBILETT Plus HP only to mains power supply outlet (receptacle), that corresponds to the installation requirements of VDE 0107 or country-specific regulations. •...

  • Page 8: Protective Measures Batteries B10 And Capacitors In Power Conversion Unit M10 And M11

    Discharge the capacitors in M10 and M11 with S10 (D7) (refer to Fig. 1). • Wait 5 minutes; then remove the left and right covers, and the cover with the cassette compartment. MOBILETT Plus HP SPR8-220.033.03 Page 4 of 8 Siemens-Elema AB Rev.
  • Page 9 - Check whether the voltage increases. - Switch the system OFF, disconnect the cable and switch S10 on. - Check whether the voltage decreases. Siemens-Elema AB SPR8-220.033.03 Page 5 of 8 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...
  • Page 10 This means a risk of high voltage. Use caution when performing measurements at the capacitors in M10 and M11. Use only the specified measurement devices (350 V DC). MOBILETT Plus HP SPR8-220.033.03 Page 6 of 8 Siemens-Elema AB Rev. 02 10.02...

  • Page 11: General Information

    Required measurements can be partially transferred from the test protocol provided. Supply schedule 1 crate: L = 1360 mm B = 780 mm H = 1860 mm Weight: gross approx MOBILETT Plus HP 370 kg (Technical documents enclosed) Siemens-Elema AB SPR8-220.033.03 Page 7 of 8 MOBILETT Plus HP Solna, Sweden Rev.
  • Page 12 1 - 8 General This page intentionally left blank. MOBILETT Plus HP SPR8-220.033.03 Page 8 of 8 Siemens-Elema AB Rev. 02 10.02 SPS-UD Solna, Sweden...
  • Page 13 - Control range: 2.5 m, Part No. 84 14 823 - Control range: 3.5 m, Part No. 31 36 731 Siemens-Elema AB SPR8-220.033.03 Page 1 of 12 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...
  • Page 14 Check the unit for cracks, fractures or other damages. • Make sure that neither the single tank nor the collimator has any mechanical defects which would impair the radiation protection. MOBILETT Plus HP SPR8-220.033.03 Page 2 of 12 Siemens-Elema AB Rev.

  • Page 15: Dhhs Checks

    2 minutes. Continue with chapter "Function check". If error message "CAL 19" or "Err 17" appear on the display, see chapter "Capacitor formation". Siemens-Elema AB SPR8-220.033.03 Page 3 of 12 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...

  • Page 16: Function Check

    Use a screwdriver and adjust the speed by potentiometer on D101: - turn clockwise (CW) for slower speed. - turn counterclockwise (CCW) for faster speed. This will effect the slow/fast speed simultaneously. NOTE MOBILETT Plus HP SPR8-220.033.03 Page 4 of 12 Siemens-Elema AB Rev. 02 10.02...

  • Page 17: Capacitor Formation (If Necessary)

    If the formation is successfully finished the display will show: kVmAs P06 PASS = Capacitor formation completed. Duration: Approximately 100 minutes. • Switch "1" of S1 on D1 to "OFF" Siemens-Elema AB SPR8-220.033.03 Page 5 of 12 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...

  • Page 18: Check The Indicators And Control Buttons

    A message, "USE 20", appears on the display indicating that the exposure release switch was released during exposure. It will also be indicated by 10 short beeps. The message can be acknowledged by pressing the kV + button. MOBILETT Plus HP SPR8-220.033.03 Page 6 of 12 Siemens-Elema AB Rev.

  • Page 19: Remote Exposure Switch System (Optional)

    Fig. 5. • Set the SID to approx. 50 cm (20"). The SID may vary between different kV-meters. Fig. 5 Siemens-Elema AB SPR8-220.033.03 Page 7 of 12 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...

  • Page 20: Check The Arm- And Single Tank Movement

    Press kV / mAs +/- button to change value. • Press lamp button to store value and leave program. • Switch "1" of S1 on D1 to "OFF". • Check the chosen values. MOBILETT Plus HP SPR8-220.033.03 Page 8 of 12 Siemens-Elema AB Rev. 02 10.02 SPS-UD...

  • Page 21: Check The Turn Plate

    Lock the brake. It should not be possible to move the MOBILETT with normal hand effort. A slight skip is acceptable when using a force, greater than 350N. Siemens-Elema AB SPR8-220.033.03 Page 9 of 12 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...

  • Page 22: Check The Light Field To X-Ray Field

    Measuring instruments required: test instrument for protective ground wire • Measure protective ground wire according to ARTD-002.731.17... "Safety regulations for installation and maintenance". Resistance of protective ground wire ≤ 0.2 ohms. MOBILETT Plus HP SPR8-220.033.03 Page 10 of 12 Siemens-Elema AB Rev. 02 10.02...

  • Page 23: Measurement Of Substitute Leakage Current

    List of compatible components Component Part No. Single tank (new) 60 77 379 X037E Single tank (repaired) 61 85 172 X037E Collimator (new) 65 84 713 X037E Siemens-Elema AB SPR8-220.033.03 Page 11 of 12 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...
  • Page 24 2 - 12 Installation and setting This page intentionally left blank. MOBILETT Plus HP SPR8-220.033.03 Page 12 of 12 Siemens-Elema AB Rev. 02 10.02 SPS-UD Solna, Sweden...
  • Page 25 Changes to previous version 3 - 1 Chapter 2 Page 7 Text corrected, DAP system Siemens-Elema AB SPR8-220.033.03 Page 1 of 2 MOBILETT Plus HP Solna, Sweden Rev. 02 10.02 SPS-UD...
  • Page 26 3 - 2 Changes to previous version This page intentionally left blank. MOBILETT Plus HP SPR8-220.033.03 Page 2 of 2 Siemens-Elema AB Rev. 02 10.02 SPS-UD Solna, Sweden...
  • Page 27 Test certificate, MOBILETT Plus HP 4 - 1 This test certificate is subdivided by analogy to installation and adjustment instruction. This test certificate shall be completed in duplicate, one copy remaining with the client, the other to be filed at the branch office.
  • Page 28 4 - 2 Test certificate, MOBILETT Plus HP Date calibrated: ....Check for reproducibility Fluctuation coefficient C: ........Measurement device Type: ......... Serial No.: ......Date calibrated: ....Check the arm- and single tank movement Check the turn plate Check the brake...
