Epson stylus c44: specifications
Hide thumbs Also See for Stylus C44:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, User Manual
Left edge
Paper support
guide
Maintenance
button and
error light
Power button
and light
Accessories

Ink Cartridges

Cartridge
Part numbers
Black
T036120
Color
T037020
Media
EPSON paper name
Premium Bright White Paper
Photo Quality Ink Jet Paper
Photo Quality Ink Jet Cards
High Quality Ink Jet Paper
Glossy Photo Paper (Photo Paper)
Ink Jet Transparencies
Matte Paper Heavyweight
Double-Sided Matte Paper
All-Purpose Glossy Paper
Photo Quality Glossy Paper
Photo Quality Self Adhesive Sheets A4
Glossy Photo Greeting Card Kit
Photo Stickers Kit (CD-ROM/paper)
Photo Stickers (refill)
Printer cover
Output tray
Size
Part number
Letter
S041586
Letter
S041062
A4
S041061
Legal
S041067
A6
S041054
Letter
S041111
A4
S041117
4 x 6 inches,
perforated
S041134
Letter
S041141
S041271
S041272
S041649
A4
S041140
Panoramic
S041145
Letter
S041064
Letter
S041257
Letter
S041568
Letter
S041654
Letter
S041124
A4
S041126
S041106
Letter
S041606
A6
S041144-KIT
A6
S041144

User Replaceable Parts

Part name
Printer cover
Paper support
Output tray (stacker)
Power cable

Printer Specifications

Printing
Printing method
On-demand ink jet
Nozzle configuration
Black
48 nozzles
Color
45 nozzles (15 each: cyan, magenta, yellow)
Print direction
Bidirectional with logic seeking
Input buffer
12KB
Mechanical
Paper feed
method
Friction
Paper path
Sheet feeder, top entry
Sheet feeder
capacity
100 sheets of 17 lb (65.8 g/m
Dimensions
Storage
Width: 16.7 inches (423 mm)
Depth: 9.0 inches (229 mm)
Height: 6.8 inches (172 mm)
Printing
Width: 16.7 inches (423 mm)
Depth: 18.1 inches (459 mm)
Height: 10.9 inches (277 mm)
Weight
5.47 lb (2.48 kg) without ink cartridges
Electrical
Input voltage range*
Rated frequency range
Input frequency range
Rated current
Power consumption
* Check the label on the back of the printer for your printer's
voltage.
4/03
EPSON Stylus C44 Series
Reference number
Part number
101
1253353
102
1254040
103
1253255
400
2020113
90 to 132 V
50 to 60 Hz
49.5 to 60.5 Hz
0.4 A to 0.2 A
Approx. 19 W (ISO10561 Letter Pattern)
Approx. 3W in standby mode
Approx. 2.7 W in Power Off mode
EPSON Stylus C44 Series
2
) paper
- 1
