Operating instructions
AdoraDry V2000
Tumble dryer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AdoraDry V2000 and is the answer not in the manual?

Questions and answers

Related Manuals for V-ZUG AdoraDry V2000

Summary of Contents for V-ZUG AdoraDry V2000

  • Page 1 Operating instructions AdoraDry V2000 Tumble dryer...
  • Page 2 Validity These operating instructions apply to: Model designation Type AdoraDry V2000 AT2T-12017 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2021...

  • Page 3: Table Of Contents

    EcoManagement...........   24 Timed drying............ 12 8.10 Childproof lock............  24 Textile programmes .......... 12 8.11 Drum illumination..........  25 Standard and extra programmes ..... 13 8.12 V-ZUG-Home............  25 Additional functions.......... 13 8.13 Factory settings.............   25 EcoManagement.......... 14 Demo mode  25 Operating the appliance  14 Switching on ............
  • Page 4 14.1 Saving energy............ 35 14.2 Avoiding damage .......... 35 Disposal  36 Index  37 Service & Support  39...

  • Page 5: Safety Warnings

    Safety warnings Symbols used and have understood the haz- ards involved. Children shall Denotes important safety precau- tions. not play with the appliance. Failure to observe said precautions Cleaning and user mainten- can result in injury or in damage to ance shall not be undertaken the appliance or fittings! by children without supervi-...
  • Page 6 1 Safety warnings or heat sources such as burn- as white spirit, alcohol, stain ing candles, incense sticks, remover, oil, edible oil, tur- room heaters and the like pentine, acetone, paint, wax, away from the appliance. etc.) are a fire and explosion ▪...

  • Page 7: Instructions For Use

    1 Safety warnings ▪ If the appliance is not working properly ▪ The appliance must not be in- or in case a repair is needed, follow the stalled behind a lockable instructions given in the «Service and door, a sliding door or a door repairs»...
  • Page 8 1 Safety warnings Room size, room climate and ventilation ▪ WARNING: If the size of the room is <10 m (<20 m ), it needs to be ventil- ated. There must be air inlet and outlet openings to the adjacent room or to the outside, e.g.

  • Page 9: Initial Set-Up

    Initial set-up The appliance must be installed and connected to the electricity supply in accord- ance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. If the location of the appliance is changed, because of the heat pump it must stand in its final position for around 2 hours before it can be operated again.

  • Page 10: Operating And Display Elements

    3 Appliance description Operating and display elements Operating panel Buttons Operating panel EcoManagement V-ZUG-Home display Standard and extra programmes TouchDisplay Start/Pause/Drum illumination Indicator light End of programme Favourites TouchDisplay Buttons Coloureds Textile programmes Select programme Extra dry Normal dry Iron dry...

  • Page 11: Button State

    4 Programme overview Button state Background colour Symbol colour State Blue White Function is active. Black White Function is selectable. Black Black Function is not selectable. Programme overview All the programmes are described below. Automatic programmes Consumption values The stated values for the programme duration and energy apply for the maximum stated load capacity with a wash spun at around 1000 rpm (corresponds to a moisture level of approx.

  • Page 12: Timed Drying

    4 Programme overview Timed drying Dries textiles for a set duration, irrespective of ▪ Load: 1–7 kg their level of dryness. For final drying of sleep- ing bags and quilts, provided they have the relevant fabric care symbols. Load for bulky textiles: 1 item Textile programmes Coloureds...

  • Page 13: Standard And Extra Programmes

    4 Programme overview Standard and extra programmes Standard programme The stated values for the programme duration and energy apply for the maximum stated load capacity with a wash spun at around 1000 rpm (corresponds to a moisture level of approx. 60%). A higher spin speed or a smaller load reduce them by approx. 20–30%. The most energy efficient programme for dry- ▪...

  • Page 14: Ecomanagement

    5 Operating the appliance EcoManagement The «EcoManagement» user setting must be turned on to use «EcoManage- ment» (see page 24). EcoManagement provides information on the energy and water consumption of the appliance. The following statistical data can only be re- trieved when there is no programme running: ▪...

  • Page 15: Selecting A Programme

    5 Operating the appliance Selecting a programme To avoid damaging the laundry, follow the fabric care symbols on garment labels: Automatic programmes When a programme is selected, all the necessary settings for it are assigned automatic- ally. Additional functions can be selected or deselected by using further buttons in other views.

  • Page 16: Selecting Additional Functions

    5 Operating the appliance Standard and extra programmes ▸ Touch the button. Extra – The selection of standard and extra pro- grammes appears in the TouchDisplay. Standard Basket ▸ Touch the button for the desired standard or extra Airing programme, e.g. –...

  • Page 17: Checking And Changing The Settings

    5 Operating the appliance Checking and changing the settings ▸ Touch the button in the Additional functions Extra dry 2 h 52 menu. – The start screen appears in the TouchDisplay. ▸ Select a new programme (see page 15). ▸ To make a change once a programme has star- ted, the programme must be ended before time.

  • Page 18: Adding Washing

    5 Operating the appliance Adding washing Washing can be added at any time during the drying process. ▸ Press the 5 dots at the edge of the appliance door. – The appliance door opens. – The drum illumination switches on. –...

  • Page 19: Drum Illumination

    5 Operating the appliance After being unlocked, the appliance can be operated normally. The childproof lock is automatically activated as soon as the programme starts. 5.12 Drum illumination The drum illumination automatically switches on whenever the appliance door is opened and switches off when it is closed.

  • Page 20: Ecomanagement

    5 Operating the appliance 5.14 EcoManagement The «EcoManagement» user setting must be activated to use «EcoManagement» (see page 24). Displaying estimate during programme selection The expected energy consumption can be displayed during additional function selection. ▸ Touch the button for the desired programme, e.g. Extra dry 2 h 52 –...

  • Page 21: Favourites

    6 Favourites Favourites The appliance door has to be open to define, change or delete a favourite. Defining and saving favourites ▸ Press the 5 dots at the edge of the appliance door. – The appliance door opens. ▸ Touch the button.

  • Page 22: Starting Favourites

    – The programme selected starts. V-ZUG-Home Conditions The following conditions must be met for full use of V-ZUG-Home: ® ▪ Access to the internet and to Google Play Store / App Store ▪ a wireless network that meets one of the following standards: 2.4GHz 802.11 b/g/n ▪...

  • Page 23: Initial Set-Up

    – A 6-digit PIN appears in the display of the appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password.

  • Page 24: Button Tone

    8 User settings Button tone The button tone can be turned on and off. The but- ▪ On (factory setting) ▪ Off ton tone for the buttons cannot be turned off. Viewing angle The readability of the TouchDisplay is improved ▪...

  • Page 25: Drum Illumination

    8.12 V-ZUG-Home With V-ZUG-Home (see page 22), you can access ▪ Operate and display your appliances over the V-ZUG App to, for instance ▪ Display ▪ Off (factory setting) ▪ switch off a running appliance ▪ call up the status of your household appliances.

  • Page 26: Switching Off

    10 Care and maintenance Switching off ▸ Press the 5 dots at the edge of the appliance door. – The appliance door opens. – The drum illumination switches on. ▸ Simultaneously press the buttons until the Demo mode menu appears in the Touch- Display.

  • Page 27: Cleaning The Front Filter Mat

    10 Care and maintenance Cleaning the door filter and door filter mat ▸ Take out the door filter 1, as described in «Cleaning the door fil- ter». ▸ Open the door filter 1 and take out the door filter mat 2. ▸...

  • Page 28: Cleaning The Moisture Sensor

    10 Care and maintenance ▸ Clean the front filter mat 3 carefully using a vacuum cleaner with the crevice tool attachment. ▸ Clean the air duct in front of the front filter mat with a vacuum cleaner or moist cloth if necessary. ▸...

  • Page 29: Trouble-Shooting

    11 Trouble-shooting Trouble-shooting You may be able to trouble-shoot the following malfunctions yourself. If not, note down the error message in full (message, F and E numbers) and call Customer Services. 11.1 Error messages Display Possible cause Solution A0 Check outlet ▪...

  • Page 30: Other Possible Problems

    11 Trouble-shooting Display Possible cause Solution FXX/EXX see in- ▪ Various situations can ▸ Press the button. structions lead to this error mes- ▸ Remove the mains plug from the mains sage. socket. SN XXXXX ▸ Wait for about 1 minute. XXXXXX ▸...
  • Page 31 11 Trouble-shooting Problem Possible cause Solution The laundry is ▪ Mixed laundry load. ▸ Select a longer programme, e.g. extra not dry enough and the waist- band of jeans is still wet. ▸ Select timed drying. ▸ Change the level of dryness (see page 24).
  • Page 32 11 Trouble-shooting Problem Possible cause Solution The appliance ▪ Various situations in ▸ Close the appliance door. door springs the appliance can ▸ Touch the button. open during op- cause this. – The programme is resumed. eration. The drum is ▪...

  • Page 33: Spare Parts

    12 Spare parts Spare parts Please give model designation and type when ordering parts. Door filter Door filter mat Front grille Front filter mat Technical data General notes Height 85 cm Width 59.5 cm Depth 61 cm Weight 52.0 kg Pumping height of pump 1.2 m Load capacity 7 kg dry washing...

  • Page 34: Product Fiche

    13.2 Product fiche In accordance with EU Regulation No. 392/2012 Brand V-ZUG Ltd The model identifier corresponds to the first 5 al- 12017 phanumerics on the identification plate. Rated capacity for cotton laundry at full load Type of appliance...

  • Page 35: Drying Tips

    14 Drying tips In accordance with EU Regulation No. 392/2012 Weighted condensation efficiency Sound power level 1 Energy consumption x kWh per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes.
  • Page 36 15 Disposal Disposal 15.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 15.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
  • Page 37 Index Extra dry............. 11 Extra programmes ........... 10 Additional functions ......... 13 Starting............  16, 23 Starting............ 16 Airing Extra programmes........ 13 Factory settings ..........25 Appliance disposal .......... 36 Favourites ............10 Automatic programmes ........10 Starting............ 22 Consumption values ........ 11 Final airing............
  • Page 38 Shirts ..............  12 Silks.............. 12 Type............... 2 Underwear Standard dry .......... 11 Using for the first time........9 Validity..............2 Viewing angle ........... 24 V-ZUG App ............23 V-ZUG-Home............. 10 Switching on mode........ 25 Warranty extensions ........39 WLAN connection ..........23...
  • Page 39 V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive service agreements.
  • Page 40 ▸ Load laundry. ▸ Clean the door filter. ▸ Close the appliance door. ▸ Close the appliance door. ▸ Select programme and any additional functions (if required). ▸ Press the button. Programme starts. 1098484-02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug info@vzug.com, www.vzug.com...
