PC-Software HMGWIN 3000

3.4 Starting the program

If you have installed the program in the default path suggested by the Setup Wizard it is
•
located in the Start Menu under "Programs"
the program, click on "HMGWIN".
When launching the program for the first time a window appears enabling you to select
•
the user interface language: German, English or French. To do this, select the language
by mouse click. Confirm the setting by clicking the "OK" button.

3.5 Setting up Connection with HMG 3010

• To establish a connection with a HMG device connected to the PC, click on the
"Units" dialogue box and select "Connection" from the drop-down menu.
• A window for Connection opens.
• Click on "Modify" to open the window for the interface settings.
• Make the corresponding pre-selection for the port settings in the window that
opens under Interface selection.
Select the relevant port address and Baud rate under Interface settings.
As an alternative, you can also automatically search for HMG devices con-
nected to the PC under HMG3000 devices search by pressing "Start".
HMGWIN 3000 indicates at which port HMG 3000 has been recognised. Click
on
If a HMG has been detected, click on "Apply" to keep this interface or on "Can-
cel" to discard the interface changes.
• Click "Refresh" to update the interfaces marked under Interface selection in
terms of availability.
• Click on "OK" to apply the modified settings or "Cancel" to discard these chang-
es. In either case you will then return to the Connection window.
• Afterwards click on "Connect" in the Device box to connect the HMG to the PC.
• The successful connection will be symbolized by a green dot on the right-hand
edge of the window.
• Pressing "Disconnect" in the Device box allows you to interrupt the existing
connection
the HMG and the PC.
• At the end you also have the option of selecting an automatic connection setup.
Placing a checkmark in the box for "Set up connection next time automatical-
ly" causes the HMGWIN software to set up a connection automatically with the
HMG that is linked via USB during startup. To ensure that this happens, no
changes should be made to the interface parameter settings after the currently
existing connection is disconnected.
• Click on "OK" to complete the connection setup.
