Sealey PC20SD20V Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
1. SAFETY
i
Remove the battery pack from the cleaner before servicing, changing accessories, or performing any maintenance.
9
Use only genuine parts and accessories. Unauthorised parts and accessories may be dangerous and will invalidate your warranty.
9
Maintain the cleaner in good condition. Keep machine clean, but DO NOT use solvents.
9
For dry vacuuming ensure the filter is firmly in place before operating the cleaner.
9
DO NOT operate the unit without a filter in place. Using the cleaner without a filter may cause damage to the vacuum cleaner and
8
will invalidate your warranty.
DO NOT allow children or untrained persons to operate the cleaner.
8
DO NOT place attachments close to your face (especially eyes, ears, etc). DO NOT point the hose end at other persons or animals.
8
▲ DANGER! DO NOT vacuum hot or glowing ash, cigarette ends, inflammable, explosive, corrosive or other dangerous substances.
DO NOT leave machine running unattended. Turn power OFF and DO NOT leave the vicinity until motor has come to a complete stop.
8
DO NOT operate the cleaner while under the influence of drugs, alcohol or impairing medication, or if you are tired.
8
DO NOT use the cleaner in the rain or in very damp conditions.
8
DO NOT use the cleaner for a task it is not designed to perform.
8
When not in use, store the cleaner in a safe, dry, childproof location.
9
2. INTRODUCTION
Extremely lightweight portable cordless wet and dry vacuum cleaner. Convenient for use in the home, workshop or car, especially
where mains power is not easily accessible. Features a 20ltr stainless steel drum mounted on four swivel casters for
easy manoeuvrability. Unit also has built in blower function which can be used for many applications. Body only. Supplied with
comprehensive accessory pack. 2Ah battery available - Model No. CP20VBP2 (Approx. 15 mins running time). 4Ah battery available -
Model No. CP20VBP4 (Approx. 27 mins running time). Mains charger available - Model No. CP20VMC.
3. SPECIFICATION
Model no.: ......................................................... PC20SD20V
Motor power: .................................................................140W
Supply: .............................................................................20V
Airflow: .......................................................................65m
Drum size: ....................................................................... 20ltr
Filter type ...................................................................... Foam
Maximum vacuum pressure ....................................... 80mbar
Nett weight .................................................................... 3.7kg
Vacuum accessories diameter ..................................... 32mm
Consumables:
Foam filter: .................................................PC20SD20VFF10
Bag filter ........................................................ PC20SD20VCF
20V 2Ah Li-ion battery (15 min. run time) ............. CP20VBP2
20V 4Ah Li-ion battery (27 min. run time) ............. CP20VBP4
Mains charger: ...................................................... CP20VMC
4. CONTENTS
4.1. Contents (fig.1) are inside cleaner body (except items 2).
4.2. Locate the two side clasps (fig.3) which hold the top
section in place.
4.3. Undo the clasps, remove the top section and take out
the items in the container (fig.1).
4.4. Check and identify each component as shown. If
anything is missing or damaged please contact your
supplier immediately.
© Jack Sealey Limited
CORDLESS VACUUM CLEANER WET & DRY
20LTR 20V - BODY ONLY
MODEL NO:
CARTON CO
PC20SD20V
/hr
3
fig.1
Item no. Description
1 Flexible hose
2 Suction tube
3 Castors
4 Bag filter
5 Foam filter
6 Combination nozzle
7 Crevice nozzle
Original Language Version
Quantity
1
3
4
1
1
1
1
PC20SD20V Issue 1 22/02/19
