- Page 1 DPS Blade V100R001C50 Configuration Manual Issue Date 2019-06-30 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
-
Page 3: Change History
DPS Blade V100R001C50 Configuration Manual Change History Change History Date Version Change History Author 2019-06-30 V1.0 Released the first version. Zhang Jianye (employee ID: 00485354) 2019-09-30 V1.1 Add export control instructions Zhang Jianye (employee ID: 00485354) Refresh certification status 1. Revise the communication 2019-12-24 V1.2... -
Page 4: Table Of Contents
DPS Blade V100R001C50 Configuration Manual Contents Contents Change History ..........................ii 1 Overview ............................. 1 1.1 Purpose ................................. 1 1.2 Naming Conventions .............................. 1 1.2.1 Naming Description ............................1 2 Configuration Overview ....................... 2 2.1 Product Overview ..............................2 2.2 Product Composition ............................. 4 2.3 Installation and Maintenance Modes ........................ - Page 5 DPS Blade V100R001C50 Configuration Manual Contents 2.6.14 Selecting an Installation Mode .........................19 3 Configuration Description ......................20 3.1 Configuration Rules for Accessories ........................20 3.2 Configuration Rules of Cables and Terminals ......................21 3.2.1 Power Cable Configuration Rules ........................21 3.2.2 Configuration Rules of Northbound Communication Cables................26 3.3 Configuration Rules of Auxiliary Material Packages ....................29...
-
Page 6: Overview
This document is for internal use only. It aims to guide relative personnel to perform product selection, commercial configuration, and sales of the DPS Blade V100R001C50. It is a technical disclosure document for the marketing department and describes the components, configuration list, configuration rules, actual conditions, and technical limitations of the DPS Blade V100R001C50. -
Page 7: Configuration Overview
2 Configuration Overview 2.1 Product Overview The DPS Blade V100R001C50 is an outdoor and indoor wall-mounted power supply solution designed for wireless micro base stations. It integrates the functions of power supply, energy storage, power distribution, monitoring, cooling, surge protection, and grounding, meeting the requirements for fast site deployment. - Page 8 2 Configuration Overview Figure 2-1 Typical networking of the DC DPS system The DPS Blade series does not support networking with different Huawei equipment and third-party equipment at the same time, only support choose one type (one RS485 cable or MBUS).
-
Page 9: Product Composition
2.3 Installation and Maintenance Modes The DPS Blade V100R001C50 can be mounted on a wall, against a wall, or on a pole, a channel steel, or angle steel tower. Cables can be routed from the bottom. The following table lists the installation and maintenance modes of the DPS Blade V100R001C50. -
Page 10: Cabling Rules For Cascading Multiple Modules
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Table 2-2 Installation and maintenance modes Item Description Installation mode Wall-mounting (flush mounting), pole-mounting (flush mounting and side mounting), mounting on a channel steel (flush mounting), and mounting on an angle steel tower... - Page 11 DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Figure 2-2 Cable connection of scenario 1 Scenario 2: 3200 W, two PSUs In this scenario, the power supply system supplies power to dual-sector AAUs, one-band RRUs, or other DC devices (such as BBUs).
- Page 12 DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Figure 2-4 Cable connection of scenario 3 DB15 DB15 DB15 Scenario 4: 6400 W, four PSUs The load ports are occupied. Each blade PSU remains two load ports. Figure 2-5 Cable connection of scenario 4...
-
Page 13: Typical Installation Modes
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview 2.3.2 Typical Installation Modes Figure 2-6 Side mounting or flush mounting on a small pole Small poles refer to poles with a diameter of 60–114 mm. Figure 2-7 Flush mounting on a wall and on a large pole Large poles refer to poles with a diameter of 114–400 mm. -
Page 14: Installation Rules
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Figure 2-8 Specifications and installation modes for channel steels and angle steels 2.3.3 Installation Rules Table 2-3 Installation rules Installation Installation Maximum Configuration Maximum System Scenario Mode for One Layer Configuration Side Two PSUs + Two 20 Ah 1. -
Page 15: Application Environment
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Figure 2-9 Installing batteries on different layers on a small pole 2.4 Application Environment Table 2-4 Operating environments of the DPS Blade V100R001C50 Environment Parameter Operating Transportation Storage Remarks Environment Environment Environment... -
Page 16: Application Limitations
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Environment Parameter Operating Transportation Storage Remarks Environment Environment Environment Category Item Unit Humidity Low relative humidity High relative humidity Condensatio Yes/No Altitude Low altitude The power system High altitude 4000 4000 4000... -
Page 17: System Configuration
Manufactured Board,EN11PWRBK 5A991(OAM) The target markets of the DPS Blade V100R001C50 power system include China, Asia Pacific, Europe, Latin America, Canada, and Commonwealth of Independent States (CIS). It cannot be directly sold in Japan, South Korea, and North America. Submit an OR ticket before selling in these states or regions. -
Page 18: Configuration Procedure
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Number of Load Number of Number of Backup Power Backup Power Lithium Capacity (Wh) Capacity (Wh) Routes PSUs Batteries (DBU20B) (DBU50B) DPU40D-N06A3 2400 1920 4800 2880 7200 3840 9600 ⚫ PSU (DPU40D-N06A3): When one PSU is configured, the maximum output power of the PSU is 2000 W. -
Page 19: Determining Ac Input Voltage
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Start Determine AC input voltage. Class 3 B and Class 4 Countries with poor power grids mains power supply Determine power grid types. Risk warning for poor Class 1, Class mains power supply... -
Page 20: Determining Power Grid Types
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview When a blade power supply works in the input mode of single-phase 110 V AC, the power is derated by 50%. 2.6.2 Determining Power Grid Types The following alarm will be generated for Class 3B and Class 4 grids: Contact the MO to determine the power grid types if necessary. -
Page 21: Is The Site Within 500 M Away From The Sea
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview Figure 2-10 Areas where the highest ambient temperature is over 45°C 2.6.4 Is the Site Within 500 m Away from the Sea No is chosen by default. You can choose Yes. If this parameter is set to Yes, a warning needs to provided: Contact the MO if necessary. -
Page 22: Determining Input Load Power
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview The blade here refers to the blade power supply, and the blade lithium battery is not included. Scenario 1 is selected by default, and Scenario 2, Scenario 3, and Scenario 4 are optional. -
Page 23: Whether Need The Live-C App
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview : aging coefficient. The value is 0.8. : capacity coefficient. The longer the discharge time, the larger the value of K DOD: depth of discharge of the lithium battery BOM Code Product... -
Page 24: Input The Number Of Loads
DPS Blade V100R001C50 Configuration Manual 2 Configuration Overview ⚫ If you choose No, 02312NGM-001 will be configured. 2.6.11 Input the Number of loads Scenario 1: N =3, Range load load Scenario 2: N =6, Range load load Scenario 3: N... -
Page 25: Configuration Description
If components that are not in Configuration Table for DPS Blade V100R001C50 Mounting Kits and Internal Cables are needed, the following alarm is generated: The component is not included in the standard configuration list. -
Page 26: Configuration Rules Of Cables And Terminals
DPS Blade V100R001C50 Configuration Manual 3 Configuration Description Configuration BOM Code Description Quantity Remarks Description 21150765-00 Engineering Installation 12 L hanging kit, Used to mount DPUs Kit,DKBA41509257.ASM, quotation item and DBUs, and can be Bracket,Fasting Screw used with 21150763, Demand,Multifunctional... - Page 27 DPS Blade V100R001C50 Configuration Manual 3 Configuration Description survey is available or site survey data cannot be provided, the default configuration can be used for delivery. For versions in China, AC power cables and ground cables are not configured by default.
- Page 28 DPS Blade V100R001C50 Configuration Manual 3 Configuration Description Configuration Code Description Quantity Remarks Code Description w/Green),27A,Ou delivered by default area: 2–4 mm tdoor if no site survey data Outer diameter: Cable,CCC,CE is provided; the 9–14.5 mm specific length is determined based on site survey data;...
- Page 29 DPS Blade V100R001C50 Configuration Manual 3 Configuration Description Configuration Code Description Quantity Remarks Code Description Cable,650mm,10mm2 cable, 0.65 m, al cable, ,Yellow/Green,OT-10 quotation item 0.65 m mm^2-M6,H07Z-K-10 ^2G&Y,OT-10mm^2- M6,LSZH 04151857- Power C3 equipotential Equipotenti Cable,1.6M,10mm^2, cable, 1.6 m, al cable, 1.6...
- Page 30 ), number of blade lithium batteries (N ), and installation mode, refer to Configuration Table for DPS Blade V100R001C50 Mounting Kits and Internal Cables to get the lists of mounting kits, internal power cables, and internal signal cables. You are advised to get the BOM code list by referring to the typical Issue 01 (2019-06-30) Copyright ©...
-
Page 31: Configuration Rules Of Northbound Communication Cables
DPS Blade V100R001C50 power system is used as auxiliary equipment. ⚫ If the main equipment of the DPS Blade V100R001C50 is Huawei RRUs, you can select appropriate communications cables by referring to the following table. Table 3-5 Northbound communications cable list... - Page 32 DPS Blade V100R001C50 Configuration Manual 3 Configuration Description Configuration Code Description Quantity Remarks Code Description seal,NO 040804 Monitor&Alarm Used for Cable,DPU Comm. with communicatin quotation item TDD RRU wire,5M,D9 g with Huawei Male-I+D9 Waterproof TDD RRUs Plastic Shell,CAT5E SFTP through...
- Page 33 DPS Blade V100R001C50 Configuration Manual 3 Configuration Description Table 3-6 Monitoring cables for Huawei RRUs Transmission BOM Code Main Equipment Length Remarks Type Dry contact + 04080336 FDD RRU RS485 04080419 TDD RRU (DC) Dry contact + Two cables in...
-
Page 34: Configuration Rules Of Auxiliary Material Packages
The 02231YSG is the auxiliary material package for the DPS Blade power system. It is a quotation item.The configuration method of the typical configuration auxiliary material package is described in Configuration Table for DPS Blade V100R001C50 Mounting Kits and Internal Cables. There are two cases: Internal cables are packaged and internal cables are not packaged. - Page 35 DPS Blade V100R001C50 Configuration Manual 3 Configuration Description BOM Code Description Quantity Remarks 14170020 Naked Crimping 3 PCS Terminal for the Terminal,OT,16mm^2,M6,Tin main ground cable Plating,Naked Ring Terminal 30037609 30037609_DRAen,Inner 1 PCS cardboard,310mm-215mm, for all products 14170024 Naked Crimping 3 PCS...
-
Page 36: Spare Parts List And Manual
DPS Blade V100R001C50 Configuration Manual 4 Spare Parts List and Manual 4 Spare Parts List and Manual Site spare part list and spare parts manual DPS Blade V100R001C50 Spare Parts.xlsx Product managers need to confirm the quantity of loose parts and then quote. -
Page 37: License Configuration
DPS Blade V100R001C50 Configuration Manual 5 License Configuration 5 License Configuration The license software quotation is not involved in the DPS Blade V100R001C50. Issue 01 (2020-07-21) Copyright © Huawei Technologies Co., Ltd. -
Page 38: Appendix
DPS Blade V100R001C50 Configuration Manual 6 Appendix 6 Appendix None Issue 01 (2020-07-21) Copyright © Huawei Technologies Co., Ltd.
