- Page 1 GLOBAL PLASMA SOLUTIONS iMOD Installation Operation & Maintenance Manual 10 Mall Terrace, Building C Savannah, GA 31406 (912) 356-0115 Phone www.globalplasmasolutions.com 012019-GPSIMOD-IOM REV C...
- Page 2 4. (1) End cap per completed modular bar. End cap inserts into the last modular section of the bar. 5. A minimum of (2) mounting magnets per bar for securing the GPS-iMOD to the cooling coil inlet or filter rack. Secure magnets to the modular sections.
- Page 3 MECHANCIAL INSTALLATION For standard IAQ applications, there should be (1) GPS-iMOD on each cooling coil up to 60 inches in height. The GPS-iMOD(s) may be located closer to each other than 60 inches, but 60 inches is the maximum height they should be placed apart. The bar should be assembled such that the entire finned width of the cooling coil is covered.
- Page 4 Please note, the installing contractor will have to provide a piece of metal angle across the face of the coil to attach the GPS-iMOD, if the coil finned surface area is over 3 feet wide.
- Page 5 SWITCH INSIDE HOUSING IS CONFIRMED IN THE CORRECT POSITION FOR THE PRIMARY POWER BEING APPLIED!!! The GPS-iMOD system requires a total of 15 watts to power up to (6) GPS-iMODs at any length. The power supply will accept 24VAC, 115VAC or 208-240VAC at 50HZ or 60HZ. CAUTION!! The power supply has an internal voltage selector switch set to 115VAC from the factory, refer to Figure 8.
- Page 6 3. One opening in the high voltage (HV) section will be left open for attachment of the HV wire. Refer to Figure 9. Based on the jobsite specific wiring route, access to the right, left or top side may be desired. Remove the plug from the port desired and fill the port not used with the spare plug.
- Page 7 GPS-iDETECT-P sensor. DO NOT RUN CONTROL WIRING WITH HV CABLES! 3. Mount the GPS-iDetect-P using the included 1” coated pipe clamp and secure to a GPS-iMOD section as shown in Figure 11 using a nut and bolt.
- Page 8 When the switch is turned “On” the “Power On” light will illuminate letting the end user know power is supplied and the GPS-iMOD system is energized. Note: If a door switch, fan interlock switch or air flow switch are in series with the power, the system may not turn on until all safeties are closed.
