  • Page 1 IMPORTANT: IMPORTANT : IMPORTANTE: Read Before Using Lire avant usage Leer antes de usar Operating/Safety Instructions Consignes de fonctionnement/sécurité Instrucciones de funcionamiento y seguridad Call Toll Free for Pour obtenir des Llame gratis para Consumer informations et les adresses obtener información Information &...
  • Page 2 1.800.561.8187 information@itm.com www. .com...
  • Page 3 1.800.561.8187 information@itm.com www. .com...

  • Page 4: General Safety Rules

    General Safety Rules Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE THESE INSTRUCTIONS Work area safety Keep work area clean and well lit. Cluttered or dark areas invite accidents. DO NOT operate the laser tool around children or allow children to operate the laser tool.
  • Page 5 radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. –...

  • Page 6: Intended Use

    Maintain tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the operation. If damaged, tool repaired before use. Many accidents are caused by poorly maintained tools. Use the tool, accessories, etc., in accordance with these instructions and in the manner intended for the particular type of tool, taking into account the working conditions and the work to be performed.

  • Page 7: Technical Data

    Features The numbering of the product features shown refers to the illustration of the tool on the graphic page. 1 Button for adjustment of the measuring accuracy 2 On/Off switch 3 Audio signal button 4 Display 5 Magnet plate 6 Reception area for the laser beam 7 Center mark 8 Direction LED “move downward”...

  • Page 8: Operation

    Weight 0.44lb (0.2 kg) Dimensions 5.9” x 2.9” x 1.6” (150x 74 x 41mm) 1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun irradiation). 2) The angular accuracy between the 45° laser line and the 90° laser line is max. ±0.4 mm/m. Please observe the article number on the type plate of your tool.
  • Page 9 When no button is pressed on the tool for approx. 20 minutes and when no laser beam reaches the reception area 6 for 20 minutes, the tool automatically switches off in order to save the battery. The switching off is indicated by brief lighting up of all LEDs.

  • Page 10: Maintenance And Service

    If the tool should fail despite the care taken in manufacturing and testing procedures, repair should be carried out by an authorized after- sales service center for Bosch power tools. In all correspondence and spare parts orders, please always include the 10-digit article number given on the type plate of the tool.
  • Page 11 BOSCH within 30 days of the date of purchase for a full refund or replacement. To obtain this 30-Day Refund or Replacement, your return must be accompanied by the original receipt for purchase of the laser or measuring tool product.

This manual is also suitable for:

000346391008
