Cambridge Audio Azur 840W Technical Specifications

Azur 840W Class XD Power Amplifier

The 840W is a high-end power amplifier that has been
designed by the same team behind the 840A and uses an
evolution of Cambridge Audio's hugely innovative Class
XD™ technology for a highly detailed naturally musical
performance. The second generation Class XD is now
complemented by a new output stage carefully adjusted to
integrate with this novel technology, along with revised
balanced input connections for lower distortion and noise
circuits. Each channel uses 2 pairs of very high output
transistors to ensure that the 840W can drive even the
most demanding load At the core of the 840W's strength
is a patent pending, Class XD (crossover displacement)
Azur 840w Features
Power Output
Audio Inputs:
Audio Outputs
Other Connections
Damping factor
Frequency Response:
Signal to Noise ratio
THD(unweighted):
Max. Power Consumption:
Dimensions (W x D x H):
Weight:
Cambridge Audio, Gallery Court, Hankey Place, London SE1 4BB
©2007 Cambridge Audio Ltd. Issued August 2007
technology This unique design gives pure Class A operation
at low levels, moving smoothly into an enhanced version of
Class B at higher levels.
The 840W delivers an impressive 200 watts per channel in
stereo mode, and can be bridged to output a massive 500
watt mono output. Also included is the latest development of
Cambridge Audio's proprietary CAP5 protection system.
CAP5 (Cambridge Audio Protection 5) is an innovative and
intelligent protection system. It constantly monitors the
amplifier, without degrading signal purity, ensuring ultimate
reliability and high performance from this mighty amplifier.
200 watts per channel into 8 ohms
300 watts per channel into 4 ohms
500 watts mono into 8 ohms in bridged mode.
1 pairs Gold Plated RCA stereo phono inputs
1 pair XLR balanced inputs
1 pairs Gold Plated RCA stereo phono outputs
1 pair XLR balanced outputs
12v trigger in/out, control bus in/out, IR emitter in.
A & B speaker premium gold plated binding posts
>300
10Hz – 50kHz +/- 1dB
83 db
<0.0015% @ 1kHz
1200 Watts (Standby: 12 Watts)
430 x 385 x 145mm
21.8kg/48.2 lbs
Cambridge Audio's policy is one of improvement.
Designs and specifications are therefore subject to
change without notice
