- Page 1 Undercounter Refrigeration Design Guide REVISED 1/2021...
-
Page 2: Undercounter Refrigeration
UNDERCOUNTER WINE MODELS UW-24 UW-24FS Features and specifications are subject to change at any time without notice. Visit subzero.com/specs for the most up-to-date information. Throughout this guide, dimensions may vary by ± 1/8" Dimensions in parentheses are millimeters unless other-... -
Page 3: Overall Dimensions
Overall Dimensions IMPORTANT NOTE: Overall dimensions are based on the UNDERCOUNTER MODELS stainless steel models. Refer to page 9 for door clearance information. " 24" (606) (610) 34" (864) 4" (102) " (645) 26" 8" (660) (203) subzero.com | 3... - Page 4 Undercounter Refrigeration Overall Dimensions WINE MODEL UW-24 WINE MODEL UW-24FS " 24" " " (606) (610) (616) (625) 34" " (864) (868) 4" 4" (102) (102) " " (645) (645) " " (44) (44) IMPORTANT NOTE: Overall dimensions are based on the Freestanding model UW-24FS has a finished stainless steel stainless steel models.
-
Page 5: Opening Dimensions
TOP VIEW Dual installation kits are available through an authorized Sub-Zero dealer. For local dealer information, visit the find a showroom section of our website, subzero.com. For questions regarding the installation, call Sub-Zero Customer Care at 800-222-7820. "... -
Page 6: Electrical Requirements
IMPORTANT NOTE: For outdoor model UC-24RO, a our website, subzero.com. ground fault circuit interrupter (GFCI) is required to reduce the risk of electrical shock. A GFCI is not recommended for... -
Page 7: Custom Panel
Sub-Zero dealer. For local for more information. Overall dimensions are the same for dealer information, visit the find a showroom section of glass and solid door panels. our website, subzero.com. Refer to the chart below for standard handle lengths. HANDLE LENGTH TUBULAR Undercounter Model 24 1/4"... -
Page 8: Full-Scale Template
Undercounter Refrigeration Wine Rack Wood Facing FULL-SCALE TEMPLATE WOOD FACING WIDTH UW-24, UW-24FS 19 1/2" (495) The natural cherrywood facing on wine storage racks can be stained and sealed, or replaced with wood more complementary to surrounding cabinetry. Refer to the full-scale templates for the profile dimensions of the wood facing and the charts for the width. - Page 9 90°. UNDERCOUNTER ADJACENT UNIT CABINETRY DOOR CLOSED " (13) " (19) DOOR PANEL " " HINGE AT 145° OPENING (DOOR OPENS PAST 145°) 0" 1" (25) SCALE 145° door opening (top view) subzero.com | 9...
-
Page 10: Warranty
To receive parts and/or service and the name of Sub-Zero Factory Certified Service nearest you, contact Sub-Zero, Inc., P.O. Box 44848, Madison, WI 53744; check the Product Support section of our website, subzero.com, email us at customerservice@subzero. com, or call 800-222-7820. - Page 11 To receive parts and/or service and the name of Sub-Zero Factory Certified Service nearest you, contact Sub-Zero, Inc., P.O. Box 44848, Madison, WI 53744; check the Product Support section of our website, subzero.com, email us at customerservice@subzero. com, or call 800-222-7820.
