SERVICE
TFT-LCD TV
UE**D6*****
LED-TV
Chassis : U68A
Model
: UE**D600*T*
UE**D61**S*
UE**D620*T*
UE**D63**S*
Manual
1. Precautions
2. Product specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UE D600 T Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung UE D600 T Series

Summary of Contents for Samsung UE D600 T Series

  • Page 1 LED-TV Chassis : U68A Model : UE**D600*T* UE**D61**S* UE**D620*T* UE**D63**S* SERVICE Manual TFT-LCD TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UE**D6*****...

  • Page 2: Table Of Contents

    Contents 1. Precautions ......................1-1 1-1. Safety Precautions ......................1-1 1-2. Servicing Precautions ..................... 1-2 1-3. Electrostatically Sensitive Devices (ESD) Precautions ..........1-2 1-4. Installation Precautions ....................1-3 2. Product specifications .................... 2-1 2-1. Specifications Information ....................2-1 2-2. Detail Factory Option ...................... 2-8 2-3.
  • Page 3 This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2011 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable All rights reserved. International and/or domestic law. Printed in Korea...

  • Page 4: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.

  • Page 5: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions WARNING: An electrolytic capacitor installed with the wrong polarity might explode. Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 6: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than a people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 7: Product Specifications

    2. Product specifications 2. Product specifications 2-1. Specifications Information 2-1-1. Model Comparison Model UD600*/UD620* UD61**/UD63** Front view Detail view Front Color Clear + Rose black Rose Black Without Stnand 771.27 x 29.9 x 470.36 768 x 29.9 x 475.3 32" With Stand 771.27 x 240 x 532.53 768 x 240 x 533.4...
  • Page 8 2. Product specifications 2-1-2. Feature & Specifications Model UE32D60**/UE32D61**/UE32D62**/UE32D63** Feature UE : Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 3-USB 2.0(Media Play), D-SUB , LAN, 1-Scart ሪ Respons time : 6.5 ms ሪ Dynamic contrast, Super-PVA ሪ PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV)) ሪ...
  • Page 9 2. Product specifications Model UE37D60**/UE37D61**/UE37D62**/UE37D63** Feature UE : Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 3-USB 2.0(Media Play), D-SUB , LAN, 1-Scart ሪ Respons time : 5.5 ms ሪ Dynamic contrast, Super-PVA ሪ PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV)) ሪ...
  • Page 10 2. Product specifications Model UE40D60**/UE40D61**/UE40D62**/UE40D63** Feature UE : Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 3-USB 2.0(Media Play), D-SUB , LAN, 1-Scart ሪ Respons time : 5.5 ms ሪ Dynamic contrast, Super-PVA ሪ PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV)) ሪ...
  • Page 11 2. Product specifications Model UE46D60**/UE46D61**/UE46D62**/UE46D63** Feature UE : Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 3-USB 2.0(Media Play), D-SUB , LAN, 1-Scart ሪ Respons time : 5.5 ms ሪ Dynamic contrast, Super-PVA ሪ PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV)) ሪ...
  • Page 12 2. Product specifications Model UE55D60**/UE55D61**/UE55D62**/UE55D63** Feature UE : Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 3-USB 2.0(Media Play), D-SUB , LAN, 1-Scart ሪ Respons time : 5.5 ms ሪ Dynamic contrast, Super-PVA ሪ PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV)) ሪ...
  • Page 13 2. Product specifications 2-1-3. Spec Comparison to the Old Models Model UD6T UC6U UE60**/UE62** UE61**/UE63** Design Display Type LED TV LED TV Built-in Tuner Resolution 1920 x 1080 1920 x 1080 LCD Panel TFT LCD Panel 100Hz TFT LCD Panel 100Hz Screen Size 32"/37"/40"/46"/55"...

  • Page 14: Detail Factory Option

    2. Product specifications 2-2. Detail Factory Option If you replace the main board with new one, please change the factory option as well. ※ The options you must change are "Type" and "Front Color". 2-2-1. UE60** Model Name UE32D60** UE37D60** UE40D60** UE46D60** UE55D60**...
  • Page 15 2. Product specifications 2-2-2. UE61** Model Name UE32D61** UE37D61** UE40D61** UE46D61** UE55D61** Vendor AMLCD AMLCD AMLCD AMLCD BN07-01019A BN07-01020A BN07-01018A BN07-01046A Panel CODE BN07-01017A BN07-01046A BN95-00534A BN95-00467A BN95-00466A BN95-00466A LD460CGC-C3 LD320CGC-C2 LD400CGC-C2 LD550CGC-C2 SPEC LD370CGB-C2 LD460CGB-A2 LTJ320HW02-V LTJ400HV03-V LTJ550HW03-V LTJ460HW03-V HANSOE HANSOE Vendor...
  • Page 16 2. Product specifications 2-2-4. UE63** Model Name UE32D63** UE37D63** UE40D63** UE46D63** UE55D63** Vendor AMLCD AMLCD AMLCD AMLCD AMLCD BN07-01019A BN07-01046A BN07-01020A BN07-01018A Panel CODE BN07-01017A BN07-01046A BN95-00466A BN95-00534A BN95-00467A BN95-00466A BN95-00503A LD460CGC-C3 LD550CGC-C2 LD320CGC-C2 LD400CGC-C2 SPEC LD370CGB-C2 LD460CGB-A2 LTJ550HW03-V LTJ320HW02-V LTJ400HV03-V LTJ460HW03-V LTJ550HW04-C...

  • Page 17: New Functions Explanation

    2. Product specifications 2-3. New Functions Explanation 2-3-1. Smart Hub '11 Smart Hub vs '10 Internet@TV „ '11 Smart Hub  C oncepts and Features Launcher : Internet TV, Media Play, Content Button  S earch All : Provides integrated search results for a variety of areas  F ull Browser : PC's Web browser, such as access to common web site content and applications so you can...
  • Page 18 2. Product specifications Smart Hub Concepts „ Gateway to access all type of diverse content • It's all integrated to guide you to easier diverse entertainment choice • Control your entertainment life with easy and simple user friends UI • Access to driverse Apps that are adding every day •...
  • Page 19  Your Movie: recommended movie or TV program  Top Application: popular Application list  Top Searched: popular searsh list  Search History The application provides Web and SNS based search engine.  YouTube  Facebook  Your Movie  Samsung Apps  AllShare 2-13...
  • Page 20 „ AllShare™ connects your TV and compatible Samsung mobile phones/ devices through a network. On your TV, you can view call arrivals and SMS messages, and received by your mobile phones. In addition, you can play media contents including videos, photos, and music saved on your mobile phones or the other devices (such as your PC) by controlling them on the TV via the network.
  • Page 21 2. Product specifications Using the Media Function An alarm window appears informing you that media contents (videos, photos, music) sent from a mobile phone will be displayed on your TV. The contents are played automatically 3 seconds after the alarm window appears. If you press the RETURN or EXIT button when the alarm window appears, the media contents are not played.
  • Page 22 2. Product specifications AllShare™ setup and checklists „ Problem Possible Solution Deleted mobile phone list showing up • [Menu > Application > Content View > AllShare™ > Message] again. Where need to block the added mobile phone or device again. Because deleted device would be added again if that device turns on or attempt to approach.
  • Page 23 Connected Home or Screen Share function which are found on Samsung Smartphones. • Check that the PC Share Manager is enabled, the Samsung TV is set to allow connections and the ScreenShare function on the connected cell phone is enabled. •...
  • Page 24 2. Product specifications Possible Solution Problem • AllShare (ScreenShare Server) I cannot find the remote control service Check that the ScreenShare Client device is correctly connected to the network of provided by the ScreenShare Server from the the sharing device that the DTV is connected to. ScreenShare Client.
  • Page 25 2. Product specifications 2-3-4. Media Play Media Play „ Functions that are not supported when connecting to a PC through a network: - Sorting files by preference in the Photos, Music, and Videos folders. - The � (REW) or μ (FF) button while a movie is playing. - Divx DRM, Multi-audio, embedded captions are not supported.
  • Page 26 2. Product specifications Other Restrictions N NOTE • If there are problems with the contents of a codec, the codec will not be supported. • If the information for a Container is incorrect and the file is in error, the Container will not be able to play correctly. •...
  • Page 27 2. Product specifications 2-3-5. 3D Display What is 3D Display? „ • A system that display 3D images artificially • How ?  Using binocular time delay 1 Left eye recognizes left image, right eye recognizes right image. 2 Human eyes be far away each other 65mm horizontally.
  • Page 28 2. Product specifications 2-3-6. DVB-T2 DVB-T vs T2 „ DVB-T2 Capacity „ DVB-T2 Channel capacity incresed 47% than DVB-T. 2-22...

  • Page 29: Accessories

    (UK) Warranty Card / Registration Card / Safety Guide Manual BN68-03469* (60**) User Manual BN68-03474* (61**) (Simple Guide) BN68-03475* (62**) BN68-03476* (63**) Samsung Electronics Service center Holder-Wire stand BN61-05491A Holder-Ring (4ea) BN61-05280A CI Gender 3709-001663 Scart Gender BN39-01154F Component Gender...

  • Page 30: Disassembly And Reassembly

    3. Disassembly and Reassemble 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LED TV. WARNING: This LED TV contains electrostatically sensitive devices. Use caution when handling these components. 3-1. Disassembly and Reassembly Cautions: 1.
  • Page 31 3. Disassembly and Reassemble Description Picture Description Screws Lift up and remove the rear-cover. * Caution : Becareful when you lift up the rear-cover, It’s really sharp. Remove the Speakers(R/L). Remove the Bluetooth module. 6001-002653 SCREW-MACHINE (M3, L6-WHT) Remove the screws of Main Board. 6001-002653 SCREW-MACHINE (M3, L6-WHT)
  • Page 32 3. Disassembly and Reassemble Description Picture Description Screws Remove the screws and disconnect all connectors of IP board. Remove the IP board. 6001-002653 SCREW-MACHINE (M3, L6-WHT) Remove the screws of Cover Bottom. * Notice : Cover bottom assembled basically not accessory on 11 year model.
  • Page 33 3. Disassembly and Reassemble Description Picture Description Screws Remove the panel from cover front. Reassembly procedures are in the reverse order of disassembly procedures. ※...
  • Page 34 3. Disassembly and Reassemble How to replace the function Board „ Description Picture Description Refer Remove the locking clip. Heat the function Board and Remove the function Board. Place the new function Board. FUNCTION Board (BN96-16729*) Locking the clip. Bracket-Support, PCB (BN61-07248A)

  • Page 35: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting 4-1-1. Previous check Check the various cable connections first. • Check to see if there is a burnt or damaged cable. • Check to see if there is a disconnected or loose cable connection. •...
  • Page 36 4. Troubleshooting Simple flow chart of malfunction „ Does the TV turn on? Can you see anything on the screen? Can you see OSD menu running on the screen? Can you see Digital Channel broadcast ? Check LVDS cable connected Check the Power Cord to Main Board.
  • Page 37 4. Troubleshooting USB3 USB2 OPTICAL USB1 CN201 Power HDMI4 IC1001 IC Video process HDMI3 CN1601 LVDS IC801 IC Video decoder HDMI2 CN1201_3D Function HDMI1 CN301 Speaker Component + AV PC sound SCART D-sub Headphone+ Audio L/R PIN 13 PIN 11 PIN 12 PIN 4...
  • Page 38 4. Troubleshooting 4-1-2. How to check fault symptom No Power „ Genoa-S N Refer to the next page to check the lacation such a CN201 or IC1001 SVC Manual mentioned. The LEDs on The front panel do not work when connecting The power cord. Symptom The SMPS relay does not work when connecting The power cord.
  • Page 39 4. Troubleshooting Location (Main) Detail PIN 11(B13V) PIN 7(B18VS) IC204 PIN 4(A5V) PIN 7(B18VS) IC207 IC201 IC208 IC210...
  • Page 40 4. Troubleshooting No Video (Analog PC signal) Genoa-S „ N Refer to the next page to check the lacation such a CN201 or IC1001 SVC Manual mentioned. Symptom Audio is normal but no picture is displayed on the screen. Check the PC source Major Check the Arsenal, Check the Valencia.
  • Page 41 4. Troubleshooting Location (Main) Detail IC801 CN401...
  • Page 42 4. Troubleshooting WAVEFORMS „ 1 PC input (V-sink, H-sink, R/G/B) 2 LVDS output...
  • Page 43 4. Troubleshooting No Video (HDMI 1, 2, 3, 4 - Digital Signal) „ Genoa-S N Refer to the next page to check the lacation such a CN201 or IC1001 SVC Manual mentioned. Symptom Audio is normal but no picture is displayed on the screen. Check the HDMI source Major Check the HDMI switch, Check the Valencia.
  • Page 44 4. Troubleshooting Location (Main) Detail IC601 IC1001 CN1601 4-10...
  • Page 45 4. Troubleshooting WAVEFORMS „ 1 PC input (V-sink, H-sink, R/G/B) 2 LVDS output 4-11...
  • Page 46 4. Troubleshooting No Video (Tuner_CVBS) „ Genoa-S N Refer to the next page to check the lacation such a CN201 or IC1001 SVC Manual mentioned. Symptom Audio is normal but no picture is displayed on the screen. Check the Tuner CVBS source Major Check the Tuner, Check the Valencia.
  • Page 47 4. Troubleshooting Location (Main) Detail TU702_FN IC1001 CN1601 4-13...
  • Page 48 4. Troubleshooting WAVEFORMS „ 1 CVBS OUT (Grey Bar) 2 LVDS output 4-14...
  • Page 49 4. Troubleshooting No Video (Tuner DTV) „ Genoa-S N Refer to the next page to check the lacation such a CN201 or IC1001 SVC Manual mentioned. Symptom Audio is normal but no picture is displayed on the screen. Check the DTV source. Major Check the Tuner, Check the Valencia.
  • Page 50 4. Troubleshooting Location (Main) Detail TU702_FN IC1001 CN1601 4-16...
  • Page 51 4. Troubleshooting WAVEFORMS „ 1 LVDS output 2 CH_CLK, CH_VALID 4-17...
  • Page 52 4. Troubleshooting No Video (Video CVBS) Genoa-S „ N Refer to the next page to check the lacation such a CN201 or IC1001 SVC Manual mentioned. Symptom Audio is normal but no picture is displayed on the screen. Check the Video CVBS source. Major Check the Valencia.
  • Page 53 4. Troubleshooting Location (Main) Detail R505 IC1001 CN503_EU CN1601 4-19...
  • Page 54 4. Troubleshooting WAVEFORMS „ 1 CVBS OUT (Grey Bar) 2 LVDS output 4-20...
  • Page 55 4. Troubleshooting No Video (Component) Genoa-S „ N Refer to the next page to check the location such a CN201 or IC201 SVC Manual mentioned. Symptom Audio is normal but no picture is displayed on the screen. Check the Component source Major Check the Valencia.
  • Page 56 4. Troubleshooting Location (Main) Detail COMP1_PR COMP1_PB COMP1_Y IC1001 CN1601 4-22...
  • Page 57 4. Troubleshooting WAVEFORMS „ 1 Compnent_Y (Gray scale) / Pb / Pr (Color bar) 2 LVDS output 4-23...
  • Page 58 4. Troubleshooting No Sound (1.Speaker 2.Monitor_out, 3.Optical) Genoa-S „ N Refer to the next page to check the location such a CN201 or IC201 SVC Manual mentioned. Symptom Video is normal but there is no sound. When the speaker connectors are disconnected or damaged. Major When the sound processing part of the Main Board is not functioning.
  • Page 59 4. Troubleshooting Location (Main) Detail IC303 IC1001 CN501 AV2_SR PC_SL AV2_SL PC_SR HP_SL COMP1_SL HP_SR COMP1_SR CN402 CN503_EU CN302 #4.CN301 : L- #1.CN302 #3.CN301 : L+ #2.CN301 : R- #1.CN301 : R+ 4-25...
  • Page 60 4. Troubleshooting WAVEFORMS „ 1 MCLK / LRCLK / PCM_I2C_DATA 2 Speaker / Monitor OUT , SPDIF OUT 4-26...

  • Page 61: Alignments And Adjustments

    4. Troubleshooting 4-2. Alignments and Adjustments 4-2-1. General Alignment instruction Usually, a color LED-TV needs only slight touch-up adjustment upon installation. Check the basic characteristics such as height, horizontal and vertical sync. Use the specified test equipment or its equivalent. Correct impedance matching is essential.

  • Page 62: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : ● If you do not have Factory remote - control Power OFF INFO MENU MUTE Power ON ●...

  • Page 63: Factory Data

    4. Troubleshooting 4-4. Factory Data Option Factory Menu Name Data Range Remark Factory Reset 32P1UF3E/37P1UF3E/40 Type P1UF6E/46L1UF3E/55A 2UF7E EU/EU_ITALY/EU_GER/ Local set EU_UK/EU_FRANCE/ EU_BENERUX/EU UD6000/UD6100/UD6120/ Model UD6200/UD6300/UD6350 SEC_TCS/SEC_TC/ TUNER SEC_T2C Light Effect Ch table … Country Front Color U-T-R-BK/U-T-C-BK Control Factory Menu Name Data Range Remark...
  • Page 64 4. Troubleshooting DLNA … … Play List … NETWORK Support Int-Wifi IPERF Stopped Info Link Country None Info Link Server Type development TTX List … TTX Group … ND ADJ Support 24Px4 Support Power Indicator Support BD Wise Support RF Remocon Support Data Service Support PVR Support 3D Support...
  • Page 65 4. Troubleshooting LVDS SSC ON/OFF LVDS SSC Value DDR SSC ON/Off DDR SSC Value Napoli LVDS SSC On/Off Napoli LVDS SSC MFR Napoli LVDS SSC MRR Napoli DDR SSC ON/OFF Napoli DDR SSC MFR Napoli DDC SSC MRR DDR Margin A CTRL_OFFSET_0_3 A CTRL_OFFSET_D B CTRL_OFFSET_0_3...
  • Page 66 4. Troubleshooting Cr6 TH Cr7 TH S.DEV0 S.DEV1 Checksum 0x0000 EEPROM RESET EER RESET NVR All Clear KEY SENSITIVITY NotUsed PDP Option LOGIC CONNECT PIXEL SHIFT TEST PANEL VERSION PANEL INCH PANEL TYPE PANEL TEMPERATURE LOGIC SW VERSION LOGIC SW CHECKSUM SAPC TIMER APC SPEED Real 100 Hz Support...
  • Page 67 4. Troubleshooting PD EN SOUND High Devi Carrier Mute Volume Curve Type1 Pilot Level High Thld 0x30h Pilot Level Low Thld 0x10h Chattering Cnt FM Prescale 0x14h AM Prescale 0x1Ah NICAM Prescale 0x14h Amp Volume 0xCBh Amp Scale 0x3Dh AMP Speaker EQ AMP EQ CheckSum 0xBCC084 AMP PEQ Test...
  • Page 68 4. Troubleshooting HV Flip Num Of Display DVI/HDMI SOUND Auto HDMI HOT PLUG Disable HOTPLUG SWITCHING Boot CLK TERMDURATION 300ms HOT PLUG OFF HOLD TIME 1200ms HDMI FLT CNT SIG 100ms HDMI FLT CNT LOS 100ms UNSTABLE BAN CNT 1250ms HDMI Err Cnt HDMI ROBIN HDMI Callback...
  • Page 69 4. Troubleshooting sSCC Lx sSCC Ly pSCC Const pSCC Hx pSCC Hy pSCC Lx pSCC Ly SCC Source Data SWAP Factory Menu Name Data Range Remark Test Pattern LOGIC Pattern Sel LOGIC Level Sel LDAsic Pattern Sel GenaoP Pattern Sel GenoaS Pattern Sel Napoli Pre Test Pattern Napoli Post Test Pattern...
  • Page 70 4. Troubleshooting A_Modulation_0 A_Code Rate_0 A_Timer InterLeave_0 A_Segments Num_0 A_BER_0 B_Modulation_0 B_Code Rate_0 B_Timer InterLeave_0 B_Segments Num_0 B_BER_0 C_Modulation_0 C_Code Rate_0 C_Timer InterLeave_0 C_Segments Num_0 C_BER_0 MICOM UPGRADE Temp Last Temp Read DDC Version 0x40519 DDC_CHK_SEL DDC_Check_Total IR_ON_OFF 0xaa BT ADDRESS BT UPGRADE SVC Reset Expert...
  • Page 71 4. Troubleshooting 1st_COMP_Y_Low 1st_COMP_Cb_Low 1st_COMP_Cr_Low 1st_COMP_Y_High 1st_COMP_Cb_High 1st_COMP_Cr_High 1st_COMP_Delta 1st_PC_Low 1st_PC_High 1004 2nd_AV_Low 2nd_AV_High 2nd_PC_Low 2nd_PC_High 2nd_Delta ADC Result 1st_Y_GH 1st_Y_GL 1st_Cb_BH 1st_Cb_BL 1st_Cr_RH 1st_Cr_RL 2nd_R_L 2nd_G_L 2nd_B_L 2nd_R_H 2nd_G_H 2nd_B_H White Balance Sub Brightness R-Offset G-Offset B-Offset Sub Contrast R-Gain G-Gain B-Gain...
  • Page 72 4. Troubleshooting Advanced Factory Menu Name Data Range Remark Picture_2D FBE3 BM_slope BM_start BM_start_max Lfunc_gain Hfunc_gain ACR-Offset Skin-UV FBE Sub color M-Skin-UV M-Sub Color N_Skin_UV N_Sub_Gamma Color Gamut LFUNC_TH1 LFUNC_TH2 LFUNC_TH3 LFUNC_OUT2 LFUNC_OUT3 LFUNC_OUT4 LFUNC_OUT5 UFUNC_TH1 UFUNC_TH2 UFUNC_TH3 UFUNC_OUT2 UFUNC_OUT3 UFUNC_OUT4 UFUNC_OUT5 PPHC_Red...
  • Page 73 4. Troubleshooting MSub Brightness MSub Contrast N_Rgain N_Bgain N_Roffset N_Boffset W1_Rgain W1_Bgain W1_Roffset W1_Boffset W2_Rgain W2_Bgain W2_Roffset W2_Boffset Movie Contrast Movie Bright Movie Color Movie Sharpness Movie Tint Movie Backlight Movie Gamma M_Sub_Gamma HDMI Black Level SubSetting Gamma 0.95 PWM Max PWM Mid PWM Min Contrast Dimming...
  • Page 74 4. Troubleshooting Auto_Blue_R Auto_Blue_G Auto_Blue_B Auto_Yellow_R Auto_Yellow_G Auto_Yellow_B Auto_Cyan_R Auto_Cyan_G Auto_Cyan_B Auto_Magenta_R Auto_Magenta_G Auto_Magenta_B EPA 3D Standard Contrast Standard Brightness Standard Sharpness Standard Color Standard Tint Standard Backlight 3D Contrast 3D Brightness V_3D PWM Delay_60 V_3D ANA Delay_60 V_3D PWM Delay_50 V_3D ANA Delay_50 Motion plus Delay Home Delay...
  • Page 75 4. Troubleshooting FB_Delay_adj RGB_Delay_adj slice_mod_fine scm_fdet_lvl bl_range AR_ADC PHASE SOG_BW SSC_PC RGB_DLY YC_Delay PAL_BG PAL_DK PAL_I PAL_M PAL_N SECAM_BG SECAM_DK SECAM_L NTSC_358 NTSC_443 AV_PAL AV_PAL_M AV_PAL_N AV_SECAM AV_NT358 AV_NT443 AV_PAL60 CH_DP BD_MAX_PERCENT_X BD_MAX_PERCENT_Y BD_DETAIL_AMT_MAX BD_TOUCH_SUPP BD_TOUCH_SUP_INV DR_SIGMA_FIL_GAIN DR_GAIN_IN_ETE SD2HD_Metric Sharpness Pre_GainH1 Pre_GainH2 Pre_GainH3...
  • Page 76 4. Troubleshooting Pre_GainV1 Pre_GainV2 Pre_GainV3 Post_GainH1 Post_GainH2 Post_GainH3 Post_GainV1 Post_GainV2 Post_GainV3 Post_GainPE1 Post_GainPE2 Post_GainPV1 Post_GainPV2 CTI_Gain Pre_LTIH LTI_H LTI_V PRE_CORING_H PRE_CORING_V POST_CORING Pre_TOT Post_TOT SH Sub Color Sharpness_LNA S1_Pre_GainH1 S1_Pre_GainH2 S1_Pre_GainH3 S1_Pre_GainV1 S1_Pre_GainV2 S1_Pre_GainV3 S1_Post_GainH1 S1_Post_GainH2 S1_Post_GainH3 S1_Post_GainV1 S1_Post_GainV2 S1_Post_GainV3 S1_Post_GainPE1 S1_Post_GainPE2 S1_Post_GainPV1...
  • Page 77 4. Troubleshooting S2_Pre_GainH2 S2_Pre_GainH3 S2_Pre_GainV1 S2_Pre_GainV2 S2_Pre_GainV3 S2_Post_GainH1 S2_Post_GainH2 S2_Post_GainH3 S2_Post_GainV1 S2_Post_GainV2 S2_Post_GainV3 S2_Post_GainPE1 S2_Post_GainPE2 S2_Post_GainPV1 S2_Post_GainPV2 S3_Pre_GainH1 S3_Pre_GainH2 S3_Pre_GainH3 S3_Pre_GainV1 S3_Pre_GainV2 S3_Pre_GainV3 S3_Post_GainH1 S3_Post_GainH2 S3_Post_GainH3 S3_Post_GainV1 S3_Post_GainV2 S3_Post_GainV3 S3_Post_GainPE1 S3_Post_GainPE2 S3_Post_GainPV1 S3_Post_GainPV2 LNA_Plus Synctip_Noise 4-43...
  • Page 78 4. Troubleshooting LNA+_Yfilter FRCS FRCS LVDS Format FRCS LVDS BitWidth FRCS LVDS Sequence FRCS Hangup Detection FRCS FMD Demo LDAsic R_LD4_L3DD_RATIO R_LD4_LD_ON R_DELAY R_ALL_READ R_LVDS_TX_FMT R_LVDS_SW EmitOn EmitStartPosi60 EmitStartPosi50 EmitStartPosi48 3DSyncVstart60 3DSyncVend60 3DSyncVstart50 3DSyncVend50 3DSyncVstart48 3DSyncVend48 2D3D Focus 2D3D Depth1 2D3D Depth2 2D3D Depth3 2D3D Depth4...
  • Page 79 4. Troubleshooting N240 ANA Delay_50 N240 PWM Delay_48 N240 ANA Delay_48 Reading POST_FDISPLAY RAMP_SPEED POST_RAMP_SPEED LVDS_RX_FMT LVDS_TX_FMT LVDS_RX_BIT LVDS_TX_BIT POST_OUT1_ORDER POST_OUT2_ORDER POST_OUT3_ORDER POST_OUT4_ORDER CROSS_PATTERN EnableFB HMVSRMargin_2X_H HMVSRMargin_2X_M HMVSRMargin_2X_L VMVSRMargin_2X HSADPercentT1_2X HSADPercentT2_2X HMVSRMargin_FILM_H HMVSRMargin_FILM_M HMVSRMargin_FILM_L VMVSRMargin_FILM HSADPercentT1_FILM HSADPercentT2_FILM LEDDriver VSYNC_DELAY_3D_50 VSYNC_DELAY_3D_60 FRCQ Option SSC_OnOff SSC_Width...
  • Page 80 4. Troubleshooting X_VStabStatF X_VStabCorF X_VStabSensF X_HaloSizStatVid X_HaloSizStatF X_HaloSizCorF X_HaloSizSensF Film_Low_SD Film_Medium_SD Film_High_SD Film_Low_HD Film_Medium_HD Film_High_HD Video_Judder_Low Video_Judder_Med Video_Judder_High Hangup Detection Q LVDS Sequence Q LVDS Format Q LVDS bit width PC_Mode_OnOff FRCQ Fallback SensD_Film_Low SensD_Film_Medium SensD_Film_High Rel_Start_Film Rel_Slope_Film H_Len_Start_Film H_Len_Slope_Film V_Len_Start_Film V_Len_Slope_Film SensD_Video...

  • Page 81: White Balance

    4. Troubleshooting 4-5. White Balance 4-5-1. Calibration ADC/WB AV Calibration Comp Calibration PC Calibration HDMI Calibration 4-6-2. Service Adjustment You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration „ Adjust spec. 1. Source : HDMI 2.
  • Page 82 4. Troubleshooting Method of Color Calibration (AV) „ 1) Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port 2) Press the Source key to switch to "AV1" mode 3) Enter Service mode 4) Select the "ADC/WB" and "ADB" menu 5) Select the "AV Calibration"...

  • Page 83: Software Upgrade

    4. Troubleshooting 4-6. Software Upgrade Software Upgrade can be performed by network connection or downloading the latest firmware from “www. samsung.com” to a USB memory device. By USB „ Insert a USB drive containing the firmware upgrade file, downloaded from “www.samsung.com” into the TV.

  • Page 84: Sub Micom Upgrade

    4. Troubleshooting 4-7. Sub Micom Upgrade How to update submicom „ SUB MICOM FW is include in MAIN FW. In the Factory mode „ SVC  MICOM UPGRADE  (off  wait) about 7minutes later, It will be reset automatically (Turn off/on). Check version of sub micom FW in Factory mode.

  • Page 85: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5-1. Wiring Diagram For 32"_37"_40"_46"...
  • Page 86 5. Wiring Diagram For 55"...

  • Page 87: Connector

    5. Wiring Diagram 5-2. Connector For common CN1601_FHD (to Panel) CN602(to HDMI1) TX1_AN HDMI1_RX2+ HDMI1_RXCLK- TCON_EEPROM_WP HDMI1_RX2- HDMI_CEC BLACK_INS_SYNC HDMI1_RX1+ TCON_RESET HDMI1_DDC_SCL PANEL_VCC HDMI1_RX1- HDMI1_DDC_SDA PANEL_VCC HDMI1_RX0+ SDA_TCON PANEL_VCC HDMI1_5V PANEL_WP PANEL_VCC HDMI1_RX0- HDMI1_HPD LUT_SELECT0 PANEL_VCC HDMI1_RXCLK+ 3D_ENABLE CN603(to HDMI2) SCL_TCON TX2_AN HDMI2_RX2+...
  • Page 88 5. Wiring Diagram CN401(to PC) CN503_EU(to SCART) PC_RED PC_5V PC_GREEN IDENT_PC SC1_G PC_BLUE SDA_DOWN PC_H_SYNC SC1_AV_CVBS_IN IDENT_SC1_AV PC_V_SYNC SC1_B SCL_DOWN SC1_CVBS_OUT SC1_AV_SL_IN SC1_FB SC1_AC_SR_IN CN402(to PC Sound) SC1_R SC1_SL_OUT PC_SL_IN SC1_SR_OUT PC_SR_IN CN404(to Component & AV) CN301(to Speaker) COMP_Y_AV1 IDENT_COMP COMP_PB AV1_SL_IN CN303(to Optical Jack)

  • Page 89: Connector Functions

    5. Wiring Diagram 5-3. Connector Functions Connector Functions CN201  CN803 Supply power from SMPS to Main Board. The LVDS signal transfered from Main Board to Panel. CN1601  J101 5-4. Cables Main-SMPS Main-Tcon 32" : BN39-01486A 32" : BN96-18130A 37"...
