For a DM NVX transmitter or receiver, configure DM NAX (AES67) audio in Slot-18: DM
NAX (AES67) Routing. In order for a DM NVX device to transmit DM NAX (AES67) audio,
configure DM NAX (AES67) audio in Slot-18-01: DM NAX (AES67) TX. In order for a DM
NVX device to receive DM NAX (AES67) audio, configure DM NAX (AES67) in Slot-18-33:
DM NAX (AES67) RX. For additional information, refer to the SIMPL Windows help file.

Dante and AES67 Audio Embedding and De-embedding

NOTE: This section applies to the DM-NVX-363 and DM-NVX-363C only.
Dante and AES67 support allows the selected audio source to be transmitted as a
2-channel Dante or AES67 source while another 2-channel Dante or AES67 audio stream
is received from a Crestron DSP or other third-party device and combined with the video
signal.
When the DM-NVX-363(C) functions as a transmitter, the Dante or AES67 received
audio stream can be output via the local HDMI output, primary AV stream, secondary
audio stream, and analog audio output. When the DM-NVX-363(C) functions as a
receiver, the Dante or AES67 received audio stream can be combined with the video and
then output via the HDMI output and analog audio output.
NOTE: An AES67 stream that is received by a DM NVX
that endpoint.
Prerequisites for Dante or AES67 audio networking consist of the following:
1. Audio routing between Dante or AES67 devices requires Audinate® Dante
Controller software. Download Dante Controller software from the Audinate
website at www.audinate.com/products/software/dante-controller.
2. Dante and AES67 audio can coexist with DM-NVX-363(C) devices on the same
network; however, additional network considerations may need to be addressed.
For Ethernet switch guidelines, refer to the information provided on the Audinate
website at
3. For AES67 audio networking with DM-NVX-363(C) devices, enable AES67 mode
using the Dante Controller software. Enabling AES67 mode results in a multicast
stream that is compatible with AES67 receiver and transmitter devices.
4. For additional information, go to www.audinate.com.
To configure Dante or AES67 audio for DM-NVX-363(C) devices, use the web interface or
SIMPL Windows as discussed in the following sections.
30 • DM-NVX-36x(C) Encoders/Decoders
www.audinate.com/networks-and-switches.
endpoint cannot be transmitted from
