Crestron DM-MD8X8/16X16/32X32
Di g i t al M edi a ™ Swi t chers
Operations Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM-MD8X8 and is the answer not in the manual?

Questions and answers

Related Manuals for Crestron DM-MD8X8

Summary of Contents for Crestron DM-MD8X8

  • Page 1 Crestron DM-MD8X8/16X16/32X32 Di g i t al M edi a ™ Swi t chers Operations Guide...

  • Page 2: Important Safety Instructions

    Prevent foreign objects from entering the device. This device includes an aggregation of separate independent works that are each generally copyrighted by Crestron Electronics, Inc., with all rights reserved. One of those independent works, Linux Bridge Project, is copyrighted under the GNU GENERAL PUBLIC LICENSE, Version2, reproduced in “GNU General Public License”...

  • Page 3: Regulatory Compliance

    Regulatory Compliance As of the date of manufacture, this unit has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. Federal Communications Commission (FCC) Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Table Of Contents

    Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers Contents DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Introduction ..........................1 Features and Functions ....................1 Applications.........................6 Internal Block Diagrams....................7 Specifications ......................9 Physical Description....................15 Setup ............................28 DigitalMedia Wiring ....................28 HDCP Signal Path .....................30 Ethernet Setup ......................32 Identity Code ......................32 Installation .........................33 Hardware Hookup .....................34...
  • Page 6 Appendix C: Output Configuration ..................175 Glossary ..........................180 Return and Warranty Policies ....................184 Merchandise Returns / Repair Service ..............184 CRESTRON Limited Warranty................184 Trademark Information ................... 185 GNU General Public License ....................186 Contents Operations Guide – DOC. 6755C...

  • Page 7: Digitalmedia™ Switchers: Dm-Md8X8/16X16/32X32

    DigitalMedia™ (DM) switchers provide the foundation for a complete DigitalMedia system, delivering a true high-definition multi-room AV signal routing solution that is flexible and installer-friendly. The DM-MD8X8, DM-MD16X16, and DM-MD32X32 afford low-latency switching and pure, lossless distribution of HDMI™ and other signals to support the latest Blu-ray Disc™ players, HDTV receivers, digital media servers, computers, and other AV devices.
  • Page 8 DM-MD16X16 are factory-configurable to provide up to 16 DM room outputs and/or HDMI outputs in a single chassis, with expansion capability possible for up to 80 outputs using multiple chassis. The outputs of the DM-MD8X8 are field-configurable to provide up to eight DM room outputs and/or HDMI outputs in a single chassis, with expansion capability possible for up to 40 outputs using multiple DM-MD8X8 chassis.
  • Page 9 LAN connection. Its Gigabit Ethernet connection to the external LAN helps maximize bandwidth for each network port. Ethernet is also utilized internally by the Crestron control bus to manage all of the DM devices in the system and provide display control in each room.
  • Page 10 QuickSwitch HD Technology Crestron QuickSwitch HD technology minimizes the switching latency that plagues typical HDMI switchers. As the move to digital takes hold, more and more movie studios and television service providers are using HDCP (High-bandwidth Digital Content Protection) to protect their DVDs, Blu-ray Discs, and broadcast signals against unauthorized copying.
  • Page 11 DigitalMedia™ Switchers CEC Embedded Device Control The primary objective of every Crestron system is to enable precisely the control desired for a seamless user experience. DigitalMedia provides an alternative to conventional IR and RS-232 device control by harnessing the CEC (Consumer Electronics Control) signal embedded in HDMI.

  • Page 12: Applications

    DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 Applications The following diagram shows a DM-MD8X8 in a lecture hall application. DM-MD8X8 in a Lecture Hall Application DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 13: Internal Block Diagrams

    Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers Internal Block Diagrams The following diagrams represent the switching abilities of the DM switchers. Internal Block Diagram of the DM-MD8X8 DM-MD8X8 Internal Block Diagram Fr om Input To Output Digital Video /Audio Switch cards (x8) Modules (x8) 3.4Gbps bandwidth...
  • Page 14 Stereo Input Card Audio Audio (x16) (typical) 10/100 ENET (x16) 10/100 To/From Output ENET To/From Managed Ethernet Switch Modules (x32) Input cards (x32) Gbit To/From DM-MD32X32 CPU To/From external LAN port ENET DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 15: Specifications

    Switcher DM-MD8X8: 8x8 digital matrix, modular input/output cards, Crestron QuickSwitch HD DM-MD16X16: 16x16 digital matrix, modular input/output cards, Crestron QuickSwitch HD DM-MD32X32: 32x32 digital matrix, modular input/output cards, Crestron QuickSwitch HD Input Signal Types Configurable via modular plug-in cards supporting HDMI, DisplayPort Multimode...
  • Page 16 SMPTE 296M (HD-SDI): 1280x720@24Hz (720p24), 1280x720@25Hz (720p25), 1280x720@30Hz (720p30), 1280x720@50Hz (720p50), 1280x720@60Hz (720p60); SMPTE 259M-C (SD-SDI): 720x480@59.94 (NTSC), 720x576@50i (PAL) Output Resolutions Matched to inputs Backplane Data Rate 12.5 Gbps (Continued on following page) DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 17 DigitalMedia DM fiber, DM CAT, DMNet, HDCP management, EDID format management, Ethernet 10/100/1000BASE-T, auto-switching, auto-negotiating, auto-discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, RSTP Supports USB HID class devices (Continued on following page) Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 18 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM Switcher Specifications (Continued) SPECIFICATION DETAILS DM-MD8X8: Provides (1) onboard Ethernet Switch 10/100/1000BASE-T Gigabit Ethernet port, (1) internal 10BASE-T/100BASE-TX Ethernet port for the switcher, and (16) remote 10BASE-T/100BASE-TX Ethernet ports via select outboard devices DM-MD16X16: Provides (1) onboard...
  • Page 19 6.97 in (177 mm) without feet DM-MD16X16: 12.22 in (311 mm) without feet DM-MD32X32: 24.44 in (621 mm) without feet Width DM-MD8X8 and DM-MD16x16: 17.28 in (439 mm) without ears 19.00 in (483 mm) with ears DM-MD32X32: 19.15 in (487 mm) Depth DM-MD8X8 &...
  • Page 20 1. DisplayPort Multimode connectivity is supported via an HDMI or DVI input port using a suitable adapter or interface cable (not included). 2. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following these footnotes.

  • Page 21: Physical Description

    DigitalMedia™ Switchers Physical Description This section provides information on the connections, controls and indicators available on the DM switchers. DM-MD8X8 Physical View (Front) DM-MD8X8 Physical View (Rear, Shown with Optional DM Cards) Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 22 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM-MD16X16 Physical View (Front) DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 23 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers DM-MD16X16 Physical View (Rear, Shown with Optional DM Cards) Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 24 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM-MD32X32 Physical View (Front) DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 25 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers DM- MD32X32 Physical View (Rear, Shown with Optional DM Cards) Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 26 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM-MD8X8 & DM-MD16X16 Overall Dimensions 18.13 in (461 mm) 6.97 in DM-MD8X8 (177 mm) 17.28 in (439 mm) 12.22 in DM -M D16X16 (311 mm) NOTE: Cable connections can extend the overall depth of the DM switcher by approximately two to three inches.
  • Page 27 (487 mm) 15.72 in 17.28 in (400 mm) (439 mm) 24.44 in (621 mm) NOTE: Cable connections can extend the overall depth of the DM switcher by approximately two to three inches. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 28 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM-MD8X8 Buttons and Ports DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 29 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers DM-MD16X16 Buttons and Ports Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 30 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM-MD32X32 Buttons and Ports DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 31 (8) pushbuttons and red LEDs, select input for routing DM-MD16X16 (16) pushbuttons and red LEDs, select input for routing DM-MD32X32 (32) pushbuttons and red LEDs, select input for routing (Continued on following page) Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 32 Ethernet activity DM OUTPUT SLOT DM-MD8X8 and DM-MD16X16 1 & 2 / 1-8 (2) DM switcher output card slots; Each slot accepts (1) 4-channel (DM-MD8X8) or (1) 8-channel (DM-MD16X16) DM output card; DM-MD32X32 (8) DM switcher output card slots; Each slot accepts (1) 4-channel DM output card;...
  • Page 33 (1) 6-32 screw, chassis ground lug 1. Interface connectors for DMNET and EIG ports are provided with the unit. 2. Output cards on DM-MD8X8 and DM-MD32X32 are field-installable (DMC-series). Output cards on DM-MD16X16 (DMCO-series) require factory installation. 3. For external DMNet power, use Crestron CNPWS-75, C2N-SPWS300, or other Cresnet power supply as required.

  • Page 34: Setup

    Setup DigitalMedia Wiring Connections between DigitalMedia Switchers and DigitalMedia Room Controllers can be made using a variety of wiring solutions. For optimum performance, Crestron recommends Crestron DigitalMedia cable or CresFiber. When wiring the DigitalMedia network, consider the following: Use Crestron Certified Wire.
  • Page 35 Up to two repeaters can be used to extend the transmission distance between the DM switcher and the Room Controller. The following diagram illustrates the maximum hop length between switcher/room controller and repeaters and maximum aggregate cable length. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 36: Hdcp Signal Path

    H = The maximum hop distance between a DM Switcher/ DM-RMC-100 Room Controller and a DM-DR Repeater T = The maximum total distance from the DM Switcher to the DM-RMC-100 Room Controller For more information on DigitalMedia and other cable products, visit the Crestron website (http://www.crestron.com/wireoverview).
  • Page 37 The HDCP specification states that the maximum depth of devices between source and display is six. Some examples are shown in the following diagram. Examples of Reported HDCP Devices and Reported HDCP Depth Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 38: Ethernet Setup

    Tools to set the IP ID, refer to “Control System IP ID” on page 48. For information on setting an IP table, refer to the Crestron Toolbox help file. The IP IDs of multiple DM switchers in the same system must be unique.

  • Page 39: Installation

    2. Position a rack ear so that its mounting holes align with the holes vacated by the screws in step 1. 3. Secure the ear to the unit with three screws from step 1, as shown in the following diagram. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 40: Hardware Hookup

    For details on making connections to installed DM input cards and DM output cards, refer to “Appendix A: Hardware Hookup for DM Cards” on page 75. Apply power after all connections have been made. When making connections to the DM switcher, use Crestron power supplies for Crestron equipment. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 41 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers Hardware Connections for the DM-MD8X8, Front COMPUTER: To USB Port On PC Hardware Connections for the DM-MD16X16, Front COMPUTER: To USB Port On Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 42 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 Hardware Connections for the DM-MD32X32, Front COMPUTER: To USB Port On DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 43 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers Hardware Connections for the DM-MD8X8, Rear DM INPUT CARD SLOTS 1-4: DM INPUT CARD SLOTS 5-8: DM OUTPUTS (SLOT 1): DMNET PORTS (SLOT 1): Install Cards to Receive Input Install Cards to Receive Input Install Card to Transmit DigitalMedia...
  • Page 44 Tie All Source and 10/100/1000BASE-T Connect to DM Receivers and Select DigitalMedia Signals to DigitalMedia From Line Voltage Device Grounds to Ethernet to LAN Internal or External Power Room Controllers GROUND Terminal DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 45 10/100/1000BASE-T Connect to DM Receivers and Select Install Cards to Transmit DigitalMedia From Line Voltage Device Grounds to Ethernet to LAN Internal or External Power Signals to DigitalMedia Room Controllers GROUND Terminal Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 46 Providing DMNet Power Internally Label the Buttons Use Crestron Engraver software to print custom labels for the DM switcher’s front panel buttons and LEDS. Crestron recommends printing on 100-pound paper. Paper with a weight less than 100 pounds will tend to crumple while sliding in, while paper with a weight of more than 100 pounds may not fit.

  • Page 47: Configuration

    After making all hardware connections, the DM switcher must be configured for operation. The DM switcher can be configured from the DM switcher’s front panel using Installer Tools or from a PC using Crestron Toolbox. This document contains instructions for using Installer Tools. For information on using Crestron Toolbox to configure the DM switcher, refer to the Crestron Toolbox help file.

  • Page 48: Inputs

    To open the Inputs section of Installer Tools: 1. Open Installer Tools as described on page 41. 2. Turn the selection knob to highlight Inputs and press the ENTER button. A list of installed input cards will be displayed. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 49: Outputs

    3. To configure an output, turn the selection knob to highlight an output and press the ENTER button. For instructions on configuring a specific output card, refer to “Appendix C: Output Configuration” on page 175. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 50: Network

    IP Address DM switchers use TCP/IP communications for communications between network devices, the Crestron control system and other devices. The IP address can be obtained from a DHCP server or manually set. For information on using DHCP to obtain an IP address, refer to “DHCP” on page 46. To view or set the IP address: 1.
  • Page 51 3. Press the soft button under the octet to be adjusted. 4. Turn the selection knob to the desired number. 5. Repeat for each octet until the Subnet Mask address is displayed. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 52 A DM switcher’s IP address can be obtained from a DHCP server or manually set using Crestron Toolbox. The default setting for the DHCP mode is “On”. For information on manually setting the IP address, refer to “IP Address” on page 44. To set the DHCP mode: 1.
  • Page 53 Move the cursor to another position by pressing the soft buttons labeled . To delete a character, press the soft button marked Del. NOTE: The maximum length for the hostname is 64 characters. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 54 2. Turn the selection knob to highlight Control System IP Address and press the ENTER button to display the Control System IP Address controls. If previously entered, the IP address of the control system will be displayed. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 55: Control

    To open the Control section of Installer Tools: 1. Open Installer Tools as described on page 41. 2. Turn the selection knob to highlight Control and press the ENTER button. A list of functions will be displayed. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 56 1. Open the Control section as described on page 49. 2. Turn the selection knob to highlight Password and press the ENTER button to display the Password controls. The current password is displayed. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 57 Front Panel Lock Controls Front Panel Lock Unlock * Lock 3. Turn the selection knob to highlight Lock or Unlock. The current setting is indicated with an asterisk (*). Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 58: Firmware Configuration

    1. Open the Control section as described on page 49. 2. Turn the selection knob to highlight About and press the ENTER button to display the About controls. About Controls About Hardware Configuration Firmware Configuration DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 59: Message Log

    To open the Message Log section of Installer Tools: 1. Open Installer Tools as described on page 41. 2. Turn the selection knob to highlight Message Log and press the ENTER button. The Message Log will be displayed. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 60: Commission System

    HDMI using HDCP authentication. To run an HDCP check: 1. Open the Commission System section as described on page 54. 2. Turn the selection knob to highlight HDCP Check and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 61 Analysis of Cards to Be Tested HDCP Check Status 1. Non-HDCP Card 2. Non-HDCP Card 3. Will Be Tested Back A progress bar will be displayed to show the progress of the HDCP check. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 62 HDCP Check Results HDCP Check Results Input 1 (DVD) Max HDCP Keys: 9 Possible Destinations: 8 DONE << >> Press the soft buttons labeled to scroll through the results for other inputs. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 63 5. Turn the selection knob to highlight an output for testing and press the ENTER button to mark it. Outputs to be tested are marked with an asterisk (*). To test all of the outputs, press the soft button labeled All. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 64 Data Rate Check - Success Kid’s Room – 2.22Gbps Living Room – 3.60Gbps Kitchen – 2.22Gbps Resolution Done If an error was encountered during the data rate check, an error message will be displayed. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 65 EDID on the input card receivers. Using Crestron Toolbox, the DM switcher can be configured to use several different algorithms to determine what EDID information is sent to each source:...
  • Page 66 Manual Use Crestron Toolbox to select which resolutions are transmitted to the source. “Best Common” is initially set to use information from all displays, but can be modified to use information from just a subset of displays by deselecting them in Crestron Toolbox.

  • Page 67: Programming Software

    Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at www.crestron.com/support.
  • Page 68 2. The system tree of the control system displays the device in the appropriate slot with a default IP ID as shown in the following illustration. C2ENET-1 Net Device, Slot 8 (DM-MD8X8 shown) 3. Additional DM switchers are assigned different IP ID numbers as they are added.
  • Page 69 To configure a SIMPL Windows program for this layout, drop DM-RMC-100-F devices onto the output cards that are on the DM-Switcher as shown in the following diagram. The IP table of each DM-RMC-100-F will be automatically configured and uploaded. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 70 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 DM-RMC-100-Fs Placed on DMCO-10 Outputs DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 71: Example Program

    DM-RMC-100-F will require manual configuration. Program Manager Program Manager is the view where programmers “program” a Crestron control system by assigning signals to symbols. The symbol can be viewed by double clicking on the icon or dragging it into Detail View.

  • Page 72: Uploading And Upgrading

    The COMPUTER port on the DM switcher connects to the USB port on the PC via the included Type A to Type B USB cable. 1. Use the Address Book in Crestron Toolbox to create an entry using the expected communication protocol (USB). When multiple USB devices are connected, identify the DM switcher by entering “DM-MD8X8”,...

  • Page 73: Programs And Firmware

    8-pin RJ-45 connectors. Alternatively, use a CAT5 crossover cable to connect the two LAN ports directly without using a hub or router. 4. Use the Address Book in Crestron Toolbox to create an entry for the DM-MD8X8, DM-MD16X16, or DM-MD32X32 with the DM switcher’s TCP/IP communication parameters.

  • Page 74: Dm Tool

    IP address 127.0.0.1. DM Tool In the Crestron Toolbox Address Book, select the DM switcher. Then use the DM Tool to configure EDID, HDCP or to troubleshoot AV on the DM switcher. Refer to the help file for additional information.

  • Page 75: Operation

    Operating Modes A DM switcher can operate in the Route mode, the View mode, or the Info mode. The DM switcher can also be controlled from Crestron Toolbox. For more information, refer to the Crestron Toolbox help file. Route Mode The Route mode uses the front panel controls to route input signals to outputs.

  • Page 76: View Mode

    All outputs that are receiving the same input signal are also displayed. 2. Press AUDIO, VIDEO, or USB to see the input that is providing the audio, video, or USB portions of the output signal. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 77: Info Mode

    HDMI port can be selected for viewing by pressing the soft button of the desired output. 2. Turn the selection knob to display available information. 3. Press another output button to view its information. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 78: Problem Solving

    DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. DM Switcher Troubleshooting TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION Incorrect Audio or...

  • Page 79: Check Network Wiring

    100 ft (30 m) 300 ft (91 m) NOTE: All Crestron certified DMNet wiring must consist of two twisted pairs. One twisted pair is the +24V conductor and the GND conductor and the other twisted pair is the A conductor and the B conductor.

  • Page 80: Reference Documents

    Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. You can also log onto the online help section of the Crestron website (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features.

  • Page 81: Appendix A: Hardware Hookup For Dm Cards

    DM switcher, with a potential cable length up to 450 feet (137 m) using DigitalMedia cable. NOTE: For optimum performance, Crestron recommends Crestron DigitalMedia cable. Additional connections on the card include both HDMI and stereo analog audio loopback outputs.
  • Page 82 DM switcher, with a potential cable length up to 450 feet (137 m) using DigitalMedia cable. NOTE: For optimum performance, Crestron recommends Crestron DigitalMedia cable. The DMC-CAT-DSP provides all of the features of the DMC-CAT with the addition of internal DSP processing to enable the simultaneous distribution of uncompressed 7.1 channel HD surround sound and 2-channel audio.
  • Page 83 DM switcher for output expansion purposes. The USB HID host port allows a remote mouse/keyboard connected at the display location, to control a centralized source device (i.e. computer, media server, etc.) at the equipment rack. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 84 UNBALANCED AUDIO INPUT L – signal return, jumper to GND Shield/Ground Ground R – signal return, jumper to GND Typical Balanced/Unbalanced Inputs Unbalanced Balanced Input Input Shield Jumpers Left Left Shield Right Right Shield DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 85 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers The BNC output of a wideband RGB switcher such as the Crestron CEN-RGBHV12X4 can be connected to a DMC-DVI using either a BNC-to-DVI adapter (not included) or a BNC-VGA adapter (not included) with the included VGA-DVI adapter to provide further expansion. When connecting sources to the switcher, please make the following connections.
  • Page 86 DM switcher, with a potential cable length up to 1000 feet (300 m) using multimode fiber optic cable. NOTE: For optimum performance, Crestron recommends Crestron DigitalMedia cable. The DMC-F-DSP provides all of the features of the DMC-F with the addition of internal DSP processing to enable the simultaneous distribution of uncompressed 7.1...
  • Page 87 2-channel audio, use model DMC-HD-DSP. The USB HID port allows a remote mouse/keyboard connected at the display location, to control a centralized source device (i.e. computer, media server, etc.) at the equipment rack. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 88 The USB HID port allows a remote mouse/keyboard connected at the display location, to control a centralized source device (i.e. computer, media server, etc.) at the equipment rack. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 89 For instance, it can be used to convert SDI video and audio to HDMI, or to extract an analog audio signal from an SDI signal. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 90 NTSC/PAL composite and S-video. An HDMI loop back output connection is also provided, which passes the audio and video input signals through digitally to feed a local device, or to feed a second DM switcher for output expansion purposes. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 91 AUDIO INPUT L – signal return jumper to GND Shield/Ground Ground R – signal return jumper to GND Typical Balanced/Unbalanced Inputs Balanced Unbalanced Input Input Shield Jumpers Left Left Shield Right Right Shield Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 92 An HDMI loop back output connection is also provided, which passes the audio and video input signals through digitally to feed a local device, or to feed a second DM switcher for output expansion purposes. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 93: Output Connections

    DM output cards. D & M Ports Using DM Cable For cards equipped with DM cable connection (RJ-45) refer to the following diagram. Hardware Hookup for DM Cable Outputs Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 94 Hardware Hookup for DM Fiber Outputs To DM Receiver DMNET: To DM Receiver (Optional) NOTE: When wiring the 24ABG port, connect the 24 and G lines only. Do not connect the A and B lines. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 95 UNBALANCED AUDIO OUTPUT L – signal return, jumper to GND Shield/Ground Ground R – signal return, jumper to GND Typical Balanced/Unbalanced Inputs Balanced Unbalanced Output Output Shield Jumpers Left Left Shield Right Right Shield Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 96: Appendix B: Input Card Configuration

    Video Input Card with Analog Audio for DM Switchers, refer to “DMC-VID-RCA-A” on page 161. For information on configuring the DMC-VID-RCA-D RCA Analog Video Input Card with Digital Audio for DM Switchers, refer to “DMC-VID-RCA-D” on page 168. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 97: Dmc-Cat

    To cancel and return to the list of options for the input card, press the MENU button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 98 The DMC-CAT can display information about the audio portion of the incoming signal. Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 99 The loopback output can be set to enable or disable the deep color feature of the carried video signal. To enable or disable deep color: i. Turn the selection knob to highlight Allow Deep Color and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 100 Press the MENU button to return to the Loopback Settings. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 101 The card can be configured to use specifc types of cables for the DM input signal. To view or select a cable type: 1. Turn the selection knob to highlight DM Cable Type and press the ENTER button. The selected cable type is displayed with an asterisk (*). Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 102 The number of HDCP keys specify the number of display devices that can be connected to a source over HDMI using HDCP authentication. To run an HDCP check: 1. Turn the selection knob to highlight HDCP Check and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 103 OK to begin the HDCP check. A progress bar will be displayed to show the progress of the HDCP check. HDCP Check in Progress HDCP Check Test in Progress... When the check is complete the results will be displayed. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 104 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 105: Dmc-Cat-Dsp

    To cancel and return to the list of options for the input card, press the MENU button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 106 The DMC-CAT-DSP can display information about the audio portion of the incoming signal. Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 107 The loopback output can be set to enable or disable the deep color feature of the carried video signal. To enable or disable deep color: i. Turn the selection knob to highlight Allow Deep Color and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 108 Press the MENU button to return to the Loopback Settings. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 109 The card can be configured to use specifc types of cables for the DM input signal. To view or select a cable type: 1. Turn the selection knob to highlight DM Cable Type and press the ENTER button. The selected cable type is displayed with an asterisk (*). Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 110 The number of HDCP keys specify the number of display devices that can be connected to a source over HDMI using HDCP authentication. To run an HDCP check: 1. Turn the selection knob to highlight HDCP Check and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 111 OK to begin the HDCP check. A progress bar will be displayed to show the progress of the HDCP check. HDCP Check in Progress HDCP Check Test in Progress... When the check is complete the results will be displayed. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 112 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 113: Dmc-Dvi

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name < > Done Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 114 Turn the selection knob to highlight Picture Controls and press the ENTER button. b. Turn the selection knob to highlight the picture control to be adjusted and press the ENTER button. Controls are available for brightness, contrast, saturation, and hue. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 115 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers Brightness Control Input 6 Video Settings Brightness Contrast Control Input 6 Video Settings Contrast Saturation Control Input 6 Video Settings Saturation Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 116 DMC-DVI. Available information includes deep color setting, audio details and EDID information. To view the loopback settings: 1. Turn the selection knob to highlight Loopback Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 117 The current selection is indicated with an asterisk (*). Turn the selection knob to highlight Off or On and press the ENTER button. b. To view audio details: i. Turn the selection knob to highlight Audio and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 118 HDCP keys specify the number of display devices that can be connected to a source over DVI using HDCP authentication. To run an HDCP check: 1. Turn the selection knob to highlight HDCP Check and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 119 OK to begin the HDCP check. A progress bar will be displayed to show the progress of the HDCP check. HDCP Check in Progress HDCP Check Test in Progress... When the check is complete the results will be displayed. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 120 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 121: Dmc-F

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name DM Transmitter < > Done Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 122 Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. Audio Settings Audio Format: PCM Frequency: 48.0kHz Channels: 2 DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 123 The current selection is indicated with an asterisk (*). Turn the selection knob to highlight Off or On and press the ENTER button. b. To view audio details: i. Turn the selection knob to highlight Audio and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 124 Audio Output Level The output level of the audio signal can be adjusted. To adjust the audio output level: 1. Turn the selection knob to highlight Audio Output Level and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 125 Use the Restore Defaults function to reset the card to its factory settings. The card’s factory settings are: Loopback Allow Deep Color: On Color Space Mode: Force RGB Enable/Disable input: Input enabled Brightness level: 0 Contrast level: 0 Saturation level: 0 Hue level: 0 Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 126 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 127: Dmc-F-Dsp

    To cancel and return to the list of options for the input card, press the MENU button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 128 The DMC-F-DSP can display information about the audio portion of the incoming signal. Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 129 The loopback output can be set to enable or disable the deep color feature of the carried video signal. To enable or disable deep color: i. Turn the selection knob to highlight Allow Deep Color and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 130 Press the MENU button to return to the Loopback Settings. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 131 The DMC-F-DSP can display all EDID data for the source connected to the HDMI IN port. To view EDID information for the connected source: 1. Turn the selection knob to highlight Show Full EDID and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 132 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 133: Dmc-Hd

    To cancel and return to the list of options for the input card, press the MENU button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 134 The DMC-HD can display information about the audio portion of the incoming signal. Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 135 The loopback output can be set to enable or disable the deep color feature of the carried video signal. To enable or disable deep color: i. Turn the selection knob to highlight Allow Deep Color and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 136 Press the MENU button to return to the Loopback Settings. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 137 The DMC-HD can display all EDID data for the source connected to the HDMI IN port. To view EDID information for the connected source: 1. Turn the selection knob to highlight Show Full EDID and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 138 Running an HDCP check will disconnect any audio and video routes that are currently set. To proceed with the HDCP check, press the soft button labeled Yes. To cancel the HDCP check, press the soft button labeled No. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 139 If the number of displays in use exceeds the number of devices supported by the source, an error message will be displayed. 3. Press the soft button labeled OK to return to the list of options for the input card. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 140 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 141: Dmc-Hd-Dsp

    To cancel and return to the list of options for the input card, press the MENU button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 142 The DMC-HD-DSP can display information about the audio portion of the incoming signal. Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 143 The loopback output can be set to enable or disable the deep color feature of the carried video signal. To enable or disable deep color: i. Turn the selection knob to highlight Allow Deep Color and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 144 Press the MENU button to return to the Loopback Settings. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 145 The DMC-HD-DSP can display all EDID data for the source connected to the HDMI IN port. To view EDID information for the connected source: 1. Turn the selection knob to highlight Show Full EDID and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 146 Running an HDCP check will disconnect any audio and video routes that are currently set. To proceed with the HDCP check, press the soft button labeled Yes. To cancel the HDCP check, press the soft button labeled No. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 147 If the number of displays in use exceeds the number of devices supported by the source, an error message will be displayed. 3. Press the soft button labeled OK to return to the list of options for the input card. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 148 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 149: Dmc-Sdi

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name < > Done Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 150: Video Settings

    Available information includes format, frequency, and channels. To view audio settings: 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. Audio Settings Audio Format: PCM Frequency: 48.0kHz Channels: 2 DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 151 Press the MENU button to return to the Loopback Settings. b. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 152 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 153: Dmc-Vid4

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name Security Cameras < > Done Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 154 If the DMC-VID4 is set to rotate the inputs that are displayed, the rotate rate between inputs must be set. To select a rotate rate: 1. Turn the selection knob to highlight Input Rotate Rate and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 155 A cursor will appear next to the current name and controls for changing the name will also be displayed. To cancel and return to the list of options for the input card, press the MENU button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 156 Turn the selection knob to highlight the picture control to be adjusted and press the ENTER button. Controls are available for brightness, contrast, saturation, and hue. Brightness Control Input 1 Video Settings Brightness 0 DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 157 Press the MENU button to return to the list of options for the video input. 3. Press the MENU button to return to the list of options for the input card. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 158 Off or On and press the ENTER button. b. To view EDID information about the display device connected to the HDMI OUT port: i. Turn the selection knob to highlight EDID Information and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 159 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 160: Dmc-Vid-Bnc

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name Video < > Done DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 161 Turn the selection knob to highlight Picture Controls and press the ENTER button. b. Turn the selection knob to highlight the picture control to be adjusted and press the ENTER button. Controls are available for brightness, contrast, saturation, and hue. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 162 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 Brightness Control Input 5 Video Settings Brightness 0 Contrast Control Input 5 Video Settings Contrast 0 Saturation Control Input 5 Video Settings Saturation 0 DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 163 1. Turn the selection knob to highlight Audio Settings and press the ENTER button. Audio Settings Audio Format: PCM Frequency: 48.0kHz Channels: 2 2. Press the MENU button to return to the list of options for the input card. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 164 The current selection is indicated with an asterisk (*). Turn the selection knob to highlight Off or On and press the ENTER button. b. To view audio details: i. Turn the selection knob to highlight Audio and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 165 Brightness level: 0 Contrast level: 0 Saturation level: 0 Hue level: 0 To restore the card’s default settings: 1. Turn the selection knob to highlight Restore Defaults and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 166 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 167: Dmc-Vid-Rca-A

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name Video < > Done Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 168 Turn the selection knob to highlight Picture Controls and press the ENTER button. b. Turn the selection knob to highlight the picture control to be adjusted and press the ENTER button. Controls are available for brightness, contrast, saturation, and hue. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 169 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers Brightness Control Input 4 Video Settings Brightness 0 Contrast Control Input 4 Video Settings Contrast 0 Saturation Control Input 4 Video Settings Saturation 0 Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 170 DMC-VID-RCA-A. Available information includes deep color setting, audio details and EDID information. To view the loopback settings: 1. Turn the selection knob to highlight Loopback Settings and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 171 The current selection is indicated with an asterisk (*). Turn the selection knob to highlight Off or On and press the ENTER button. b. To view audio details: i. Turn the selection knob to highlight Audio and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 172: To Restore The Card's Default Settings

    Brightness level: 0 Contrast level: 0 Saturation level: 0 Hue level: 0 To restore the card’s default settings: 1. Turn the selection knob to highlight Restore Defaults and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 173: Press The Soft Button Labeled Yes To Restore The Default Setting Or Press The

    2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 174: Dmc-Vid-Rca-D

    To cancel and return to the list of options for the input card, press the MENU button. Edit Input Name Edit Input Name < > Done DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 175 Turn the selection knob to highlight Picture Controls and press the ENTER button. b. Turn the selection knob to highlight the picture control to be adjusted and press the ENTER button. Controls are available for brightness, contrast, saturation, and hue. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 176 DigitalMedia™ Switchers Crestron DM-MD8X8/16X16/32X32 Brightness Control Input 2 Video Settings Brightness 0 Contrast Control Input 2 Video Settings Contrast 0 Saturation Control Input 2 Video Settings Saturation 0 DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 177: Press The Menu Button To Return To The List Of Options For The Input Card

    DMC-RCA-D. Available information includes deep color setting, audio details and EDID information. To view the loopback settings: 1. Turn the selection knob to highlight Loopback Settings and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 178 The current selection is indicated with an asterisk (*). Turn the selection knob to highlight Off or On and press the ENTER button. b. To view audio details: i. Turn the selection knob to highlight Audio and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 179: Restore Defaults

    Brightness level: 0 Contrast level: 0 Saturation level: 0 Hue level: 0 To restore the card’s default settings: 1. Turn the selection knob to highlight Restore Defaults and press the ENTER button. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 180 2. Press the soft button labeled Yes to restore the default setting or press the soft button labeled No to cancel and return to the list of options for the input card. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...

  • Page 181: Appendix C: Output Configuration

    ENTER button. A cursor will appear next to the current name and controls for changing the name will also be displayed. To cancel, press the MENU button. Edit Output Name Edit Output Name Living Room < > Done Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 182 Off or On and press the ENTER button. b. When DM Cable Type is selected, the type of DM cable used to connect the output can be displayed or changed. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 183 Allow Deep Color: Turn the selection knob to highlight Allow Deep Color and press the ENTER button. Allow Deep Color Mode Allow Deep Color Mode * Off Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 184 ENTER button. Allow Deep Color can be used to determine whether deep color can be sent over the output. To enable or disable deep color: Turn the selection knob to highlight Allow Deep Color and press the ENTER button. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 185 Maximum Pixel Rate on Output 2 (HDMI output on outputs 1, 3, 5 and 7): 225 Stream Name: Reverts to number of output. (i.e. The name assigned to Stream 1 will be renamed “1”.) Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 186: Glossary

    TV and is commonly used to encode DVD soundtracks. Anamorphic Adopted from the film technique of shooting a wide-screen image on a square 35mm frame, it is the process of compressing wide-screen images to DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 187 Standards Association (VESA) that defines a new license-free, royalty-free, digital audio/video interconnect, intended to be used primarily between a computer and its display monitor, or a computer and a home- theater system. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 188 SDTV Standard-definition television. Digital television format that includes 480- line resolution in both interlaced (480i) and progressively scanned (480p) formats; offers discernible improvement over conventional analog NTSC DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 189 Typically refers to TVs in the 16:9 aspect ratio. Luminance, two chrominance channels of blue minus luminance, red minus luminance. This technical shorthand for component video is also written as or Y R-Y B-Y. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 190: Return And Warranty Policies

    Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures.

  • Page 191: Trademark Information

    U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...

  • Page 192: Gnu General Public License

    License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 193 5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 194 NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32 Operations Guide – DOC. 6755C...
  • Page 195 Crestron DM-MD8X8/16X16/32X32 DigitalMedia™ Switchers This page is intentionally left blank. Operations Guide – DOC. 6755C DigitalMedia™ Switchers: DM-MD8X8/16X16/32X32...
  • Page 196 Crestron Electronics, Inc. Operations Guide – DOC. 6755C 15 Volvo Drive Rockleigh, NJ 07647 (2022812) Tel: 888.CRESTRON 04.10 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.

This manual is also suitable for:

Dm-md32x32Dm-md16x16

Table of Contents

Save PDF
