4. INSTALLATION INSTRUCTIONS

4.5.6. Configure a Hub-Satellite installation

WARNING:
Risk of electric shock, which can cause severe injuries or death. Only a qualified electrician is
permitted to access the installer mode.
1. Make sure the Hub station is on.
2. Switch on electrical power to the Satellite charging stations.
The Satellite charging stations power up and run the start-up sequence.
RF communication is now activated and the Satellite charging stations are ready to pair.
3. Make sure that your smartphone or tablet is paired with the Hub charging station.
4. In the EVBox Connect app, select Installer mode and then enter the Security code.
5. Select Pair RF satellites then select PAIRING MODE.
The app searches for Satellite charging stations.
6. Select the Satellite charging stations you want to pair with the Hub charging station.
The LED rings on the selected satellite charging stations flash purple.
7. Select PAIR TO HUB.
The app pairs the Satellite charging stations with the Hub charging station. The paired Satellite
charging stations are shown in the app.
The Hub-Satellite charging station installation can now use Smart Charging dynamic load balancing
and share a common Internet connection using either a Wi-Fi connection or a cellular network.
