- Page 1 Bluetooth Soundbar ® MODEL: PLSB311 User Manual...
-
Page 2: Welcome
Welcome Welcome to your experience with Polaroid products. © All rights reserved 2019. Polaroid, Polaroid & Pixel, Polaroid Classic Border Logo, and All Polaroid products we bring to you are Polaroid Colour Spectrum are trademarks of PLR IP Holdings, manufactured to the highest standards of LLC, used under license. -
Page 3: Table Of Contents
Contents Welcome Operation General Operation Unpack and Prepare Bluetooth ® What's in the box Pairing Bluetooth Devices ® Important Tips Bluetooth Playback ® Installation Troubleshooting Wall mounting instructions Connect to power Specifications Controls and Connections Compliance and Responsible Disposal Get to know your Soundbar Buttons on the Soundbar Rear Ports on the Soundbar Remote Control... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the box Before setting up your new soundbar, check you have everything: A. Bluetooth Soundbar ® B. Remote Control C. 3.5mm AUX Cable D. Optical Cable E. AC Adapter AUX to RCA Cable G. Wall Mount Adapters H. -
Page 5: Important Tips
Important Tips • Place the soundbar on a level surface. • Place the soundbar away from any source that may generate heat or vibrations. • Make sure there is enough space around the soundbar for airflow. • The remote control works up to 6 metres away from the soundbar. •... -
Page 6: Installation
Installation This soundbar can sit free-standing on a surface, or it can be mounted to a wall. Place on a secure, flat surface. Make sure the soundbar is standing on its rubber pads (on the left and right sides of the soundbar) and no other area of the bottom of soundbar is touching the surface. - Page 7 Wall mounting instructions are on the following pages. • Wall-mounted installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage! If you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing, which may be hidden inside or behind the wall.
-
Page 8: Wall Mounting Instructions
Wall mounting instructions 350mm 725mm Use a pencil to make drill hole marks on the wall for the anchors. Make sure the marks are level 18mm 25mm before drilling. Use a 4mm bit and power drill (not supplied) to drill holes on the marks. Use screws (not supplied) to fix the wall mount adapters on to the wall. -
Page 9: Connect To Power
Connect to power Make sure the soundbar is switched off at the power outlet until you have finished connecting your cables. Don't forget to plug in the soundbar to the power outlet. Leave the power switched off until installation is finished. UNPACK AND PREPARE | 9... -
Page 10: Controls And Connections
Controls and Connections Get to know your Soundbar Front Colour LED indicator light Each mode has its own corresponding Mode LED light colour LED indicator light colour: HDMI (ARC Purple Bluetooth Blue Optical Cyan White LINE IN Yellow AUX IN Green 10 | CONTROLS AND CONNECTIONS... -
Page 11: Buttons On The Soundbar
Buttons on the Soundbar (Power button): Press to turn on. Press again to put in Standby mode. SOURCE : Press to go to previous song. Hold to decrease volume. 3. Play/Pause :Press to go to next song. Hold to increase volume. Right side 5. -
Page 12: Rear Ports On The Soundbar
Rear Ports on the Soundbar ANTENNA LINE IN DC IN 15V AUX IN DC IN 15V POWER Please only use the supplied 15V 2.4V power adapter You can use this to connect Audio to your TV for AV or AUX IN GREEN Component video inputs using the supplied AUX to RCA cable. - Page 13 Plug in a USB stick to play media files stored on your USB CYAN storage device (supported file codecs and extensions may vary). The ARC (Audio Return Channel) function allows you to send HDMI (ARC) audio input from an ARC-compliant TV to an ARC-compliant PURPLE audio device (e.g.
-
Page 14: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure AAA size batteries the batteries are correctly aligned and properly included pushed into place. Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 15: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the soundbar. The remote will not operate if its path is blocked. The remote has a range of up to about 6 metres from the soundbar at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 16: Remote Overview
Remote overview POWER: Switch the unit to ON MODE: Switch between MODE or Standby. the input sources. Increase the volume level. : Skip to the previous track. : Skip to the next track. : Play/Pause/Mute/Unmute. Decrease the volume level. : Increase the bass. : Increase the treble. -
Page 17: Operation
Operation General Operation Function Action Press the POWER /MODE button on the right side of the Turn the soundbar ON soundbar, or press the POWER button on the remote control to switch the soundbar on. Press the POWER /MODE Turn the soundbar button on the sound bar or press the POWER button on... - Page 18 Using the AUX to RCA cable • Use the supplied AUX to RCA cable to connect the TV's stereo AUX (L/R) audio output socket. • Press Mode on the remote control or press Mode on the unit and select the AUX IN function. Using the HDMI (ARC )input •...
- Page 19 Using the Optical input • Use the supplied optical cable to connect the optical output on the audio source and the optical input on the soundbar. • Press the Power button on the soundbar or remote control to switch on the unit. •...
- Page 20 Using the USB • Insert a USB into the USB port to play music through the soundbar. • Press the Mode button on the soundbar or remote control until to switch to USB mode. • Use the remote control to play/pause and/or skip to the next/previous track. •...
-
Page 21: Bluetooth
Activate Bluetooth on your compatible device, and pairing mode automatically. set it to search for compatible devices. Select the name: 'Polaroid PLSB311' from the list of found devices. If a mobile phone on which you are playing music Note: Only one playback unit can be connected to receives a call, the music will be interrupted. -
Page 22: Bluetooth ® Playback
Bluetooth Playback ® Function Action Increase the Volume Hold the button on the unit or on the remote. Decrease the Volume Hold the button on the unit or on the remote. Play/Pause Press on the remote. Skip/Rewind Press on the remote to skip tracks. ®... -
Page 23: Troubleshooting
Troubleshooting If you have problems with the soundbar, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution • Ensure that the 15V power adapter is properly connected. No power •... - Page 24 Problem Solution • Make sure the input source is set to HDMI ARC mode, the LED indicator will light in purple. • Make sure your TV or external device supports ARC function and connect the HDMI cable to the ARC port of the TV or external device. •...
-
Page 25: Specifications
6 metres, 30 degrees (either distance, angle side of sensor) Bluetooth pairing operation range – Up to 10 metres distance Bluetooth pairing name Polaroid PLSB311 For Technical Support: Bluetooth pairing password 0000 Ph: 1300 886 649 DC 5V, 500mA (for playback USB output W: www.tempo.org... -
Page 26: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging Compliance The packaging of your product has been This product complies with the Australian Safety selected from environmentally friendly Standard AS/NZS 60065 to ensure the safety of the materials and can usually be recycled. Please product. - Page 27 Notes...
- Page 28 For Technical and Warranty Support 1300 886 649 www.tempo.org info@tempo.org Distributed by Tempo (Aust) Pty Ltd, PO Box 6056, Frenchs Forest DC 2086...
Need help?
Do you have a question about the PLSB311 and is the answer not in the manual?
Questions and answers
My remote on no longer works the sound bar
To fix the Polaroid PLSB311 sound bar remote that no longer works:
1. Use the remote closer to the unit and aim it directly at the sensor on the front of the soundbar.
2. Check that the battery is installed with the correct polarity (+/-).
3. Replace the battery with a new one if needed.
4. Make sure you are not mixing old and new batteries or different types (e.g., Manganese and Alkaline).
