4
5
6
7
8
9
10
11
Figure 1.2
Port Status LED
POWER LED 1/POWER LED 2
ALARM LED
Failsafe Alarm Relay
Power Supply Terminal
RS-232 Console Port
Copper/Fiber Ethernet Ports
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM M969:
AC or DC power cord (16 AWG)
CAT-5 Ethernet cables
Phillips screwdriver
4 x #6-32 screws
RUGGEDCOM M969
Installation Manual, 01/2021, C79000-G8976-1039-03
POWER 2 LED
ALARM LED
RS-232 Console Port
Failsafe Output Relay
M23 Power Supply Port
Fiber Optic Ethernet Ports
Surge Ground Connection
Chassis Ground Connection
RUGGEDCOM M969 (RJ45 Connectors Shown)
Tools/Materials
Indicate the status of each port.
State
Yellow (Solid)
Yellow (Blinking)
Off
Illuminates when power is supplied to the associated internal
power supply.
Indicates when an alarm condition exists.
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 11)"
• "Failsafe Alarm Relay Specifications (Page 23)"
The power supply port. For more information, refer to:
• "Connecting Power (Page 12)"
• "Power Supply Specifications (Page 23)"
For interfacing directly with the device and accessing initial
management functions. For information about connecting to the
device via the console port, refer to
17)".
For information about available copper and fiber Ethernet ports,
refer to "Communication Ports (Page
For connecting power to the device.
For connecting the device to the network.
For mounting the device to a panel.
For mounting the device to a panel.
Introduction
1.3 Required Tools and Materials
Description
Link established
Link activity
No activity
"Connecting to the Device (Page
19)".
Purpose
5
