PARTS INCLUDED
IN YOUR KIT:
Driver side cover rail
A
Passenger side cover rail
B
Roll cover
C
Harware Bag (see Installation Parts Include).
D
D
Installation Parts Include:
D2
J-Nut
D1
Drill Guide
2X
Tools Required:
Drill
T30 Torx
1
The serial number for the cover is located here.
For future reference, write it here:
___________________________________.
3
If the truck is equipped with factory bed caps, you will need
to install the bulkhead seal supplied in the shipping box. If the
truck is equipped with aftermarket bed caps, we recommend that you
call customer service at 877-878-9336 to purchase bulkhead seal.
TruXedo Inc. • 2209 Kellen Gross Drive Yankton, SD 57078 • 877-878-9336 • truxedo.com ©TruXedo Inc., 2020
OWNER'S MANUAL
Damaged or missing parts? Call 877-878-9336 Mon - Fri 8 am - 5 pm CT
Parts will be shipped to you factory direct. Do not return kit to place of
purchase.
READ INSTRUCTIONS - Failure to assemble cover properly will void
warranty. To view install video visit truxedo.com/lopro
Button head
D4
D3
M6 x 30MM
12X
10X
7.00 mm(9/32")
drill bit
A
D4
D3
Clamps
12X
2
It is important that all areas where the bed cover mounts are
clean and free of debris prior to installing.
For steps 4 thru 5 use hardware D1 and D2. Drill and 7MM drill bit
will also be used in these steps.
D1
TOOLS REQUIRED:
Page 1
C
B
Note: In fig. 1 , 2 and 3
D2
the J-nuts are shown
inserted behind the bed
caps.
Part# 1118564, Rev. P1 03-02-2021
