  • Page 2 SonoSite, VisualSonics, Vevo, Vevo MD and the VisualSonics logo are registered and unregistered trademarks of FUJIFILM SonoSite, Inc. in various jurisdictions. All other trademarks are the property of their respective owners. FUJIFILM VisualSonics, Inc. is a subsidiary of FUJIFILM SonoSite, Inc.

  • Page 3: Table Of Contents

    Vevo MD Getting Started Guide - English Overview Unpack the box Set up the ramp Remove the system Set up the system Connect the system to power Basic operating instructions Vevo MD Getting Started Guide - English...

  • Page 4: Overview

    Overview The Vevo MD Getting Started Guide explains how to unpack, set up, and begin using the Vevo MD Imaging System. For more in-depth instructions on how to use the system, see either: Vevo MD Help, available on the system. To access Help on the system, tap MORE and then tap Help.

  • Page 5: Unpack The Box

    Unpack the box The packing box includes an accessory box, and a crate that holds the system in place. 1 Remove the straps from the packing box. 2 Raise the lid on the packing box. Avoid damaging the lid, as it will be used later as a ramp.

  • Page 6: Set Up The Ramp

    Set up the ramp The crate lid can be used as a ramp that allows you to remove the system from the crate. 1 With a box cutter, cut all four corners of the lid so that it lays flat. 2 With the corrugated ramp supports on the bottom, place the highest end of the ramp next to the base of the crate.
  • Page 7 4 Using a 3/8-inch wrench, loosen and remove the wheel clamps. Figure 1-3 Removing the wheel clamps Vevo MD Getting Started Guide - English...

  • Page 8: Remove The System

    Remove the system 1 To unlock the wheels, press upon the rear of the locking lever on the wheels. 2 Roll the system down the ramp. Figure 1-4 Roll the system down the ramp. 3 Remove the plastic bag and packaging materials from the system and inspect the system for damage.
  • Page 9 4 Wheel the system to its intended destination. When transporting the system, push forward instead of pushing downward on the bar or pushing the display monitor. Figure 1-5 Push forward to wheel the system 5 When the system is at its desired location, lock the wheels: press down on the lever on the wheels.

  • Page 10: Set Up The System

    Set up the system 1 Raise and adjust the display monitor: a Grasp the display monitor on both sides and fold it upward. Figure 1-6 Folding the display monitor up. b Grasp the display monitor on both sides and tilt or rotate it to adjust its angle. Set up the system...
  • Page 11 2 Grasp both sides of the touch panel and pull it forward or push it backward to the desired angle. Figure 1-7 Angling the touch panel display. Vevo MD Getting Started Guide - English...
  • Page 12 3 When you are finished, your system should look as it does in Figure 1-8. Figure 1-8 Vevo MD Imaging System Set up the system...

  • Page 13: Connect The System To Power

    Warning: Use only power cords provided by FUJIFILM SonoSite with the system. Using power cords from other sources, may damage the system. 1 Connect the AC power cord, located in the accessory box, to the stand base and secure the AC power cord with the retainer wire.
  • Page 14 Figure 1-10 The power button. Caution: Do not use the system if an error message appears on the clinical display or control panel. Note the error code and turn off the system. Call FUJIFILM SonoSite. Connect the system to power...
  • Page 15 Restarting the system while it is performing data-intensive background activities, such as exporting data files, can result in loss of data. FUJIFILM SonoSite recommends waiting at least 3 minutes before restarting an unresponsive system. To power down an unresponsive system, press and hold the power button until the system shuts down.

  • Page 16: Basic Operating Instructions

    4 Enter patient information. 5 Scan. 6 Save data. 7 Export data. Connecting a transducer Caution: Only transducers manufactured by FUJIFILM SonoSite may be used with this system. Using transducers not manufactured by FUJIFILM SonoSite will cause damage to the system. Basic operating instructions...
  • Page 17 Caution: Only use coupling gels that are specifically approved for use with the Vevo MD Imaging System. Using coupling gels that are not approved, may cause damage to the transducers. To connect the transducer 1 Turn the lock handle clockwise to the vertical (unlocked) position. 2 Slide the transducer connector into the transducer bay underneath the control panel.
  • Page 18 To disconnect the transducer 1 Flip the lock handle up and rotate clockwise to the vertical (unlocked) position. 2 Pull the transducer connector away from the transducer interface. 3 Slide the connector up and out of the transducer bay. Basic operating instructions...
  • Page 19 *53152*                                          53152 1.0...
