• For U280 ES:
65:00.0 Serial controller: Xilinx Corporation Device 5009 (prog-if 01
[16450])
65:00.1 Serial controller: Xilinx Corporation Device 5008 (prog-if 01
[16450])
:
Note For deployment shells earlier than 2018.3, User PF is assigned to function 0 and Management PF is
assigned to function 1.

Running xbutil flash scan

Use the xbutil flash scan command to view and validate the card's current firmware
version, as well as display the installed card details, including card ID, shell name, and timestamp.
1. Enter the following command:
$ sudo /opt/xilinx/xrt/bin/xbutil flash scan
UG1301 (v1.3) February 12, 2019
Getting Started with Alveo Accelerator Cards
Capabilities: [100] Advanced Error Reporting
Capabilities: [400] Access Control Services
Capabilities: [410] #15
Kernel driver in use: xocl_xdma
Kernel modules: xocl
Subsystem: Xilinx Corporation Device 000e
Flags: bus master, fast devsel, latency 0, IRQ 191, NUMA node 0
Memory at de000000 (32-bit, non-prefetchable) [size=32M]
Memory at e0000000 (32-bit, non-prefetchable) [size=128K]
Capabilities: [40] Power Management version 3
Capabilities: [60] MSI-X: Enable+ Count=33 Masked-
Capabilities: [70] Express Endpoint, MSI 00
Capabilities: [100] Advanced Error Reporting
Capabilities: [1c0] #19
Capabilities: [1f0] Virtual Channel
Capabilities: [e00] Access Control Services
Kernel driver in use: xocl_xdma
Kernel modules: xocl
Subsystem: Xilinx Corporation Device 000e
Flags: fast devsel, NUMA node 0
Memory at dc000000 (32-bit, non-prefetchable) [size=32M]
Memory at e0020000 (32-bit, non-prefetchable) [size=64K]
Capabilities: [40] Power Management version 3
Capabilities: [60] MSI-X: Enable- Count=33 Masked-ss
Capabilities: [70] Express Endpoint, MSI 00
Capabilities: [100] Advanced Error Reporting
Capabilities: [e00] Access Control Services
Kernel driver in use: xclmgmt
Kernel modules: xclmgm
Chapter 5: Card Bring-Up and Validation
