- Page 1 INDUSTRIAL SEWING MACHINE CC-Link IE FIELD BASIC Communication Equipment MODEL PLK-J-LAN TECHNICAL MANUAL A180E805P01...
-
Page 2: Table Of Contents
contents [1] For safe use __________________________________________________ [2] Precautions for use ____________________________________________ [3] Use __________________________________________________________ [4] Name of each part _____________________________________________ [5] Pin number of connectors _______________________________________ [6] External dimensions ___________________________________________ 7 [7] Connection method ____________________________________________ 7 1. How to XC-G ......................8 2. - Page 3 * The contents of this manual are subject to change without notice. * An utmost effort has been made to cover all points of operation in this manual. Contact Mitsubishi if you have any questions regarding the contents. COPYRIGHT(C)2018 MITSUBISHI ELECTRIC CORPORATION...
-
Page 4: For Safe Use
[1] For safe use ■For safe use Always observe the following matters to safely use this product. Before starting Before using this product, read all of the technical manuals carefully, and correctly use the unit following the manual. Also read the instruction manual of the sewing machine to be installed. Application and purpose This product is designed as a communication device with the Mitsubishi industrial sewing machine. -
Page 5: Precautions For Use
Please make sure not to turn on the power supply switch until after the LED on the front panel of the control box has completely turned off. *Please note that if power supply is turned on again while LED still turns on, the data in the PLK-J-LAN may be damaged. -
Page 6: Use
We learn information such as sewing time from the sewing machine and perform Ethernet communication with the master station as slave station. Required network equipment Equipment of the master station: Mitsubishi Electric PLC (MELSEC iQ-F、iQ-R series) Equipment for display: PC, Mitsubishi Electric Display etc. Other equipment: HUB etc. -
Page 7: Name Of Each Part
[4] Name of each part 1. Front side 2. Back side Name Function LED (green) POWER LED LED (red) Warning LED CON A (USB-Mini B connector) Do not use Connect the operation box (XC - G10 / XC - G 500). CON B (MINI-DIN connector) Please do not use when connecting with PLK-G series. -
Page 8: Pin Number Of Connectors
DC 24V less Example of use External power supply Inside the PLK-J-LAN load * Please use external power supply as the power source of the connected equipment. (2) Input Example of use * Please use GND of PLK-J-LAN for GND. - Page 9 (3) Analog output output Connector pin Power Output voltage Maximum ratings current CON C 9PIN DC12V DC 0~10V 0.01A less * Use the input resistance of the connection destination at 1kΩ or more Example of use Input devise * Output total 0.1A or less Power DC12V PLK-J-...
-
Page 10: External Dimensions
[6] External dimensions φ4.5 4.5 ㎜ 125.3 ㎜ 40 ㎜ [7] Connection method CON B Front Operation box side XC-G10 / XC-G500 Back side CON E Network equipment RS232C cable XC-G control box PLK-G control box... -
Page 11: How To Xc-G
PLK-J-LAN front side PLK-J-LAN Back side LAN cable LAN cable Example of PLK-G connection method * Connect the RS233C cable of PLK-J-LAN to the front panel of the control box. RS232C cable PLK-J-LAN back side LAN cable PLK-G Control box... -
Page 12: Installation And Setting
[8] Install and setting In order to use PLK-J-LAN, it is necessary to use USB flash drive, install LAN system data, and set IP address etc. * When setting only the IP address etc. please put the setting data in the USB flash drive. -
Page 13: How To Use
･Connect the cable of the operation box (XC-G10 / XC-G500) to the CON B on the front of the PLK-J-LAN. ･Connect the network equipment to the CON E on the back of the PLK-J-LAN with a LAN cable. 2. Please prepare the LAN system data etc. in the USB flash drive. (Refer to [8] install and setting) 3. -
Page 14: Confirmation
[10] Confirmation 1. Before turning the switch on (1) Are the cable correctly inserted ? ･Cable for connection with sewing machine. ･Cable for connection with HUB. ･Cable for connection with operation box. 2. After turning switch on (1) Is the front panel power LED (green) on. ? (2) Is the front panel warning LED (red) on or flickering. -
Page 15: Error Indication
[11] Error indication When an error occurs, the error display LED (red) on the front panel blinks. Please deal with the reference below. PLK-J-LAN front panel error display LED (red) is blinking [ Red LED ] Blink pattern ☼ : ON : OFF ☼... -
Page 16: Specification
[12] Specification Basic specifications MITSUBISHI RIMI Servo Mitsubishi electronic pattern sewing access point XC-G series machine PLK-G series XC-G series control box Connected equipment PLK-G series control box Operation box DC12V DC12V power supply (Supplied from the control box) (Supplied from the control box) Main function Serial communication <- ->... - Page 20 MITSUBISHI ELECTRIC CORPORATION Printed in Japan...
