Step 16: Replacing the toekick
You'll need:
•
Place the toekick against the legs of the dishwasher. The slots should align with the toekick bracket screw holes.
Allow the toekick to touch the floor. Install the toekick screws.
Specifications
Capacity
Dimensions (WxDxH)
Weight
Power requirements
Current
Water pressure
Noise (dB)
Phillips screwdriver
Max 16 place settings
23.9 x 24.5 x 33.8 in. (60.6 x 62.2 x 85.8 cm)
90.4 lbs. (41 kg)
120 V~60 Hz
8.4 A
Between 20 and 120 psi (138 and 877 kPa)
49 dB
www.insigniaproducts.com
Top Control Dishwasher
23
