CHAPTER 4: OPERATION

4.1 PC PORT SWITCHING

There are two ways to access computers and devices connected to the KVM switch:
Š Manual Pushbutton Š
Š Hotkeys Š

4.1.1 MANUAL PUSHBUTTON

Press the pushbutton once, switching the selected PC port among the two connected computers cyclically.

4.1.2 HOTKEY COMMANDS

Hotkey commands are executed using only the keyboard.
The following procedure describes the hotkey functionality availability.
Hotkey Execution Procedure
1. Press the [Scroll Lock] key twice continuously to enter Hotkey mode. While in Hotkey mode, the Scroll Lock LED of the keyboard
flashes continuously. When entering or exiting from Hotkey mode, the buzzer of the KVM switch beeps.
2. Press the [Scroll Lock] key twice continuously within 5 seconds.
3. Key in the hotkey command within 10 seconds, or it will be aborted if the time exceeds 10 seconds.
NUMBER HOTKEY COMMAND
[Scroll Lock] [Scroll Lock] [Enter]
1
or [Ctrl] [Ctrl] [Enter]
[Scroll Lock] [Scroll Lock] [B] [Number]
2
or [Ctrl] [Ctrl] [B] [Number]
3 [Scroll Lock] [Scroll Lock] [S] or [Ctrl] [Ctrl] [S]
[Scroll Lock] [Scroll Lock] [I] [Number] [Enter]
4
or [Ctrl] [Ctrl] [I] [Number] [Enter]
NOTE: All hotkey value settings of the KVM switch return to default when it restarts.
TABLE 4-1. HOTKEY COMMANDS
DESCRIPTION
PC-1 PC-2
Number: 0/1
0: Disable
1: Enable (Default)
How to stop Auto-Scan when it's on:
1. Press any key on the keyboard.
2. Press the pushbutton once.
When Auto-Scan stops, the PC port
is switched to the one being scanned.
Number: 5 to 99 (Default: 5)
1.877.877.2269 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
FUNCTION
PC port cyclic switching
Buzzer switch on/off
Auto-Scan enabling
Auto-Scan time interval setting
